3-Way SRL Set Up:
NEVER use 3-Way SRL for material hoisting or for routine personnel hoisting; doing so may result in
increased wear of internal components.
3-Way SRL should only be used in personnel hoisting for the purposes or rescue/retrieval (to raise or
lower a worker that has experienced a fall).
For routine personnel or material hoisting, always use an independent winch, such as Guardian's Rescue Winch
(part # 15028). If using a winch for personnel hoisting, always use a backup fall protection device rated for
Fall Arrest.
If a winch and 3-Way SRL are being used simultaneously, winch and 3-Way SRL must be installed on separate
Arc-O-Pod legs, and Arc-O-Pod must be equipped with additional pulley.
Never connect the hook components of the winch and 3-Way SRL to same D-ring on full-body harness. This
may require the use of a dual-leg connecting device to allow the worker to employ full-body harness shoulder
D-rings.
For information relating to the use of 3-Way SRL, please refer to instructions provided with product.
For information relating to the installation and use of the Guardian Rescue Winch (part # 15028),
please refer to instructions provided with product.
1. Install Mounting Bracket onto Arc-O-Pod leg:
- Place Mounting Bracket over leg so 3-Way SRL snap hook will face up towards Arc-O-Pod Pulley.
- Select desired height of 3-Way SRL on Arc-O-Pod leg, and place Mounting Bracket at location.
- Install (2) provided Locking Pins through Mounting Bracket and Arc-O-Pod leg as shown.
- Secure Locking Pins with connected hitch pins, and ensure Mounting Bracket is fully secured to Arc-O-Pod
leg.
2. Install 3-Way SRL on Mounting Bracket:
- Remove (2) Plastic Screws from 3-Way SRL.
- Latch 3-Way SRL Swivel Eye over hook on Mounting Bracket, then lower 3-Way SRL into Mounting Bracket
cradle.
- Insert (2) screws provided with Mounting Bracket through Mounting Bracket and into 3-Way SRL at location
where Plastic Screws were removed. DO NOT use Plastic Screws to mount 3-Way SRL.
See image on following page.
