CUBEX
Measuring
Stepper motor
chip voltages
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cubify Cubex and is the answer not in the manual?

Questions and answers

Related Manuals for 3D Systems Cubify Cubex

Summary of Contents for 3D Systems Cubify Cubex

  • Page 1 CUBEX Measuring Stepper motor chip voltages...

  • Page 2: Table Of Contents

    Contents What you will need ..................... 3 Removing the Jet Wipe ....................4 Removing the Case and floor panel................4 Voltage Measurement Locations ................6 Reading the Voltages ....................7 Re attaching the floor panel and case................ 8...

  • Page 3: What You Will Need

    What you will need Multimeter 3mm hex driver Small Screwdriver...

  • Page 4: Removing The Jet Wipe

    Before beginning this process please ensure that all cartridges have been removed from the machine. Removing the Jet Wipe Run the bed to the bottom of the machine using manual move. Lift Jet wipe out of the machine Removing the Case and floor panel. Using the 3mm hex driver remove the 8 case bolts (4 either side of the machine).
  • Page 5 Lift the case up off the CubeX. Using the 3mm hex driver undo the 5 bolts holding the floor panel to the machine. Lift the front of the floor panel and cable tie it to the bed arms. This will allow you access to the Main Board PCB.

  • Page 6: Voltage Measurement Locations

    Voltage Measurement Locations Depending which stepper motor chip voltage you want to read, you will need to position your multimeter in different positions of the board. You will need to place a small screwdriver with one end of the multimeter clipped onto it on the small screw head labelled TP –...

  • Page 7: Reading The Voltages

    TP E1 TP E3 TP E2 Reading the Voltages Plug the CubeX into mains power Set the multimeter to read DC voltage. Place the Red (positive) lead onto the desired TP screwhead.

  • Page 8: Re Attaching The Floor Panel And Case

    Hold the other end of the multimeter against the ground point. The multimeter screen will give you your voltage reading. TP X should read 1.3VDC TP Y should read 1.6VDC TP Z should read 1.3VDC TP E1, E2 and E3 should read 1.1VDC If your voltage is not correct use the small screwdriver to turn the screwhead in very small increments measuring the voltage between each turn until it is correct.
  • Page 9 Using the 3mm hex driver re attach the 5 bolts that hold the floor panel. Slide the case onto the CubeX and plug in the CubeX screen.
  • Page 10 Using the 3mm Driver re attach the 8 case bolts. You may now power up your CubeX.
