Programming with mikroBootloader
You can program the microcontroller with a
bootloader which is preprogrammed by default.
To transfer .hex file from a PC to MCU you need
bootloader software (mikroBootloader USB HID)
which can be downloaded from:
www.mikroe.com/downloads/get/2144/
mikrobootloader_usb_hid_STM32F415RG.zip
After the mikroBootloader software is downloaded,
unzip it to desired location and start it.
step 1 – Connecting STM32 M4 clicker
01
Figure 4-2: USB HID mikroBootloader window
To start, connect the USB cable, or if already connected press
01
the Reset button on your STM32 M4 clicker. Click the Connect
button within 5s to enter the bootloader mode, otherwise
existing microcontroller program will execute.
Page 10
