Nav TV NTV-KIT041 Operation Instructions

Nav TV NTV-KIT041 Operation Instructions

Camera interface for 2006-up mercedes-benz gl, ml, r class suv’s

Advertisement

Camera Interface for
2006-Up Mercedes-Benz GL, ML, R
T-Harness
NTV-HAR069
X164 Module
NTV-ASY107
To Activate Rear View Camera
With the brake depressed and engine
running, engage reverse gear.
Rear View Camera picture will show on
COMAND screen.
To Activate Video Monitoring
Press the steering wheel
(+) and (-) buttons simultaneously to
activate Video.
Pressing any MODE button will return
the screen to it!s normal operation mode.
OR:
Press the steering wheel
(hang) and (-) buttons simultaneously to
deactivate Video.
Agreement: End user agrees to use this product in compliance with all State and Federal laws. NAV-TV Corp. Would not be held liable for misuse of it's product.
WARNING: Check entire surroundings while backing. Do not become distracted by using COMAND.
Class SUV's
V1 Switcher shown here, this
has been replaced with the
USB Cable
NTV-CAB009
Operation Instructions
If you do not agree, please discontinue use immediately and return product to place of purchase.
This product is intended for off-road use and passenger entertainment only.
3950 NW 120th Ave Coral Springs, FL 33432
Tel. 561-955-9770
info@nav-tv.com
X164
Compatible with Alpine made US MCS Comand
Head units. Mercesed P/N ending with 1779, 1789,
3879, 4089, 4079 3689. See 3rd page picture for
NTV-KIT041
example.
European Head units

Kit Contents

VSW-R in 03/15
Fig. 1 - Vehicle in Reverse
Fig. 2 - Video Activation
Fax. 561-955-9760
Not compatible with Models not listed or
VSW-R I/O Harness
NTV-HAR301
VSW-R Board
NTV-ASY187
VSW-R Trigger Harness
NTV-HAR066
X164
BHM 3/18/15
NTV-DOC026
