- Page 1 ECM-3512 3.5" AMD Geode GX2 Micro Module Quick Installation Guide Ed – 18 June 2013 Part No. E2017351203R...
-
Page 2: Table Of Contents
LCD Backlight Brightness Adjustment Connector (VR1)............22 Audio / USB Daughter Board User’s Guide ............23 2.4.1 Jumper and Connector Layout ....................23 2.4.2 Jumper and Connector List ....................23 2.4.3 Setting Jumper and Connector ....................24 2 ECM-3512 Quick Installation Guide... -
Page 3: Getting Started
1.2 Packing List Before you begin installing your single board, please make sure that the following materials have been shipped: 1 x ECM-3512 Onboard AMD Geode GX2 micro module 1 x Quick Installation Guide for ECM-3512 ... -
Page 4: Hardware Configuration
ECM-3512 2. Hardware Configuration 4 ECM-3512 Quick Installation Guide... -
Page 5: Product Overview
Quick Installation Guide 2.1 Product Overview ECM-3512 Quick Installation Guide 5... -
Page 6: Jumper And Connector List
COM2 RS-232/422/485 select 3 x 2 header, pitch 2.0mm 4 x 3 header, pitch 2.0mm PCI-104 voltage select 3 x 1 header, pitch 2.0mm LPWR1 LCD inverter power select 3 x 1 header, pitch 2.0mm 6 ECM-3512 Quick Installation Guide... - Page 7 5 x 2 header, pitch 2.54mm USB2 USB connector 2 & 3 5 x 2 header, pitch 2.54mm VGA1 VGA connector D-sub 9-pin, female LCD brightness adjustment connector 3 x 1 header, pitch 2.0mm 104+ PCI-104 connector ECM-3512 Quick Installation Guide 7...
-
Page 8: Setting Jumpers & Connectors
ECM-3512 2.3 Setting Jumpers & Connectors 2.3.1 TFT/CRT Select (JP1) CRT* * Default 2.3.2 BIOS Write Protect Select (JP2) Protect Write* * Default 8 ECM-3512 Quick Installation Guide... -
Page 9: Clear Cmos (Jp3)
Slave* * Default Note: If the CF is set as master, ECM-3512 will allow only one device to be connected, such as one HDD or one CD-ROM. At this time, the HDD or CD-ROM will be slave device. If the CF is set as slave, you may connect 2 IDE devices on 44-pin IDE port (IDE1);... -
Page 10: Com2 Rs-232/422/485 Select (Jp5, Jp6)
ECM-3512 2.3.5 COM2 RS-232/422/485 Select (JP5, JP6) (JP5) (JP6) RS-232* RS-232* RS-422 RS-422 * Default RS-485 RS-485 2.3.6 PCI-104 Voltage Select (JP7) +5V* +3.3V * Default 10 ECM-3512 Quick Installation Guide... -
Page 11: Lcd Inverter Power Select (Lpwr1)
Quick Installation Guide 2.3.7 LCD Inverter Power Select (LPWR1) +12V * Default 2.3.8 Audio Connector (AUD1) Signal Signal Speaker L Speaker R Mic Bais Mic-In Line-In L Line-In R Line-Out L Line-Out R ECM-3512 Quick Installation Guide 11... -
Page 12: Irda Connector (Cn1)
ECM-3512 2.3.9 IrDA Connector (CN1) Signal IRTX IRRX 2.3.10 CD-ROM Audio Input Connector (CN2) Signal CD_R CD_L 12 ECM-3512 Quick Installation Guide... -
Page 13: Serial Port 2 Connector In Rs-232 Mode (Com2)
Quick Installation Guide 2.3.11 Serial Port 2 Connector in RS-232 Mode (COM2) Signal Signal RI/+5V 2.3.12 Serial Port 2 Connector in RS-422 Mode (COM2) Signal Signal RxD- TxD+ RxD+ TxD- ECM-3512 Quick Installation Guide 13... -
Page 14: Serial Port 2 Connector In Rs-485 Mode (Com2)
Serial Port 2 Connector in RS-485 Mode (COM2) Signal Signal DATA+ DATA- 2.3.14 Digital I/O Connector (JDIO1) Signal Signal SMB_DATA_S SMB_CLK_S DIO17 DIO7 DIO16 DIO6 DIO15 DIO5 DIO14 DIO4 DIO13 DIO3 DIO12 DIO2 DIO11 DIO1 DIO10 DIO0 14 ECM-3512 Quick Installation Guide... -
Page 15: Front Panel Connector (Jfp1)
Front Panel Connector (JFP1) Signal Signal RESET HD_LED SPEAK PWR_BUT 2.3.15.1 Signal Description – Front Panel Connecter (JFP1) PIN No. Description 3, 5 Reset SW 4, 6 System LED 7, 9 Power SW 8, 10 Speaker ECM-3512 Quick Installation Guide 15... -
Page 16: Tft Panel Connector (Lcd1)
ECM-3512 2.3.16 TFT Panel Connector (LCD1) Signal Signal +3.3V +3.3V VCON SHFCLK ENBLK 16 ECM-3512 Quick Installation Guide... - Page 17 Enable backlight signal. This signal is controlled as a part of the panel power sequencing VCON Flat Panel Voltage Bias Enable. This signal is used to control LCD Bias power. 2.3.16.2 Signal Configuration – TFT Panel Display (LCD1) Signal 18-bit TFT 24-bit TFT ECM-3512 Quick Installation Guide 17...
-
Page 18: Lcd Inverter Connector (Linv1)
LCD brightness through the VR signal controlled by VR1. Please see the VR1 section for detailed circuitry information. 2.3.17.1 Signal Description – LCD Inverter Connector (LINV1) Signal Signal Description Vadj = 0.75V ~ 4.25V (Recommended: 4.7KΩ, >1/16W) ENBKL LCD backlight ON/OFF control signal 18 ECM-3512 Quick Installation Guide... -
Page 19: Parallel Port Connector (Lpt1)
Quick Installation Guide 2.3.18 Parallel Port Connector (LPT1) Signal Signal STB# AFD# ERR# INIT# SLIN# ACK# BUSY SLCT ECM-3512 Quick Installation Guide 19... -
Page 20: Lvds Connector (Lvds1)
C interface for panel parameter EEPROM. This EERPOM is mounted on the C_DAT, I C_CLK LVDS receiver. The data in the EEPROM allows the EXT module to automatically set the proper timing parameters for a specific LCD panel. 20 ECM-3512 Quick Installation Guide... -
Page 21: Auxiliary Power Connector (Pwr1)
Auxiliary Power Connector (PWR1) Signal VCCSB PSON Note: The default sets PWR1 to 1~3 opened for AT power supply using. 2.3.21 USB Connector 0, 1, 2 & 3 (USB1, USB2) Signal Signal D1-/D3- D1+/D3+ D0+/D2+ D0-/D2- ECM-3512 Quick Installation Guide 21... -
Page 22: Lcd Backlight Brightness Adjustment Connector (Vr1)
ECM-3512 2.3.22 LCD Backlight Brightness Adjustment Connector (VR1) Signal LINV1 pin 4 Variation Resistor (Recommended: 4.7KΩ, >1/16W) 22 ECM-3512 Quick Installation Guide... -
Page 23: Audio / Usb Daughter Board User's Guide
5 x 2 header, pitch 2.0mm 5 x 2 header, pitch 2.54mm 2.54mm USB 1.1/2.0 connector 2 2.0mm USB 1.1/2.0 connector 5 x 2 header, pitch 2.0mm TV / Audio connector 8 x 2 header, pitch 2.54mm ECM-3512 Quick Installation Guide 23... -
Page 24: Setting Jumper And Connector
PIN PIN Signal Signal PIN PIN Signal Signal PIN PIN Signal Mic In Mic Bais Line out L Line out R SPK L SPK R Line in L Line in R Yout TVGND Cout TVGND COMP 24 ECM-3512 Quick Installation Guide...
