Avalue Technology ECM-QM77 Quick Installation Manual

Intel ivy bridge processors 3.5” micro module with intel qm77 chipset
Hide thumbs Also See for ECM-QM77:

Advertisement

Quick Links

Download this manual See also: User Manual
ECM-QM77
Intel® Ivy Bridge Processors 3.5" Micro Module
with Intel® QM77 Chipset

Quick Installation Guide

th
Ed – 03 September 2013
5
Part No. E2017391204R

Advertisement

loading
Need help?

Need help?

Do you have a question about the ECM-QM77 and is the answer not in the manual?

Questions and answers

Related Manuals for Avalue Technology ECM-QM77

Summary of Contents for Avalue Technology ECM-QM77

  • Page 1: Quick Installation Guide

    ECM-QM77 Intel® Ivy Bridge Processors 3.5” Micro Module with Intel® QM77 Chipset Quick Installation Guide Ed – 03 September 2013 Part No. E2017391204R...

  • Page 2: Getting Started

    Before you begin installing your single board, please make sure that the following materials have been shipped: 1 x 3.5” ECM-QM77 Micro Module  1 x Quick Installation Guide for ECM-QM77  1 x AUX-056 daughter board  1 x DVD-ROM contains the followings: ...
  • Page 3 ECM-QM77 Quick Installation Guide 2. Hardware Configuration ECM-QM77 Quick Installation Guide 3...
  • Page 4 ECM-QM77 Quick Installation Guide 2.1 Product Overview 4 ECM-QM77 Quick Installation Guide...
  • Page 5 ECM-QM77 Quick Installation Guide ECM-QM77 Quick Installation Guide 5...
  • Page 6 Label Function Note BAT1 Battery connector 2 x 1 wafer, pitch 1.25 mm Serial port 1 connector D-sub 9-pin, male COM1 CPU fan connector 4 x 1 wafer, pitch 2.54 mm CPU_FAN1 HDMI connector HDMI1 6 ECM-QM77 Quick Installation Guide...
  • Page 7 Serial ATA connector 1 SATA1 SATA2 Serial ATA connector 2 SYS_FAN1 System fan connector 4 x 1 wafer, pitch 2.54 mm USB1_1 On-board connector for USB3.0 VGA1 VGA connector D-sub 15-pin, female MPCIE1 Mini-PCI connector DDR3 SODIMM connector ECM-QM77 Quick Installation Guide 7...
  • Page 8 ECM-QM77 Quick Installation Guide 2.3 Setting Jumpers & Connectors 2.3.1 Clear CMOS (JBAT1) Protect* Clear CMOS * Default 2.3.2 COM 1 pin 9 signal select (JRI1) Ring* +12V * Default 8 ECM-QM77 Quick Installation Guide...
  • Page 9 ECM-QM77 Quick Installation Guide 2.3.3 AT/ ATX Input power select (JAT1) * Default 2.3.4 5VSB connector in ATX (PWR_SB1) Signal SIO_PSON# +ATX5VSB ECM-QM77 Quick Installation Guide 9...
  • Page 10 ECM-QM77 Quick Installation Guide 2.3.5 Battery connector (BAT1) Signal +3.3V 2.3.6 CPU fan connector (CPU_FAN1) Signal +12V CPUFANIN0 CPUFANOUT0 10 ECM-QM77 Quick Installation Guide...
  • Page 11 System fan connector (SYS_FAN1) Signal +12V SYSFANIN SYSFANOUT 2.3.8 COM 1 RS-422-485 mode (J422/1) Signal PIN PIN Signal 485_422TX- 422RX- 485_422TX+ 422RX+ Note: J422/485 is available after modify the mode of COM1 in BIOS setting ECM-QM77 Quick Installation Guide 11...
  • Page 12 MIC1-JD LINE1-JD FRONT-JD MIC1-L-IN MIC1-R-IN LINE1-L-IN LINE1-R-IN FRONT-L-OUT FRONT-R-OUT 2.3.9.1 Signal Description – Audio connector (JAUDIO1) Signal Signal Description LINE1_JD AUDIO IN (LINE_RIN/LIN)sense pin FRONT_JD AUDIO Out(ROUT/LOUT) sense pin MIC1_JD MIC IN (MIC_RIN/LIN) sense pin 12 ECM-QM77 Quick Installation Guide...
  • Page 13 ECM-QM77 Quick Installation Guide 2.3.10 LCD inverter connector (JBKL1) Signal +12V BKLEN BRIADJ 2.3.11 LCD backlight brightness adjustment (JVR1) Signal BRIGHT Variation Resistor (Recommended: 4.7KΩ, >1/16W) ECM-QM77 Quick Installation Guide 13...
  • Page 14 Low pin count connector (JLPC1) Signal PIN PIN Signal LPC_AD0 +3.3V LPC_AD1 LPC_RST# LPC_AD2 LPC_FRAME# LPC_AD3 CLK_PCI_LPC INT_SERIRQ +V5S +V5A PCH_DRQ#1 2.3.13 Serial port 2 connector (JCOM2) Signal PIN PIN Signal DCD2 RxDD2 TxDD2 DTR2 DSR2 RTS2 CTS2 14 ECM-QM77 Quick Installation Guide...
  • Page 15 ECM-QM77 Quick Installation Guide 2.3.14 General purpose I/O connector (JDIO1) Signal PIN PIN Signal SMB_DATA_9555 10 SMB_CLK_9555 DIO_GP13 DIO_GP23 DIO_GP12 DIO_GP22 DIO_GP11 DIO_GP21 DIO_GP10 DIO_GP20 2.3.15 Miscellaneous setting connector (JFP1) Signal PWBT RST# PWR-LED HDD-LED COPEN# ECM-QM77 Quick Installation Guide 15...
  • Page 16 ECM-QM77 Quick Installation Guide 2.3.16 SPI connector (JSPI1) Signal Signal HOLD# SPI_SI SPI_SO SPI_CLK SPI_CS0# +3.3V 2.3.17 Power connector (PWR1) Signal PIN PIN Signal +12V +12V 16 ECM-QM77 Quick Installation Guide...
  • Page 17 ECM-QM77 Quick Installation Guide 2.3.18 LVDS connector (JLVDS1) Signal PIN PIN Signal +12V +12V LVDS_CLK2_N LVDS_CLK1_N LVDS_CLK2_P LVDS_CLK1_P LVDS_DATA7_N LVDS_DATA6_N LVDS_DATA7_P LVDS_DATA6_P LVDS_DATA5_N LVDS_DATA4_N LVDS_DATA5_P LVDS_DATA4_P LVDS_DATA3_N LVDS_DATA2_N LVDS_DATA3_P LVDS_DATA2_P LVDS_DATA1_N LVDS_DATA0_N LVDS_DATA1_P LVDS_DATA0_P +3.3V +3.3V ECM-QM77 Quick Installation Guide 17...
  • Page 18 2.3.19 On-board box header for USB3.0 (JUSB3/1) Signal PIN PIN Signal USB3_RXN3_L USB3_RXP3_L USB3_RXN4_L USB3_RXP4_L USB3_TXN3_L USB3_TXP3_L USB3_TXN4_L USB3_TXP4_L USB_PN_Z_2 USB_PP_Z_2 USB_PN_Z_3 USB_PP_Z_3 2.3.20 On-board box header for USB2.0 (JUSB1) Signal PIN PIN Signal USB_PN_Z_5 USB_PN_Z_4 USB_PP_Z_5 USB_PP_Z_4 18 ECM-QM77 Quick Installation Guide...
  • Page 19 ECM-QM77 Quick Installation Guide 2.3.21 PS/2 keyboard & mouse connector (JKB/ MS1) Signal PIN PIN Signal KBCK KBDT KBVCC MSCK MSDT 2.3.22 HD power connector (HD_PWR1) Signal ECM-QM77 Quick Installation Guide 19...
  • Page 20 LINEIN1 Line in connector Phone Jack 6 x 2 header, pitch 2.00mm AJAUDIO1 Audio connector 5 x 2 header, pitch 2.00mm AJUSB2 2.00mm USB connector 2.00mm USB connector 10 x 2 header, pitch 2.00mm AJUSB3 20 ECM-QM77 Quick Installation Guide...
  • Page 21 AUSB_PN1 AUSB_PP2 AUSB_PP1 ALINE1-L-IN ALINE1-R-IN AMIC1-L-IN AMIC1-R-IN ALINE1-JD AFRONT1-JD AMIC1-JD 2.00mm USB Connector (AJUSB3) Signal PIN PIN Signal AUSBVCC2 AUSB3_RXN1_L AUSBVCC3 AUSB3_RXP1_L 18 AUSB3_RXN2_L 17 AUSB3_RXP2_L AUSB3_TXN1_L AUSB3_TXP1_L 15 AUSB3_TXN2_L AUSB3_TXP2_L AUSB_PN3 AUSB_PP3 AUSB_PN4 AUSB_PP4 ECM-QM77 Quick Installation Guide 21...
  • Page 22 ECM-QM77 Quick Installation Guide Installing the CPU 2.5.1 Locate the CPU socket on the board. Before installing the CPU, make sure that the socket box is facing towards you and the load lever is on your left. 22 ECM-QM77 Quick Installation Guide...
  • Page 23 Separate CPU cooler and its base first by screw drawer 1. Position the CPU over the socket, making sure that the gold triangle is the same side as CPU Socket triangle CPU Socket triangle Gold triangle ECM-QM77 Quick Installation Guide 23...
  • Page 24 CPU lock clockwise to lock CPU The CPU fits in only one correct orientation. DO NOT force the CPU into the socket to prevent bending the connectors on the socket and damaging the CPU! 24 ECM-QM77 Quick Installation Guide...
