- Page 1 TIMBER BRIDGE Installation Instructions REF: SG007 - TIMBER BRIDGE pg 1 of 6...
-
Page 2: Parts Required
PARTS required SIDE ASSEMBLY - QTY 2 BASE - QTY 1 (120mm brass screws) TOOLS required pg 2 of 6 REF: SG007 - TIMBER BRIDGE... -
Page 3: Foundation Details
Foundation Details SOIL TIMBER SUPPORT POST CONCRETE pg 3 of 6 REF: SG007 - TIMBER BRIDGE... - Page 4 In addition to POST HOLES - 3 x trenches will be required (as shown above) 77mm DEEP to accomodate the 3 x BASE supports which need to be installed into the ground pg 4 of 6 REF: SG007 - TIMBER BRIDGE...
- Page 5 Assembly Instructions Attach the 2 x sides to the BASE Using 120mm brass screws to attach the sides to the base POSITIONED IN THE CENTRE = SCREW HOLE LOCATIONS pg 5 of 6 REF: SG007 - TIMBER BRIDGE...
- Page 6 Assembly Instructions Screw the sides to the base from the INSIDE As shown below Concrete the ASSEMBLED BRIDGE into the ground Following the foundation details pg 6 of 6 REF: SG007 - TIMBER BRIDGE...
