CY3280-MBR2 C
1
1. Open the back cover and insert the
batteries in the battery holder.
2. Assemble the top and bottom sections
of the kit using the screw driver.
3. Move the Power Select switch to the
"BAT" position.
3
1. Touch any button; the respective LED
glows showing one of the LED
effects.
2. For more details about the kit and its
features, see the
CY3280-MBR2 kit
guide.
®
S
EXPRESS™
AP
ENSE
QUICK START GUIDE
S
S
™ AUTO-TUNING KIT
WITH
MART
ENSE
2
1. Touch the Power (
ON/OFF.
2. Turn ON the kit and ensure that the
Power LED, LED1, and LED2 glows.
4
1. Touch more than one button
simultaneously; the touched buttons
glow displaying LED effects.
) button to turn
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Cypress CAPSENSE EXPRESS WITH SMARTSENSE CY3280-MBR2
Summary of Contents for Cypress CAPSENSE EXPRESS WITH SMARTSENSE CY3280-MBR2
- Page 1 ® CY3280-MBR2 C EXPRESS™ ™ AUTO-TUNING KIT ENSE WITH MART ENSE QUICK START GUIDE 1. Open the back cover and insert the 1. Touch the Power ( ) button to turn batteries in the battery holder. ON/OFF. 2. Assemble the top and bottom sections 2.
- Page 2 Insert the kit CD/DVD and install the kit software. View the kit guide for detailed instructions. For the latest information about this kit, visit http://www.cypress.com/go/CY3280-MBR2 © 2011-2013 Cypress Semiconductor Corporation. All rights reserved. All trademarks or registered trademarks referenced herein are the properties of their respective owners. Doc. #: 001-71858 Rev. *D...
