Digilock Curve Product Manual

SHARED & ASSIGNED USE FUNCTIONALITY
Aspire locks with a keypad interface are operated by a 4-7 digit User Code or by an ADA compliant User Key. Manager Keys provide
management access and external power. Programming is accomplished via a Programming Key unique to the lock system. An optional
mobile application tool simplifies lock system management and provides audit trail for locks with advanced functionality.
LOCK PARTS
Front Unit
C Button
Key Slot
Pull Handle
Standard
KEYS
Operates the lock
Overrides user access
Allows management inspection
Provides external power
Programs Manager Keys to the lock
Assigns user credentials
Sets lock functionality
1 Up to 6 Manager Keys may be programmed to each lock. If managed with the optional Mobile App, up to 250 Manager Keys may be programmed to each lock.
2 One (1) Programming Key allowed per lock system.
3
Up to 20 user credentials may be assigned to each lock. If managed with the optional Mobile App, up to 250 user credentials may be assigned to each lock.
Key Insertion
1
PR OD U CT G UI D E
Keypad | Basic & Advanced
Alpha Numeric
Keypad
Key Button
LED Usage Indicator
Shared Use
Assigned Use
(in assigned use functionality)
3
Deadbolt Rear Unit
Cover Plate
Cover Plate Screw
User Key Manager Key
•
Cable
½" (12.7 mm)
Deadbolt
Pin
Connection Options
Programming Key
1
• •
• •
• •
• •
•
•
•
2
