- Page 1 Z O R I F R E E S T A N D I N G L - S H A P E D S C R E E N I N S T A L L A T I O N G U I D E S C R E E N S Z I 0 0 0 2...
- Page 2 I N S T A L L A T I O N G U I D E P A R T S A N D F A S T E N E R S I N C L U D E D Pre Assembled Panel Lower Panel Upper Panel (Acrylic FRX-1046 or...
-
Page 3: Installation
I N S T A L L A T I O N G U I D E P A R T S A N D F A S T E N E R S I N C L U D E D C O N T . - Page 4 I N S T A L L A T I O N G U I D E T O O L S A N D S U P P L I E S R E Q U I R E D Drill Square Head bit ½...
- Page 5 I N S T A L L A T I O N G U I D E A S S E M B L Y : Lay pre-assembled Panel flat on a non- marring surface. F I G U R E 1 Remove Cap Plate and 10-24 x 1 Square Drive Flat Head Screws from the slotted end of the Vertical Support Column.
- Page 6 I N S T A L L A T I O N G U I D E A S S E M B L Y : Lifts the sub assembly and place it in the upside-down position. F I G U R E 4 Install (2) Bottom Plates and the L Cap Plate using (12) 10-24 x 1 Square Drive Flat Head.
- Page 7 I N S T A L L A T I O N G U I D E A S S E M B L Y : Install Panel. Note: The number of panels will depend on screen configuration. F I G U R E 7 NOTE: For Acrylic Installation Place Aluminum U-Channel on the edge of the Lower Laminate Panel and fasten using the...
- Page 8 I N S T A L L A T I O N G U I D E A S S E M B L Y : Install Upper Panel. F I G U R E 1 0 Reinstall the Upper Stretcher and tighten the 5/16-18 X .75 Cap Screw (from Fig 6).
- Page 9 1.800.815.7251 www.enwork.com 12900 Christopher Dr. Lowell, MI 49331 Specifications subject to change without notice. Rev 07.2020...
