NetVanta 3148/4148 Series Hardware Installation Guide
1.

INTRODUCTION

This hardware installation guide describes the NetVanta 3148, NetVanta 3148 Power over
Ethernet (PoE), NetVanta 4148, and NetVanta 4148 PoE Series units' physical characteristics,
lists their features and specifications, introduces basic functionality, and provides installation
instructions in the following sections:
•
Physical Description on page 9
•
Features and Specifications on page 13
•
Unit Installation on page 16
In this document, the term NetVanta 3148/4148 Series means all of the units
collectively. If a statement only applies to one particular, switch, the text refers to
that switch individually.
For additional information on shipping contents, mounting options, SFP module installation, and
supplying power to the unit, refer to the following sections:
•
Shipping Contents on page 10
•
Mounting Options on page 17
•
Supplying Power to the Unit on page 20
•
Installing SFP Modules in the Unit on page 21
For information on NetVanta 3148/4148 Series configuration for a specific application, refer to the
configuration guides provided on the
line interface (CLI), refer to the
are also available online at http://supportcommunity.adtran.com.
2.

PHYSICAL DESCRIPTION

The NetVanta 3148/4148 Series unit is a fixed-port Ethernet router designed for high-
performance Ethernet solutions, focusing on higher bandwidth applications (up to 1Gbps) for
Layer 3 Virtual Private Network (VPN) services and alternatives to T1 solutions. It provides a
cost-effective option for branch office termination of carrier services over MPLS or Ethernet
copper/fiber connections by offering 8 switchable Gigabit Ethernet Media ports and 4 routed
Gigabit Ethernet system ports.
The NetVanta 3148/4148 Series unit provides two routed 10/100/1000Base-T combination
copper/SFP Ethernet ports and two routed 10/100/1000Base-T copper Ethernet ports, as well as
eight 10/100/1000Base-T access switch ports that provide Cisco legacy, 802.3af, and 802.3at
PoE options. IPsec VPN support is included with the ADTRAN Operating System (AOS)
Enhanced Feature Pack.
SFP Module Slots
The NetVanta 3148/4148 Series has two small form-factor pluggable (SFP) slots that accept a
number of industry standard SFP modules. The SFP modules provide Gigabit Ethernet fiber
connectivity for high-speed uplinks. For a list of supported SFP modules, visit the ADTRAN
website at http://www.adtran.com.
617004148F1-34B
ADTRAN Support
AOS Command Reference
Copyright © 2020 ADTRAN, Inc.
Community. For details on the command
Guide. All other related documents
Introduction
9
