- Page 1 16 Port USB 3.0 Metal Hub w/Surge Protection – Rack/DIN-RAIL Mountable Product Manual Coolgear, Inc. Version 1.1 September 2017 Model Number: USB3-16U1 www.coolgear.com...
- Page 2 Coolgear New Manual Format About this document This product manual outlines installation and features of the USB3-16U1, 16 Port USB 3.0 Metal Hub w/Surge Protection – Rack/DIN-RAIL Mountable. Scope The scope of this manual is to give the user of the product an understanding of its use with detailed diagrams and verbiage.
-
Page 3: Table Of Contents
USB3-16U1 – Product Manual Table of Contents 1. Introduction ......................4 Features ........................4 Connector Layout ....................5 Hardware Installation ..................... 6 Checking the Hub Installation ................. 7 Environmental Specifications ................. 7 2. Notes, Tips, Warnings, and Safety ................. 8 3. -
Page 4: Introduction
USB3-16U1 – Product Manual 1. Introduction The USB3-16U1 USB 3.0 16 Port USB 3.0 DIN-Rail mounted hub provides an ideal solution for expanding your application by 16 USB 3.0 ports. Also supports Sync and Charging Simultaneously. WEIGHT 2.5 lbs DIMENSIONS 12.15”(L) x5.12”(W) x1.74”(H) (30.85 x 13.02 x 4.42 cm) -
Page 5: Connector Layout
USB3-16U1 – Product Manual 1.2 Connector Layout Figure 1 USB 3.0 Upstream Ports USB 3.0 Downstream Ports Self Power Input There are 2 Type-B There are 16 Type-A This 2-pin (one pin for upstream connectors that connectors for USB 3.0,... -
Page 6: Hardware Installation
USB3-16U1 – Product Manual 1.3 Hardware Installation 1. Use static electricity discharge precautions. Remove possible static discharge potential from any objects that the hub may come in contact with before installation. This can be accomplished by touching a bare metal chassis rail after you have turned off the power. -
Page 7: Checking The Hub Installation
USB3-16U1 – Product Manual 1.4 Checking the Hub Installation To check the USB hub installation in Windows device manager, please follow the following steps: 1. Click Start 2. Click Control Panel 3. Click System 4. Click Device Manager button 5. Double Click Universal Serial Bus Controller 6. -
Page 8: Notes, Tips, Warnings, And Safety
USB3-16U1 – Product Manual 2. Notes, Tips, Warnings, and Safety Note This USB 3.0 16-Port Hub is a Self-Power Hub Only Please make sure the polarity of the input power should be correctly matched with the terminal block pins to function properly. -
Page 9: Supporting References
© 2017 Coolgear, Inc. All Rights Reserved. All products and accompanying digital documentation including images are the property and / or trademarks of Coolgear Inc. Coolgear Inc. are continuously improving upon its products. Product specifications are subject to change without notice.
