Versa locks with an RFID interface are operated by an RFID credential or an ADA compliant User Key. Manager Keys provide management
access and external power. Programming is accomplished via a Programming Key unique to the lock system. For Advanced Models of Versa,
an optional mobile application tool is available to simplify lock system management and provide audit trail.
Lock Orientation
Front Unit
Reader
Key Button
Key Slot
LED Usage Indicator
Shared Use
Knob
Assigned Use
ADA Handle
Vertical with Knob on Bottom
RFID Credentials
RFID Card
Keys
Operates the lock
Overrides user access
Allows management inspection
Provides external power
Programs Manager Keys to the lock
Assigns user credentials
3
(in assigned use functionality)
Sets lock functionality
1
Up to 6 Manager Keys may be programmed to each lock.
2
1 Programming Key allowed per lock system.
3
Up to 20 user credentials may be assigned to each lock.
Product Guide
Vertical with Knob on Top
RFID Adhesive
RFID Keyfob
Label
User Key
•
Touch RFID
Shared & Assigned Use Functionality
Horizontal with Knob on Left
Horizontal with Knob on Right
RFID Wristband
1
Manager Key
Programming Key
•
•
•
•
•
2
•
•
•
•
•
•
1
Advertisement
Related Manuals for Digilock numeris versa mini
Summary of Contents for Digilock numeris versa mini
- Page 1 Product Guide Touch RFID Shared & Assigned Use Functionality Versa locks with an RFID interface are operated by an RFID credential or an ADA compliant User Key. Manager Keys provide management access and external power. Programming is accomplished via a Programming Key unique to the lock system. For Advanced Models of Versa, an optional mobile application tool is available to simplify lock system management and provide audit trail.
-
Page 2: Key Insertion
Product Guide Touch RFID Shared & Assigned Use Functionality Key Insertion Numeris logo must face towards the ` Button. Setup Locks are shipped with factory default settings (only operates by touching `). Each lock must be set up to operate with a Programming Key and Manager Credentials. -
Page 3: Programming Instructions
Product Guide Touch RFID Shared & Assigned Use Functionality Programming Instructions Express Register Manager Credentials The Programming Key can quickly program multiple locks to operate with the same Manager Credentials. Go to a lock already programmed to operate with the Manager Credentials. While the LED is fl... - Page 4 The locks must be reprogrammed to prevent the lost/stolen Programming Key or Manager Credentials from operating a lock. To replace the Programming Key: Note the order or serial number (found on the lock’s rear). Contact Digilock Support to purchase a replacement Programming Key. To replace the Manager Credentials: Collect all remaining and replacement Manager Credentials.
- Page 5 Product Guide Touch RFID Shared & Assigned Use Functionality Programming Instructions - In Assigned Use Functionality Assign User Credentials (for assigned use functionality only) Make sure that the lock is set for assigned use functionality (a green LED will fl ash when ` is touched). Up to 20 user credentials (User RFID Credentials and/or User Keys) may be assigned to each lock.
- Page 6 Product Guide Touch RFID Shared & Assigned Use Functionality Programming Instructions - In Assigned Use Functionality Remove User Credentials (for assigned use functionality only) Make sure the lock is in assigned use functionality (a green LED will fl ash when ` is touched). The locks must be reprogrammed to remove user credentials from operating a lock.
- Page 7 Product Guide Touch RFID Shared & Assigned Use Functionality Programming Instructions - In Assigned Use Functionality Replace an Assigned User Credential Replace an Assigned User RFID Credential with a New User Key: Touch and hold for 5 seconds (a two-tone While the LED is on, present the assigned While the LED is on, insert a new User Key.
- Page 8 Product Guide Touch RFID Shared & Assigned Use Functionality Operating Instructions - In Shared Use Functionality In shared use functionality, the user presents any User RFID Credential or inserts any User Key to lock and uses the same User RFID credential to unlock.
- Page 9 Product Guide Touch RFID Shared & Assigned Use Functionality Operating Instructions - In Assigned Use Functionality In assigned use functionality, users operate the lock with their assigned user credential (either a User RFID Credential or a User Key). Operate with a RFID Credential To unlock: Touch ` and present any User RFID Credential, then turn To lock: Close the door then turn the knob to the locked position.
-
Page 10: Battery Replacement
Does not Operate with the Programming Key The lock does not recognize the Programming Key. If the Programming Key has been replaced, operate with the Replacement Programming Key. Contact Digilock support for additional assistance. No Audible Feedback when ` is Touched The batteries may need to be replaced. -
Page 11: Safety Notice
SAFETY NOTICE Instability Hazard Mobile items on casters such as flip top, personal and movable tables of any type and storage items of any type may present an instability hazard if not secured correctly while in use or in storage. Flip top tables or training tables of any type, are inherently more unstable when folded.
