Vertical - ADA Handle on the Bottom
Example shows Confi guration 1a. See other confi guration options under the ADA handle rotation section.
Keypad
RFID
Shown in the locked position.
Cam Options
Offset Cam
Cylinder Length Options
16mm
11
Flat Washer
Phillips Screw M5
Flat Cam
Lifter Cam
22mm
Cam Guide
ADA Handle
Star Washer
Cam-Stop Options
90° Cam-Stop
30mm (Standard)
mini
Cam-Stop
Flat Cam
(See below for other cam options)
180° Cam-Stop
38mm
