- Page 1 CY3280-BMM Universal CapSense™ Matrix Button Module Kit Quick Start Doc. # 001-51788 Rev. *A Cypress Semiconductor 198 Champion Court San Jose, CA 95134-1709 Phone (USA): 800.858.1810 Phone (Intnl): 408.943.2600 http://www.cypress.com [+] Feedback...
- Page 2 ■ CY3280-BMM Quick Start ■ 1.5 mm Acrylic Overlay with adhesive Universal CapSense Module boards are available for purchase separately, or as part of combination kits. Do visit www.cypress.com/shop for more information. Prerequisites: ■ Universal CapSense Controller Board ■ PSoC MiniProg ■...
- Page 3 ISSP connector (J3) using a PSoC MiniProg and a USB cable. ■ Open PSoC Programmer by going to Windows Start > All Programs > Cypress > PSoC Programming 3.05 > PSoC Programmer. ■ Select MiniProg 1 from Port Selection view in the Programmer window.
- Page 4 ©2009 Cypress Semiconductor Corporation. CapSense™ and Programmable System-on-Chip™ are ® trademarks, and PSoC is a registered trademark of Cypress Semiconductor Corp. All other trademarks or registered trademarks referenced herein are property of the respective corporations. If you have questions, call Cypress Customer Support +1 (800) 541-4736 Ext.
