OPERATING INSTRUCTIONS
VIDEO2 (Camera Input) is activated when the
Blue cable is made live (adding a 12v+
supply) This input will override the additional
source (VIDEO1) or the navigation map when
activated.
If VIDEO 1 is required you will need to CUT
the ORANGE cable on the harness and add in
an external switch. When the orange cable is
broken the VIDEO 1 source will be activated.
When re-connected the factory Navigation will
NAV-INREN
be restored.
VIDEO INPUT
ALL Renault
With Separate Navigation
