Sunny Health & Fitness SF-RW5730 User Manual

Air magnetic rower with aluminum slide rail
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
AIR MAGNETIC ROWER WITH
ALUMINUM SLIDE RAIL
SF-RW5730
USER MANUAL
IMPORTANT! Please retain owner's manual for maintenance and adjustment instructions. Your
satisfaction is very important to us, PLEASE DO NOT RETURN UNTIL YOU HAVE CONTACTED
US:
support@sunnyhealthfitness.com
or 1- 877 - 90SUNNY (877-907-8669).

Advertisement

Table of Contents
loading

Related Manuals for Sunny Health & Fitness SF-RW5730

Summary of Contents for Sunny Health & Fitness SF-RW5730

  • Page 1 AIR MAGNETIC ROWER WITH ALUMINUM SLIDE RAIL SF-RW5730 USER MANUAL IMPORTANT! Please retain owner’s manual for maintenance and adjustment instructions. Your satisfaction is very important to us, PLEASE DO NOT RETURN UNTIL YOU HAVE CONTACTED support@sunnyhealthfitness.com or 1- 877 - 90SUNNY (877-907-8669).

  • Page 2: Important Safety Information

    IMPORTANT SAFETY INFORMATION We thank you for choosing our product. To ensure your safety and health, please use this equipment correctly. It is important to read this entire manual before assembling and using the equipment. Safe and effective use can only be achieved if the equipment is assembled, maintained, and used properly. It is your responsibility to ensure that all users of the equipment are informed of all warnings and precautions.

  • Page 3: Exploded Diagram

    EXPLODED DIAGRAM...

  • Page 4: Parts List

    PARTS LIST Description Spec. Qty. Description Spec. Qty. Coil Spring Upper Cover Assembly Fan Assembly Handlebar Computer Front Stabilizer Magnetic Board Belt Assembly Tension Control Idler Wheel Knob Left End Cap Pedal Strap Right End Cap Foam Grip Aluminum Rail Hex Bolt M6*12 Seat...

  • Page 5: Hardware Package

    HARDWARE PACKAGE #42 M8*55 2PCS #32 4PCS #47 M6*20 4PCS #48 M8*20 10PCS #55 Φ8.4*Φ19.0*T1.6 12PCS #46 M8 2PCS #60 S5 2PCS #61 S13-S17 1PC Ordering Replacement Parts (U.S. and Canadian Customers only) Please provide the following information in order for us to accurately identify the part(s) needed: ✓...
  • Page 6 ASSEMBLY INSTRUCTIONS We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877- 907-8669). STEP 1: Attach Front Stabilizer (No. 36) to Main Frame (No. 11) with 2 Carriage Bolts (No. 42), 2 Flat Washers (No.
  • Page 7 We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877- 907-8669). STEP 3: Attach Seat (No. 9) onto Aluminum Rail (No. 8) as the arrow indicates on the left picture. Attach Rear Support (No.

  • Page 8: Adjustment Guide

    ADJUSTMENT GUIDE CAUTION! Keep hands and fingers clear of the sliding rail while in use. Moving parts, such as the seat, can cause injury. PEDAL STRAP ADJUSTMENT The pedal strap is adjustable and can be personalized to fit the user’s foot size. MOVING THE ROWER To move the rower, lift the rear stabilizer until the transportation wheels on the front stabilizer touch...
  • Page 9 ❖ FOLDING THE ROWER When not in use, you can save Figure A space folding Aluminum Rail (No. 8). 1. Pull out the Pull Pin (No. 13). Fold the Aluminum Rail (No. 8) to a vertical angle (Figure A). SAFETY NOTE: The seat will glide down when folding the Aluminum Rail (No.

  • Page 10: Replace The Battery

    ❖ REPLACE THE BATTERY One AAA battery is included in the Computer (No. 3). To replace the battery, remove the computer from Main Frame (No. 11), disconnect the Trunk Wire (No. 58), and the link wire of the computer. Replace the battery. Do not mix battery types and do not mix old and new batteries.

  • Page 11: Exercise Computer

    EXERCISE COMPUTER SPECIFICATIONS: CNT(COUNT) ---------------------------------------------0~9999 TIME(TIME)-------------------------------------------------0:00~99:59MIN RPM( STRIDES/MINUTE) ----------------------------0~9999 CAL(CALORIES)------------------------------------------ 0~9999 (0.0~999.9)KCAL DIST(DISTANCE) -----------------------------------0.1-999.9 ML KEY FUNCTIONS MODE: Press to select functions, time, calories, rpm, distance, scan, and count. Hold the button for 2 seconds for a total reset. OPERATION PROCEDURES AUTO ON/OFF: If the machine is put into motion or the mode button is pressed, the computer will become active.
