SunSetter EASYSHADE Owner's Manual & Installation Instructions page 2

SunSetter Solar Powered Motorized EasyShade
Power Cord
between
Motor and
Solar Panel
not shown
Cable
Guide
Hole
Vinyl
Coated
Guide
Cable
Multi-Channel
Cable
Remote Transmitter
Bracket
Owner's Manual & Installation Instruction
Solar Powered Motorized EasyShade Schematic View
Solar Panel
Factory set to open 36" (3 ft).
Adjustable to open 84" (7 ft) max.
See Appendix A to Adjust Limits.
Note: The Solar Screen Fabric Panel width is 3" less than
the EasyShade width (measured at the Aluminum Housing).
Aluminum Housing
Solar Screen Fabric Panel
Aluminum Leading Bar
(inside Bottom Fabric Pleat)
Vertical space between
the Aluminum Housing
and Cable Brackets must
be clear of obstructions.
Figure 1
ii
31/2" Total
clearance
is needed
for the
Aluminum
Housing.
