th
3950 NW 120
Ave, Coral Springs, FL 33065 TEL 561-955-9770 FAX 561-955-9760
MY-CUE VIM
Video in Motion for MyLink/CUE
NTV-KIT495
BHM
05/20/14
NTV-DOC181

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NTV-KIT495 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Nav TV NTV-KIT495

  • Page 1 3950 NW 120 Ave, Coral Springs, FL 33065 TEL 561-955-9770 FAX 561-955-9760 MY-CUE VIM Video in Motion for MyLink/CUE NTV-KIT495 05/20/14 NTV-DOC181...
  • Page 2 05/20/14 NTV-DOC181 Overview The MY-CUE VIM enables video in motion, navigation destination input while in motion, and Bluetooth setup while in motion in select 2013+ GM vehicles equipped with either the MyLink or CUE media systems. Note: Video playback is only supported on vehicles that have factory Rear Seat Entertainment installed.
  • Page 3 05/20/14 NTV-DOC181 Dash Disassembly (Yukon) 1. Begin by raising the monitor with the button shown below (ignition is not required). Leave the monitor in the upright position during dash disassembly. 2. Remove the dash panel on the passenger side above the glove box.
  • Page 4 05/20/14 NTV-DOC181 5. Lift the center console armrest and remove the large trim panel containing the cup- holders, 12v plugs and seat heaters/coolers. It is secured with clips only. Disconnect all associated plugs and set this trim piece aside. 6. Remove (2x) 7mm screws that secure the climate control onto the sub dash (one on each lower corner).
  • Page 5 05/20/14 NTV-DOC181 3. From the provided Power Harness, solder pin 9, green wire to the plug side of the cut wire from step 2. 4. From the provided Power Harness, solder pin 18, purple wire to the car side of the cut wire from step 2.
  • Page 6 05/20/14 NTV-DOC181 My-CUE VIM Operation  To toggle Video in Motion, press the Rear Defrost button twice within 1 second. This will enable any video to continue playing while driving. This feature will reset upon every key cycle. Agreement End user agrees to use this product in compliance with all State and Federal laws. NAV-TV Corp. would not be held liable for misuse of its product.
