I N S T A L L A T I O N M A N U A L
X-STREAM SLIDE COMPONENTS
IMPORTANT: For a Left Hand Slide, Flume A, B is upper flume, and C, D is the lower
flume, in that order. For a Right Hand Slide, C, D is the upper flume and A, B is the lower
flume. Flumes are labeled A, B or C, D in small letters centered on flanges.
A,B Flume
Bottom Section
Step Support
Handrail
XS-IM Rev. 7/08 (SBK-XS INSTALL)
C,D Flume
Top Section
Hardware Kits (5)
X - S T R E A M ™ S L I D E
Straight Leg
Foot (2)
Long Leg
7
Ladder 16˚
Foot (1)
Short Leg
NOTE: In-line ball
valve (not shown)
is included by Mfr.
