ADTRAN NETVANTA 3100 SERIES Quick Start Manual

N V
ET ANTA
D B
WITH IAL
P/N 1700600L2, 1700610L2
G S
ETTING TARTED
Two configuration methods are available for your NetVanta router:
• Web-based graphical user interface (GUI)
• AOS command line interface (CLI)
The GUI lets you configure the main unit settings, and provides online guidance, explanations for
each setting, and configuration wizards to help you get started. However, using the AOS CLI may
be necessary for more advanced configurations.
A GUI
CCESS THE
You may access the GUI from any Web browser on your network by following these steps:
1. Connect the router to your PC, using an Ethernet cable connected to one of the four ports on
the back of the unit (Ethernet 1, 2, 3, or 4).
2. Connect the router to your service provider connection, using the provided cable connected
to the ETH 0/1 port on the router (for the NetVanta 3120). If you have a NetVanta 3130, plug
your ADSL line into the port labeled ADSL on the back of the unit.
3. After the router is connected to the PC, make sure the router is powered. Remember to plug
the unit in and to turn the unit on using the toggle switch at the rear of the unit.
4. During bootup, your PC will obtain an IP address from the NetVanta 3100 Series unit's
DHCP server. By default, both the DHCP and HTTP servers are enabled.
5. Enter the unit's IP address in your browser address line. The default IP address is
10.10.10.1.
6. You will then be prompted for the user name and password (the default settings are admin
and password).
7. The initial GUI screen appears. You can access initial setup information by selecting Setup
Wizard from the menu on the left.
For security purposes, you should set up an admin password
immediately. Use the Passwords menu of the GUI to change this
password.
By default, the NetVanta 3130 comes with an ADSL and an
asynchronous transfer mode (ATM) port already configured and
enabled. The service provider should provide a PVC (VPI/VCI) number,
which will be used to configure the ATM PVC.
Quick Start Guide, 61700600L2-13D, November 2009
3100 S
ERIES
U
ACKUP NIT
R
OUTER
1
