Operating the EasyShade

25. Test the operation of your EasyShade by using the
UP and DOWN buttons on the Remote
Transmitter.
25a Press and release the UP
EasyShade will roll up into the EasyShade Housing
and stop on its own. The Up stop limit should stop
the EasyShade automatically, before the Leading
Bar in the Bottom Pleat of the Solar Screen reaches
the Housing.
25b Press and release the DOWN
EasyShade will unroll from the EasyShade Housing
and stop on its own. The Down stop limit should
stop the EasyShade automatically, before the
Leading Bar in the Bottom Pleat of the Solar Screen
reaches the physical limit of the Cable Guide
Bracket. See Appendix A to adjust this stop limit.
26. A Wall Holder has been provided for the Remote
Transmitter. See Figure 2. Position the Wall Mount in
a safe location protected from weather.
CAUTION: Do not leave your Motorized EasyShade
extended during windy conditions, as the
uncontrolled movement of the extended EasyShade
Solar Screen Fabric Panel could cause damage to the
product and surrounding items. Simply retract the
Motorized EasyShade by pressing the UP
on the Remote Transmitter.
CAUTION: Do not permit the hand-held Remote
Transmitter to get wet as this can affect its proper
operation. It is recommended to keep the Remote
Transmitter indoors when the EasyShade is not in
use or if rain is expected.
CAUTION: The installation procedure for the
Motorized EasyShade includes the use of Cable
Guides to stabilize the extended Solar Screen Fabric
Panel during normal use. If your application does
not permit the installation of the necessary Cable
Guides or you do not plan to install them, you must
use additional care to prevent damage to your
product. While we do not recommend installing the
Motorized EasyShade without the supplied Cable
Guides, some customers may determine that their
application does not have a vertical surface to install
the supplied Cable Guides as instructed.
"Congratulations, your installation is complete."
Each Remote Transmitter and each Channel of
each Remote Transmitter (see Figure 20) has its
own unique ID code. Each Motorized EasyShade
is programmed to receive a signal from a unique
button. The
Remote Transmitter. A Remote Transmitter can only
communicate with a Motor if the Motor has been
specifically programmed to accept signals from that
specific Remote Transmitter.
Each Motorized EasyShade is packaged with a Remote
Transmitter programmed by SunSetter to control
button. The
that specific EasyShade. SunSetter always programs
Channel 1 (see Figure 20), the first light from the left,
to control the Motorized EasyShade.
If you own more than one Motorized EasyShade, keep
the Remote Transmitter with the EasyShade for which
it was programmed.
To control multiple EasyShades with one or more
Remote Transmitters or Channels, see Appendix C.
Button
7

Unique Remote Transmitters

Each light represents a separate
Channel with its own unique ID,
which operates as a unique Remote
Transmitter. Channel 1 is the first
light on the left.
Figure 20
Channel Selector Button
