Sola locks with a touch RFID interface are operated by an RFID credential or by an ADA compliant User Key. Manager Keys provide
management access and external power. Programming is accomplished via a Programming Key unique to the lock system.
Lock Orientation - Views
Key Slot
Handle
Vertical
User Credentials
User Key
Keys
Operates the lock
Overrides user access
Allows access for management inspection
Provides external power
Assigns user credential
Sets lock functionality
1
Up to 25 Manager Keys may be programmed to a lock.
Product Guide
Reader
Key Button
LED Usage Indicator
RFID Card
User Key
●
2
1 Programming Key allowed per lock group.
Touch RFID
Key Managed
SOLA can be installed vertically or horizontally for left or right handed confi guration.
Horizontal with Handle on the Left
Horizontal with Handle on the Right
RFID Adhesive
Label
Manager Key
●
●
●
●
●
Shared Use Functionality
RFID Wristband
RFID Keyfob
1
Programming Key
●
●
●
●
●
2
1
Advertisement
Table of Contents
Related Manuals for Digilock NEXT Sola3 Touch RFID
Summary of Contents for Digilock NEXT Sola3 Touch RFID
- Page 1 Product Guide Touch RFID Key Managed Shared Use Functionality Sola locks with a touch RFID interface are operated by an RFID credential or by an ADA compliant User Key. Manager Keys provide management access and external power. Programming is accomplished via a Programming Key unique to the lock system. Lock Orientation - Views SOLA can be installed vertically or horizontally for left or right handed confi...
-
Page 2: Key Insertion
Product Guide Touch RFID Key Managed Shared Use Functionality Key Insertion Horizontal - Handle on Left Vertical Horizontal - Handle on Right Handle Positions 90º 90º Counter-Clockwise 90º Clockwise Locked to unlock Locked to unlock 180º 180º Counter-Clockwise 180º Clockwise Locked to unlock Locked... -
Page 3: Programming Instructions
Product Guide Touch RFID Key Managed Shared Use Functionality Setup Locks are shipped with factory default settings (only operates by pressing `). Each lock must be set up to operate with a Programming Key and Manager Keys. Insert the Programming Key. While the LED is fl... - Page 4 The locks must be reprogrammed to prevent the lost/stolen keys from operating a lock. To replace the Programming Key: Note the order or serial number (found on the lock’s rear). Contact Digilock Support to purchase a replacement Programming Key. To replace the Manager Keys: Collect all remaining and replacement Manager Keys.
- Page 5 Product Guide Touch RFID Key Managed Shared Use Functionality Operating Instructions - In Shared Use Functionality In shared use functionality, the user presents an RFID credential or inserts any User Key to lock and the same User RFID Credential or User Key to unlock.
-
Page 6: Battery Replacement
Does not Operate with the Programming Key The lock does not recognize the Programming Key. If the Programming Key has been replaced, operate with the Replacement Programming Key. Contact Digilock support for additional assistance. No Audible Feedback when ` is Pressed The batteries may need to be replaced.
