Versa locks with a keypad interface are operated by a 4-7 digit User Code or by an ADA compliant User Key. Manager Keys provide
management access and external power. Programming is accomplished via a Programming Key unique to the lock system. For Advanced
Models of Versa, an optional mobile application tool is available to simplify lock system management and provide audit trail.
Lock Orientation
Alpha Numeric
Keypad
C Button
Key Button
Key Slot
LED Usage Indicator
Shared Use
Knob
Assigned Use
ADA Handle
Vertical with Knob on Bottom
Keys
Operates the lock
Overrides user access
Allows management inspection
Provides external power
Programs Manager Keys to the lock
Assigns user credentials
3
(in assigned use functionality)
Sets lock functionality
1
Up to 6 Manager Keys may be programmed to each lock.
2
1 Programming Key allowed per lock system.
3
Up to 20 user credentials may be assigned to each lock.
Key Insertion
Numeris logo must face towards the keypad.
Product Guide
Vertical with Knob on Top
User Key
•
Keypad
Shared & Assigned Use Functionality
Horizontal with Knob on Left
Horizontal with Knob on Right
Manager Key
1
Programming Key
•
•
•
•
•
2
•
•
•
•
•
•
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Digilock Numeris Versa Mini
Summary of Contents for Digilock Numeris Versa Mini
- Page 1 Product Guide Keypad Shared & Assigned Use Functionality Versa locks with a keypad interface are operated by a 4-7 digit User Code or by an ADA compliant User Key. Manager Keys provide management access and external power. Programming is accomplished via a Programming Key unique to the lock system. For Advanced Models of Versa, an optional mobile application tool is available to simplify lock system management and provide audit trail.
- Page 2 Product Guide Keypad Shared & Assigned Use Functionality Setup Locks are shipped with factory default settings (only operates by pressing = `). Each lock must be set up to operate with a Programming Key and Manager Keys. Insert the Programming Key. While the LED is fl...
- Page 3 The locks must be reprogrammed to prevent the lost/stolen keys from operating a lock. To replace the Programming Key: Contact Digilock Support to purchase a replacement Programming Key. Note the order or serial number (found on the lock’s rear). To replace the Manager Keys: Collect all remaining and replacement Manager Keys.
- Page 4 Product Guide Keypad Shared & Assigned Use Functionality Programming Instructions Set Lock Functionality Each lock can be set for either shared or assigned use functionality. Press = to check functionality. If in shared use, LED is red. If in assigned use, LED is green. To set for assigned use: Insert the Programming Key.
- Page 5 Product Guide Keypad Shared & Assigned Use Functionality Programming Instructions - in Assigned Use Functionality Assign User Credentials (for assigned use functionality only) Make sure that the lock is set for assigned use functionality (a green LED will fl ash when = is pressed). Up to 20 user credentials (User Codes and/or User Keys) may be assigned to each lock.
- Page 6 Product Guide Keypad Shared & Assigned Use Functionality Programming Instructions - In Assigned Use Functionality Remove User Credentials (for assigned use functionality only) Make sure the lock is in assigned use functionality (a green LED will fl ash when = is pressed). The locks must be reprogrammed to remove user credentials from operating a lock.
- Page 7 Product Guide Keypad Shared & Assigned Use Functionality Programming Instructions - In Assigned Use Functionality Replace an Assigned User Credential Replace an Assigned User Code with a New User Key: Press then insert a valid Manager Key. While the LED is on, While the LED is on, insert a new User Key.
- Page 8 Product Guide Keypad Shared & Assigned Use Functionality Operating Instructions - In Shared Use Functionality In shared use functionality, the user enters any 4-7 digit User Code or inserts any User Key to lock and the same User Code or User Key to unlock.
- Page 9 Product Guide Keypad Shared & Assigned Use Functionality Operating Instructions - In Assigned Use Functionality In assigned use functionality, users operate the lock with their assigned user credential (either a User Code or a User Key). Operate with the User Code = [the assigned 4-7 digit code] ` To unlock: Press then turn the knob to the...
- Page 10 Does not Operate with the Programming Key The lock does not recognize the Programming Key. If the Programming Key has been replaced, operate with the Replacement Programming Key. Contact Digilock support for additional assistance. No Audible Feedback when = is Pressed The lock may be in Sleep Mode or the batteries may need to be replaced.
