VESA Adapter for Compatible Dell Monitors
Instruction Manual
SKU: MOUNT-DLS024
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/mount-dls024
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Related Manuals for Vivo MOUNT-DLS024
Summary of Contents for Vivo MOUNT-DLS024
- Page 1 VESA Adapter for Compatible Dell Monitors Instruction Manual SKU: MOUNT-DLS024 Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-dls024 GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
- Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
- Page 3 STEP 2 Mount the VESA adapter (A) with attached monitor to your VESA mount using M4x10mm thumbscrews (B) and M4 washers (C), making sure to use two washers with each screw. Insert two M4x20mm screws (D) partially into the unused upper holes, then places the soft pads (E) on the ends of the screws.
- Page 4 - 92% within < 3hr www.vivo-us.com AVG. RESOLUTION TIME : < 15 M (within office hrs) Chat live with an agent! 309-278-5303 AVG. RESOLUTION TIME : 5M 4S (within office hrs) FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
