MODEL G18F DRAIN SYSTEM (Self-Contained Units With Optional Evaporator Pan Only)

Self-contained units have drain systems that allow thorough defrost and interior cleaning.
> Default drain valve setup (from manufacturer) is with internal evaporator pan being utilized.
Note : Model and options
chosen may affect location of
valves, drains, controller,
electrical box location, or
number of pans shown in
these illustrations.
Model G18F
Evaporator
Pan Setup
Evaporator
Shown At
Right
Evap.
Pan Tray
11
External
Drain
Main Intake
Internal
Pan
Drain
Valve
External
Drain Spout
Main
Intake
Evaporator
Drain Hose
