SunSetter EasyShade Instructions Manual

Tools Needed:

Electric Drill
1/8" Drill Bit
Pencil
Open End Wrench
Phillips Screwdriver
Tape Measure
Level

Parts Supplied:

Shade Assembly
Mounting Brackets - (2) for 4' to 9' Models, and
(3) for the 10' to 12' Models
#8 x 1- ½" Round-Head Screws – (4) for 4' to 9'
Models and (6) for 10' to 12' Models
1/8" Allen Wrench – for securing mounting
bracket set screws
Cable Guide (2)
Cable Guide Bracket (2)
Cable Guide Stops (2)
5/64" Allen Wrench – for securing cable guide
stop set screws
#8 x 1- ½" Flat-Head Screws (4)
Remote Transmitter with Wall Mounting Post(1)
WARNING: FAILURE TO FOLLOW THESE
INSTRUCTIONS CAN RESULT IN PERSONAL
INJURY! PLEASE READ THESE INSTRUCTIONS
IN ITS ENTIRETY BEFORE ATTEMPTING TO
COMPLETE THIS PROCEDURE.
NOTE: PRIOR TO INSTALLING YOUR EASYSHADE, PLEASE INSPECT
THE MOUNTING SURFACE TO ENSURE THAT THERE ARE NO
OBSTRUCTIONS ON YOUR WALL SURFACE, SUCH AS LIGHT FIXTURES,
DOOR HANDLES, ETC THAT WOULD INTERFERE WITH OR BLOCK THE
SHADE PANEL AS IT IS EXTENDED.
The SunSetter EasyShade can be installed with the mounting brackets on a wall (vertical surface)
see Figure 1a or on the underside of a structure (horizontal surface) see Figure 1b. For the 4' to 9'
models, each of the brackets should be installed so that it is no more than 10" from the end of the
shade assembly. For the 10' to 12' models, a mounting bracket should be installed at each end of
the shade assembly so that it is no more than 10" from the end of the shade assembly. The third
mounting bracket should be installed at the mid point between the two end brackets.
