Horizontal - ADA Handle on the Right
Example shows Confi guration 2a. See other confi guration options under the ADA handle rotation section.
Keypad
Cam Options
Offset Cam
Cylinder Length Options
16mm
3
Flat Washer
Phillips Screw M5
RFID
Shown in the locked position.
Flat Cam
22mm
Cam Guide
ADA Handle
Star Washer
Cam-Stop Options
Lifter Cam
30mm (Standard)
Cam-Stop
Flat Cam
(See below for other cam options)
90° Cam-Stop
180° Cam-Stop
38mm
mini
