I N S T A L L A T I O N M A N U A L
X-STREAM™ SLIDE
ALL CHART INFORMATION BELOW CORRESPONDS WITH THE DRAWING ON THE PREVIOUS PAGE.
<---
DRAWING REPRESENTS THE FOLLOWING PART NUMBERS:
XS-GR-SS
ITEM # COMPONENT
1 XS-RIGHT FLUME
2 XS-LEFT FLUME
3 XS-BOTTOM
4 XS-TOP SIDE
5 XS-L HANDRAIL
6 XS-R HANDRAIL
7 XS-FOOT PEDESTAL
8 XS-16 FOOT PEDESTAL
9 H-6 X 26
10 H-6 X 50.125
11 H-6 X 71.5
12 XS-STEP
13 H-.463 X .310 CAP
14 H-.562 X .390 CAP
15 H-SS 3/8 F NUT
16 H-SS 3/8 FLT WASHER
17 H-SS 3/8 LOC WASHER
18 H-SS 3/8 NYLON
19 H-SS 3/8 WEDGE
20 H-SS 3/8 X 3 TAP
21 H-SS 3/8 X2-1/2
22 H-SS 3/8-16X2
23 H-SS 3/8X2-1/2
24 H-SS 5/16 FLA WASHER
25 H-SS 5/16 HEX FLANGE
26 H-SS 5/16 X 2
27 H-SS 5/16 X 2-1/2
28 H-SS 5/16 X 3
29 H-1 BALL VALVE
30 H-NYLON ROD 101
31 H-1 SPA HOSE
32 H-XS GASKET
33 XS-STEP COMP
34 H-ANTI-SEIZE
* not pictured
NOTES:
X-Stream slide only comes in Summit Gray
X-Stream can turn to the right or the left
XS-IM Rev. 7/08 (SBK-XS INSTALL)
:
(XS-GR-SS)
DESCRIPTION
A & B RIGHT HAND FLUME SECTION
C & D LEFT HAND FLUME SECTION
BOTTOM SECTION
TOP SIDE SECTION WITH WARNING
LEFT HANDRAIL WITH X-STREAM LOGO
RIGHT HANDRAIL WITH X-STREAM LOGO
STRAIGHT FOOT PEDESTAL
16 DEGREE FOOT PEDESTAL
6" X 26" GRAY PVC PIPE SCHEDULE 40
6" X 50.125" GRAY PVC PIPE SCHEDULE 40
6" X 71.5" GRAY PVC PIPE SCHEDULE 40
X-STREAM BLOW MOLDED STEP
GRAY PROTECTIVE CAP
GRAY PROTECTIVE CAP
3/8" FINISH NUT S.S.
3/8" X 1" FLAT WASHER S.S.
3/8" LOCK WASHER S.S.
3/8" NYLON INSERT NUT S.S.
3/8" X 2-3/4" WEDGE ANCHOR W/NUT & FLAT WASHER S.S.
3/8" X 3" HEX HEAD TAP BOLT S.S.
3/8" X 2-1/2" HEX HEAD BOLT S.S.
3/8" X 2" HEX HEAD BOLT S.S.
3/8" X 2-1/2" ALL-THREAD STUD S.S.
5/16" FLAT WASHER S.S.
5/16" HEX FLANGE NUT S.S.
5/16" X 2" ALL-THREAD STUD S.S.
5/16" X 2-1/2" ALL-THREAD STUD S.S.
5/16" X 3" ALL-THREAD STUD S.S.
1" BALL VALVE-SLIP GRAY
NAT NYLON ROL 101 .375 DIA.
GRAY SPA HOSE FOR STEP ASSEMBLY, 10 FT. LENGTH
GASKET FOR X-STREAM SLIDE 3/8"
COMPLETE ASSEMBLED STEP, INCLUDES ITEMS 11, 12, 29, 30, & 31
ANTI-SEIZE PACKET (NOT SHOWN)
X - S T R E A M ™ S L I D E
HARDWARE KITS/PARTS KITS – QTY. COUNTS
1
1
1
1
1
1
2
1
1
1
11 20
12
22 20
12
11
8
1
10
4
3
1
HARDWARE NOTE:
Use a small dab of
anti seize lubricant
(included) on all bolt
threads.
21
1
5
10
12 12
12
12 12
12
12
4
12
4
6
2
1*
5*
10*
