N
V
ET
ANTA
P/N 1700601G2, 1700611G2, 1700612G2
G
S
ETTING
TARTED
Two configuration methods are available for your NetVanta router:
•
Web-based graphical user interface (GUI)
•
AOS command line interface (CLI)
The GUI lets you configure the main unit settings, and provides online guidance, explanations for
each setting, and configuration wizards to help you get started. However, using the AOS CLI may
be necessary for more advanced configurations.
A
GUI
CCESS THE
You may access the GUI from any Web browser on your network by following these steps:
1.
Connect the router to your PC, using an Ethernet cable connected to one of the four ports on
the back of the unit (Ethernet 1, 2, 3, or 4).
2.
Connect the router to your service provider connection, using the provided cable connected
to the ETH 0/1 port on the router (for the NetVanta 3120). If you have a NetVanta 3130, plug
your ADSL line into the port labeled ADSL on the back of the unit.
3.
After the router is connected to the PC, make sure the router is powered. Remember to plug
the unit in and to turn the unit on using the toggle switch at the rear of the unit.
4.
During bootup, your PC will obtain an IP address from the NetVanta 3100 Series unit's
DHCP server. By default, both the DHCP and HTTP servers are enabled.
5.
Enter the unit's IP address in your browser address line. The default IP address is
10.10.10.1.
6.
You will then be prompted for the username and password (the default settings are admin
and password).
7.
The initial GUI screen appears. You can access initial setup information by selecting Setup
Wizard from the menu on the left.
For security purposes, you should set up an admin password
immediately. Use the Passwords menu of the GUI to change this
password.
By default, the NetVanta 3130 comes with an ADSL and an
asynchronous transfer mode (ATM) port already configured and
enabled. The service provider should provide a PVC (VPI/VCI) number,
which will be used to configure the ATM PVC.
Quick Start Guide, 61700601G2-13D, November 2009
3100 S
ERIES
R
OUTER
1
Advertisement
Related Manuals for ADTRAN 1700601G2
Summary of Contents for ADTRAN 1700601G2
- Page 1 3100 S ANTA ERIES OUTER P/N 1700601G2, 1700611G2, 1700612G2 ETTING TARTED Two configuration methods are available for your NetVanta router: • Web-based graphical user interface (GUI) • AOS command line interface (CLI) The GUI lets you configure the main unit settings, and provides online guidance, explanations for each setting, and configuration wizards to help you get started.
- Page 2 • If the factory default switch is pressed and held for approximately 70 seconds, a default configuration will overwrite your existing configuration and reboot the unit. When the default Copyright © 2009 ADTRAN, Inc. All Rights Reserved.
- Page 3 configuration is being applied the STAT, WAN, INET, and VPN LEDs will cycle. At this point the default switch can be released. To factory default the unit, the default switch must be pressed WHILE the STAT light on the front of the unit is solid green. Do not press the default switch BEFORE the STAT light is solid green, as this will cause boot to be missed.
- Page 4 AOS (article 1925) AOS (article 1926) Additional detailed documentation for configuring your ADTRAN unit is provided on the AOS Documentation CD included in your shipment. For more detail on hardware setup, refer to the appropriate NIM quick start guides and the appropriate hardware installation guide. For more...
