White Universal Drop Ceiling Projector Mount
Instruction Manual
SKU: MOUNT-VP07DP
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/mount-vp07dp
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303

Advertisement

loading
Need help?

Need help?

Do you have a question about the MOUNT-VP07DP and is the answer not in the manual?

Questions and answers

Summary of Contents for Vivo MOUNT-VP07DP

  • Page 1 White Universal Drop Ceiling Projector Mount Instruction Manual SKU: MOUNT-VP07DP Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-vp07dp GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
  • Page 2: Package Contents

    NOTE: SOME HARDWARE INCLUDED MAY NOT BE USED CAUTION! DO NOT INSTALL INTO DRYWALL ALONE. VERIFY YOUR CEILING CONSTRUCTION. USE WOOD STUDS TO MOUNT. We include mounting for brick and concrete. If unsure, please contact us at vivo-us.com, email at help@vivo-us.com, or call us at 309-278-5303.
  • Page 3: Tools Needed

    TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. 29.7 lbs Failure to do so may result in serious injury. (13.5 kg) Phillips Drill Screwdriver ASSEMBLY STEPS STEP 1 Remove plastic plug from Ceiling Plate (D). STEP 2 Insert toggles at end of Y-Cable (F) into 2 of the 16 slots on the top of the Ceiling Plate (D), making sure the slots chosen will provide optimal support for the mount with projector.
  • Page 4 STEP 3 Push Clips (E) down over T-bar to hold the Ceiling Plate (D) down. STEP 4 Connect Bracket (B) to Mount (A) using Plastic Oval Washers (S-F), Plastic M5 Washer (S-E), Small M5 Washer (S-D), M5x12mm Screw (S-C), and 4mm Allen Wrench (T-A). STEP 5 OPTION A: Insert cables through center of Mount OPTION B: Insert cables through side of Mount...
  • Page 5 STEP 6 Secure Mount Assembly to Ceiling Plate (D) using M6x18mm Bolts (S-A) with M6 Washers (S-B), and tighten with 5mm Allen Wrench (T-B).
  • Page 6 STEP 7 Align Mount Arms (C) with mounting holes in projector, and mount to projector using screws (M-A thru M-D) and Washers (M-E thru M-H) most appropriate for your projector. NOTE: If your projector has 3 mounting holes, simply remove one of the arms, or for mini projectors with a single hole, remove all arms and mount projector directly to Bracket.
  • Page 7 STEP 8 Secure Mount Arms (C) to Assembled Mount using M5 Plastic Washer (S-E), M5 Washer (S-D), M5x12mm Screw (S-C) and 4mm Allen Wrench (T-A). STEP 9 Adjust angle and rotation of projector if desired by loosening screws on Assembled Mount using 4mm Allen Wrench (T-A).
  • Page 8 : 1HR 8M (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
