P P r r o o d d u u c c t t O O v v e e r r v v i i e e w w
Table 1. Chiller status area (continued)
Button/Touch target
Water temperature touch target
Setpoint source touch target
Auto/Stop buttons

Main Display Area/Home Screen

All screens appear within the main display area (shown as Location 2 shown in the figure in
"Screen Overview," p.
H H o o m m e e s s c c r r e e e e n n : : C C h h i i l l l l e e r r s s t t a a t t u u s s i i n n f f o o r r m m a a t t i i o o n n
The home screen (shown in
chiller status information on "touch targets" (the entire white rectangular areas) for each chiller
component. Touching any touch target displays a screen containing more chiller status
information related to each component (refer to
Each touch target that appears on the home screen is described in the following table, including
those for Simplex chillers, and those for Duplex™ chillers.
In the lower right corner of the home screen, you can view the date and time as well as additional
chiller information. For details, see the last three rows of the following table.
10
Description
The water temperature touch target shows one of the following, depending on whether the chiller is in
heating or cooling mode (also referred to as the Active Control Type):
• If the Active Control Type is chilled water, the Evaporator Leaving Water Temperature appears and
the touch target links to the evaporator component screen.
• If the Active Control Type is hot water, the Condenser Leaving Water Temperature appears and the
touch target links to the condenser component screen.
• If the Ice Building mode is Active, the Evaporator Entering Water Temperature appears and the
touch target links to the evaporator component screen.
Note: For more information on the evaporator and condenser component screens, refer to
Screens," p. 14.
The current setpoint source is highlighted in green on the setpoint source touch target. Touch this
target to view the Setpoint Source screen, where you can change the setpoint source.
Note: For more information, refer to
Auto and Stop are toggle buttons: One appears raised when the other is appears depressed.
• Touch Auto to activate the chiller startup process.
• Touch Stop to active the chiller shutdown process.
Note: For more information, refer to
8).
"Screen Overview," p.
"Changing the Setpoint Source," p. 44
"Stopping/Restarting Chiller Operation," p.
8) provides the most frequently needed
"Component Screens," p.
"Component
.
18.
14).
CTV-SVU01G-EN
