Terra Dc Wallbox Version Description; Signs - ABB Terra DC wallbox Installation Manual

On the inside of the system there are some differences. The Terra DC Wallbox EU version
has a AC input board provided with contact blocks for main connection that are de-
signed to be connected with a three phase + neutral power grid. On the other hand, the
NAM version has a different AC input board designed to be connected with a phase to
phase power grid.
1.4

Terra DC Wallbox version description

The Terra DC Wallbox is available in different versions depending on the available out-
lets.
The versions are:
Version
Terra DC Wallbox C EU
Terra DC Wallbox J EU
Terra DC Wallbox CJ EU
Terra DC Wallbox C UL
Terra DC Wallbox J UL
Terra DC Wallbox CJ UL
C CCS (Combo) standard
J CHAdeMO standard
1.5

Signs

The following signs are used on the equipment and in this manual:
2 2 -O CT -19
CCS2 CCS 1
X
X
DANGER
Hazardous voltage
Identifies a hazard that could result in severe injury or death
through electrocution.
WARNING
Various
Identifies a hazard that could result in severe injury or death.
WARNING
Rotating parts
Identifies a hazard that could result in injury due to the
presence of rotating or moving parts.
T ERRA D C WA LLBO X
CHAdeMO EU
X
X
X
X
CHAdeMO UL
X
X
7/ 40
