8 Technical Data

8.1

Electrical data

Input
Supply voltage
Input voltage range
Maximum rated input current & power
Power factor
Efficiency
DC output (C)
Maximum output power
Output voltage range
Maximum output current
DC output (J)
Maximum output power
Output voltage range
Maximum output current
General
DC connection standard
DC cable length
DC plug type
RFID data
2 2 -O CT -19
3 phase, 400 V AC: PE, N, L1, L2, L3 (EU)
1 phase / 2 phases, 208 V AC/240 V AC: PE,
L1, L2 (NAM)
3 phase, 277Y/480Δ V AC: PE, N, L1, L2, L3
(NAM 3-ph)
400 V AC +10%, -15%(50 Hz)
208V AC/240 V AC +10%, -15% (60 Hz)
480 V AC +10%, -15% (60Hz)
3x40A (EU), 100A (NAM),24kVA
> 96%
95% at nominal output power
22,5 kW (peak 24kW)
150-920 V DC (CCS 2)
60 A DC +/- 5% (CCS 2)
22,5 kW (peak 24kW)
150-500 V DC (CHAdeMO)
60 A DC (CHAdeMO)
EN61851-23 / DIN 70121 CCS 2 CHAdeMO 1.0
3,5 or 7 meters +/- 10%
CCS 2 / JEVS G105 CHAdeMO
