CDVI ATRIUM AC22 Installation Manual

2-door controller
Hide thumbs
Table of Contents

Advertisement

Quick Links

ENGLISH
EN
AC22
2-Door Controller
The installer's choice
cdvigroup.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ATRIUM AC22 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CDVI ATRIUM AC22

Summary of Contents for CDVI ATRIUM AC22

  • Page 1 ENGLISH AC22 2-Door Controller The installer’s choice cdvigroup.com...

  • Page 2: Table Of Contents

    7] WARRANTy - TERMS & CONDITIONS ..........30 Copyright (C) 2011 CDVI. All rights reserved. ATRIUM Access Control is protected by copyright law and international treaties.

  • Page 3: Product Presentation

    INSTALLATION MANUAL ATRIUM 2-Door Controller 1] PRODUCT PRESENTATION The AC22 is a powerful Web-Based IP controller that can manage up to 10 doors (2 on-board and 8 using four 2-door expansion modules, AX22). Ten AC22 controller can be add to a site for a maximum of 100 doors per site. The AC22 includes an embedded web server that combines performance and simplicity enabling you to manage Users/Cards, lock or unlock doors, view system events and display controller information from any place in the world! Industry-unique and effortless card enrollment mode minimizes system start up and simplifies your life.

  • Page 4: Notes And Recommendations

    UL 294 COMPLIANCE NOTICE • Use only UL 294 listed power supply • Connect CDVI LED status indicator, part number 7020-0001-0000, to the DC Input gray terminals of the AC22. Note: Backup battery provides operation of up to 12 hours but has been tested for 4 hours per Section 33 of UL 294, fifth edition.

  • Page 5: Recommended Wiring

    INSTALLATION MANUAL ATRIUM 2-Door Controller RECOMMENDED WIRING Maximum Equipment Wire Type Size Length 4 to 8 conductors, stranded, shielded (foil), drain Card reader and 22AWG (0.64mm) to conductor. For example: Alpha 5196, 5198, 5386, 150m (500ft.) 18AWG (1.02mm) Wiegand keypad 5388, Belden 9553 Zone input 2 conductors, copper 22AWG (0.64mm)
  • Page 6 Battery Backup 12Vdc 7Ah rechargeable acid/lead or gel cell backup battery (UL/ULC: YUASA #NP7-12 Battery Capacity recommended, Europe: CDVI B7AH recommended). Ensure proper polarity. 250mA (default), 320mA, 500mA, or 1A. Refer to the ATRIUM user interface instruction manual Charging Current for more information on how to modify the battery charging current.

  • Page 7: Package Contents

    INSTALLATION MANUAL ATRIUM 2-Door Controller 3] PACKAGE CONTENTS This chapter details how to install and setup the ATRIUM 2-Door Controller. CONTENT OF ThE 2-DOOR CONTROLLER The 2-Door Controller contains: • One 2-Door Controller module in its cabinet with connection diagram label •...

  • Page 8: Location And Mounting

    INSTALLATION MANUAL ATRIUM 2-Door Controller LOCATION AND MOUNTING The cabinet is designed to be installed indoors, in a safe and secure location. Suggested locations include electrical rooms, communication equipment rooms, closets or in the ceiling. To save time, wiring and facilitate testing, install the cabinets at an equal distance between its controlled doors.

  • Page 9: Mounting Instructions

    INSTALLATION MANUAL ATRIUM 2-Door Controller 4] MOUNTING INSTRUCTIONS The box needs to be prepared before fixing it to its location. INSTALLINg ThE TAMPER SWITChES Installing tamper switches allows the AC22 to detect when the cabinet door is opened and/or when the cabinet is removed from the wall.
  • Page 10 INSTALLATION MANUAL ATRIUM 2-Door Controller Install the wall tamper switch using the supplied bolts and nuts as shown in the following picture. Install the tamper switch plastic spacer on the back at bottom left side of Enclosure Side View the box as show in the following picture.
  • Page 11 INSTALLATION MANUAL ATRIUM 2-Door Controller Install the door tamper switch by aligning the switch holes to the pre-installed plastic bracket pins. Press firmly to secure the tamper switch in position, then fix the bracket to is mounting flange. Refer to page page 16 for tamper switch wiring diagram. Fix the tamper switch to the bracket then mount the bracket on the...

  • Page 12: Installing The Box Lock

    INSTALLATION MANUAL ATRIUM 2-Door Controller INSTALLINg ThE BOx LOCK Installing the box lock allows to secure the box from non authorized access. If needed install the box lock as shown in the following picture (inside view of the door). Remove the box door knock-out. Insert the lock in the hole.

  • Page 13: Fixing The Box To Its Location

    INSTALLATION MANUAL ATRIUM 2-Door Controller FIxINg ThE BOx TO ITS LOCATION Install the box to its location using 4 screws (not supplied) as shown in the following picture. If the wall tamper switch is used, make sure that the tamper switch arm moves freely and is completely pushed in when the enclosure is installed on the wall.

  • Page 14: Installing The 2-Door Controller Pc Board

    INSTALLATION MANUAL ATRIUM 2-Door Controller INSTALLINg ThE 2-DOOR CONTROLLER PC BOARD Install the 7 fasteners (PCB holder) supplied respectively to the box holes identified in red in the following picture. cdvigroup.com...
  • Page 15 INSTALLATION MANUAL ATRIUM 2-Door Controller Install the 2-Door Controller PCB by aligning the fasteners with the corresponding PCB holes and pressing firmly to secure the PCB in place. AC22 2-Door Controller cdvigroup.com...

  • Page 16: Wiring Diagram

    INSTALLATION MANUAL ATRIUM 2-Door Controller 5] WIRING DIAGRAM CONNECTINg ThE BOx TAMPER SWITChES Connecting the tamper switches allows the 2-Door Controller to detect when the cabinet door is opened and/or when the cabinet is removed from the wall. To install the tamper switches, see “Installing the Tamper Switches”. To use both switches: Connect one end of the supplied wire, the one with a log at each end, to the door tamper switch terminal and the other end to the wall tamper switch terminal.

  • Page 17: Connecting Bells

    INSTALLATION MANUAL ATRIUM 2-Door Controller CONNECTINg BELLS The ATRIUM 2-Door Controller supports the connection of one or several bells or sirens in parallel. The high current output allows to drive bell(s)/siren(s) in parallel for up to 40 watts total. The Bell control circuitry gives the following indications.

  • Page 18: Connecting Readers And Keypads

    INSTALLATION MANUAL ATRIUM 2-Door Controller CONNECTING READERS AND KEyPADS The 2-Door Controller allows automatic format detection and decoding of the connected reader/keypad. When installing a keypad with a Wiegand output, the keypad’s “D0” and “D1” wires should be connected to the same terminals as the reader (the reader output must be open collector).

  • Page 19: Connecting Inputs

    INSTALLATION MANUAL ATRIUM 2-Door Controller CONNECTING INPUTS The 2-Door Controller can monitor the state of up to 20 devices (using zone doubling) such as magnetic contacts, motion detectors, temperature sensors, or other devices. The following are examples of the type of inputs that can be monitored: Magnetic Door Contact: Permits supervision of door “status”...
  • Page 20 INSTALLATION MANUAL ATRIUM 2-Door Controller Examples of Input Connection Methods Single without EOL and without TAMPER Supervision INPUTS (Limit of 1 Detection Device on the Input) 12V Z1 GND Z2 Z3 GND Z4 Z5 When using this method, only one device can be connected to the input.
  • Page 21 INSTALLATION MANUAL ATRIUM 2-Door Controller Single with WIRE SHORT and WIRE CUT Supervision INPUTS (Limit of 1 Detection Device on the Input) 12V Z1 GND Z2 Z3 GND Z4 Z5 When using this method, only one device can be connected to the input.

  • Page 22: Door - Locking Devices

    INSTALLATION MANUAL ATRIUM 2-Door Controller DOOR - LOCKINg DEVICES Each 2-Door Controller Module has two lock outputs and each of these outputs is associated to a reader input. When the LOCK OUTPUT is configured (see “Jumper Settings” on page 17) to provide power (12Vdc), the LOCK OUTPUT is protected by a fuseless protection monitoring algorithm and will shutdown if the current exceeds 750mA @ 12Vdc.
  • Page 23 INSTALLATION MANUAL ATRIUM 2-Door Controller Wiring Diagram of Locking Device Using On-Board Lock Outputs: 750mA @ 12Vdc Power Supply ENERGIZED (12V) Work with “Fail Safe” device Electromagnetic Option AC22 Door Strike Option 2-Door Controller Default DE-ENERGIZED (0V) Work with “Fail Secure” device Using External Lock Outputs:...

  • Page 24: Power Connections

    INSTALLATION MANUAL ATRIUM 2-Door Controller POWER CONNECTIONS Do not power up the 2-Door Controller until all connections are completed. The module operates from any 120/240 Vac sources using the supplied AC/DC power supply and provides fully monitored power solutions using: •...
  • Page 25 INSTALLATION MANUAL ATRIUM 2-Door Controller AC Terminal Fuse The following steps are only presented in case you need to replace the AC terminal fuse. 1. Disconnect the AC power cord from the power source or for permanent installation, turn off the power breaker 2.
  • Page 26 12Vdc 7Ah rechargeable acid/lead or gel cell backup battery (UL/ULC: YUASA #NP7-12 recommended, Europe: CDVI B7AH recommended). Ensure proper polarity. Various (means any type, from any manufacturer that complies with the “Technical Data and securement means” and meets the “Mark of conformity”...

  • Page 27: Led Indicators

    INSTALLATION MANUAL ATRIUM 2-Door Controller LED INDICATORS The ATRIUM 2-Door Controller has several status LEDs that are very useful to diagnose problems when using or installing the ATRIUM system. Refer to the following picture for the emplacement of those LEDs on the ATRIUM 2-Door Controller.

  • Page 28: Ethernet 10/100 Mbps Network Connection

    INSTALLATION MANUAL ATRIUM 2-Door Controller EThERNET 10/100 MBPS NETWORK CONNECTION The ATRIUM 2-Door Controller provides a 10/100Mbps Ethernet port to allow direct connection from a local PC or interconnect to an existing LAN/WAN. Connect the Ethernet 10/100 Mbps port of the ATRIUM 2-Door Controller to a LAN or WAN network using an UTP cable (maximum 100m (300ft)).

  • Page 29: Connecting Expander Modules To The Controller

    INSTALLATION MANUAL ATRIUM 2-Door Controller CONNECTINg ExPANDER MODULES TO ThE CONTROLLER The 2-Door Controller has a RS485 LOCAL BUS terminal allowing the connection with the ATRIUM expander module. The RS485 LOCAL BUS communication is up to 1220 m (4000 ft) maximum of wires. Connect the expander module’s using these topologies: DAISy ChAIN AC22...

  • Page 30: Programmation

    INSTALLATION MANUAL ATRIUM 2-Door Controller 6] PROGRAMMATION The stand-alone card enrollment allows you to add or delete user cards without the need of a PC by using one of the following procedures. CARD ENROLLMENT PROCEDURE (USINg 2-DOOR CONTROLLER MODE BUTTON). Press and hold the on-board MODE button for 1 second.

  • Page 31: Card Enrollment Procedure (Using Master & Programming Cards Only)

    INSTALLATION MANUAL ATRIUM 2-Door Controller CARD ENROLLMENT PROCEDURE (USING MASTER & PROGRAMMING CARDS ONLy). Present the MASTER card to a reader. The door will unlock. Within 5 seconds, present the PROGRAMMING card to the reader. Reader LEDs will begin flashing in sequence Carte Master (2 Red flashes + 2 Green).

  • Page 32: Warranty - Terms & Conditions

    CDVI or a local CDVI subsidiary. The “5 Year Warranty” is only applicable to hidden defects detected during the lifetime of the product, as defined by the CDVI Group (5 years or 200 000 operations - whichever of the two expires first).
  • Page 33 • Any product which has undergone even the slightest modification or change; • Any product which has been installed and/or used with any auxiliary device not supplied by CDVI; • Any product which has been used for demonstrations or display;...
  • Page 34 INSTALLATION MANUAL ATRIUM 2-Door Controller NOTES: cdvigroup.com...
  • Page 35 INSTALLATION MANUAL ATRIUM 2-Door Controller NOTES: cdvigroup.com...
  • Page 36 Reference : G0301EN0413V02 Extranet : EXE-CDVI_IM AC22 CMYK A4 EN 02 *G0301EN0413V02* CDVI group FRANCE (Headquarter/Siège social) Phone: +33 (0)1 48 91 01 02 Fax: +33 (0)1 48 91 21 21 CDVI CDVI FRANCE + EXPORT IBÉRICA Phone: +33 (0)1 48 91 01 02...
