Thank you for your purchase of LE-series.
This booklet tells you only the basic operation. For more detailed information, please
refer to the instruction manual (PDF) in the utility CD attached to the product.
When you unpack the product, confirm following items
□
Protocol Analyzer
□
Interface Sub-board (attached to the analyzer)
□
DSUB 25pin Monitor Cable (Model: LE-25M1)
□
DSUB 9pin Monitor cable (Model: LE-009M2)
□
DSUB 25-9 conversion adapter
□
5wire TTL probe (Model: LE-5LS)
□
Micro USB Cable
□
Carrying Bag (Model: LEB-01)
□
USB Battery Charger (Model: LE-P2USB)
□
Utility CD
□
Quick Start Guide (this booklet)
□
Registration Card, Warranty
Please let us know if you find any damage to the product or accessories lacking.
2020 by LINEEYE CO., LTD. All rights reserved.
Quick Start Guide
Quick Start Guide
MULTI PROTOCOL ANALYZER
LE-3500XR
LE-2500XR
1
1
1
1
1
1
1
1
1
1
1
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LE Series and is the answer not in the manual?

Questions and answers

Related Manuals for LineEye LE Series

Summary of Contents for LineEye LE Series

  • Page 1 USB Battery Charger (Model: LE-P2USB) □ Utility CD □ Quick Start Guide (this booklet) □ Registration Card, Warranty Please let us know if you find any damage to the product or accessories lacking. 2020 by LINEEYE CO., LTD. All rights reserved.
  • Page 2 ・ Reference page is displayed in (Pxxx). It is prohibited to reprint or duplicate any part of this manual without prior permission of LINEEYE. The content of this manual and specification of the product is subject to change without any notice.

  • Page 3: Safety Information

    This may result in an electric shock and malfunction. * Do not use the batteries other than the Lithium-Ion batteries specified by LINEEYE. Do not short the electrode of battery, disassemble or modify. This may result in generation of explosion and ignition.

  • Page 4: Panel Description

    Panel Description ⑤ ⑩ ⑧ ⑦ ⑥ ④ ③ ② ⑬ ① ⑪ ⑫ ⑨ N a m e D e s c r i p t i o n ① Power Switch Turning the power on/off. ② SD Card Slot The inlet for a SD/SDHC card.

  • Page 5: Power Supply And Battery

    ＜ Notice for battery ＞ * Do not short the terminal of the battery. * Use the battery and battery charger specified by LINEEYE. * Do not disassemble or modify the battery. * Do not use the analyzer near the heater or leave it in the place with high temperature.
  • Page 6 Touch Panel and Keys Touch panels enable to select settings by soft touch or to scroll displays by swipe. Keys Operations Function Turn ON/OFF the power. [　　　] Press it longer to turn off the power. [RUN] Start monitoring, measuring or testing operation. [STOP] Stop monitoring, measuring or testing operation.

  • Page 7: Initial Settings

    Initial Settings Press [ ] to turn on the power. Select language and set data & time. *The top screen displays the model name. Press [M EN U ] to set the i n it ial settings. Swipe the screen to set all settings.
  • Page 8 Interface 　 Select a measurement port of analyzer. Shortcut key 　［ MENU ］ ,[1] For Simulation, select DTE or DCE mode and polarity. For Monitoring, polarity has to be set as well. Function 　 Select a function. Shortcut key 　［ MENU ］ ,[7] →[Monitor Function] (P13) →[Simulation Function] (P16) →[BERT Function] (P19)
  • Page 9 Configuration 　 Select basic communication conditions. Shortcut key 　［ MENU ］ ,[0] Protocol : Select Asy nch ronous (ASY NC), Cha r a ct e r sy nch ronou s (SY NC, BSC), Bit sy nch ronou s ( H DLC, SDLC), I2C or SPI.
  • Page 10 Record control 　 Set recording conditions of measured data. Shortcut key 　［ MENU ］ ,[3] Touch the tab or press 、 [SHIFT]+[ 　　 ] or [SHIFT]+[ 　　 ]. ‫ ڦ‬Additional info. Idle time : Select ON/OFF of idle time (non- communication time) and time resolution.
  • Page 11 System Setting and Version Press [MENU] and then touch "System Settings". Shortcut key 　［ MENU ］ ,[D] Touch the tab or press 、 [SHIFT]+[ 　　 ] or [SHIFT]+[ 　　 ]. ‫ ڦ‬Display It is able to adjust the brightness of LCD back light, set the power saving mode, and select the storage device of screen shot.
  • Page 12 Connect to the Target Devices ‫ ڦ‬Connect to RS-232C Connect RS-232C connectors of the target devices to the RS-232C port of analyzer using monitor cable. ‫ ڧ‬For monitoring Either is Dsub 25 Both Dsub 9 pin connector pin connector Dsub9 Dsub25 Dsub25-9 MONITOR Cable...
  • Page 13 ‫ ڦ‬Connect to RS-422/485　 Connect appropriate signals of target device to the RS-422/485 port. < RS-422/485 port > Connect TXD+ and TXD-, and RXD+ and RXD- using twisted pair cable. *T h i s i s t h e r e m ova b l e t e r m i n a l . R e m o v e i t f r o m a n a l y ze r f i r s t , connect cables and return it to the ‫...
  • Page 14 ‫ ڦ‬Connect to TTL interface　 Connect appropriate signals of UART, I2C and SPI to the TTL port of analyzer using attached probe cable. MIL box type 10pin header Cable color Input/ Signal Name LE-5LS TTL port Output TXD, SDA of I2C, SDO of SPI Brown RXD, SDI of SPI RTS, SS(CS) of SPI...

  • Page 15: Monitor Function

    Monitor Function ‫ ڦ‬Start and Stop measurement Press [RUN] to start monitoring. Measured data is displayed at real time and recorded in the capture memory. Send (TXD) data and receive (RXD) data are displayed in two lines as a pair. The latest data is displayed on the left side of " " marker.
  • Page 16 ③ ④ ⑤ ⑥ ⑦ ① ② ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ⑭ ① Measuring 〔　　〕 , Pause 〔　　〕 . Position of data/ all data. Able to type the position of data. ② （*1） Speed and character framing while measuring (e.g. B8-PO-S1). ③...
  • Page 17 ‫ ڦ‬Signal Voltage and Delay Time Press [MENU ]->"Function"-> "MONITOR" -> "DELAY Function " and then touch "Advanced settings". Set the start/ stop conditions of delay time for target signals. Press [RUN] to display the delay time and voltage (max./ min.). Use "Wave monitor"...

  • Page 18: Simulation Function

    Simulation Function You can execute a communication test for a device in development by sending/receiving data by the analyzer depending on the selected mode. ‫ ڦ‬Registration of Transmission Data Select the simulation function at "Operation mode" of [MENU], and then touch "Tx-data registration"...
  • Page 19 ‫ ڦ‬Start and Stop Measurement Touch [RUN] to start the specified test function and touch [STOP] to stop it. When the analyzer is set to DTE, The TXD line means the data is transmitted from the analyzer. When the analyzer is set to DCE, the RXD line means the data is transmitted from the analyzer.
  • Page 20 ‫ ڧ‬POLLING Mode W he n t he m a st e r mo d e i s s e t , polling messages are sent to 32 types of slave address stations, and the returned data is checked and displayed for each slave station.
  • Page 21 BERT (Bit Error Rate Test) Function ‫ ڦ‬Measurement Start and Stop Select the test mode, test pattern, and on/off of RTS-CTS f low control in advance. By pressing [RUN] it starts transmission of the specified test pattern and compares the received data with the test pattern. Then it measures the bit error rate etc.

  • Page 22: Useful Functions

    Useful Functions ‫ ڦ‬Trigger Function By this function it executes a special measurement processing ("Action") triggered by specific conditions ("Factor") such as the occurrence of a communication error during the measurement or reception of the specified data. 〔Factor〕 Error Communication error, break, multiprocessor bit on Character Communication data of up to 8 characters Line state...
  • Page 23 Setting example 1: When you want to notify an external measuring instrument that a block check error has occurred. Turn on the check mark of the trigger to be used and touch the trigger factor. Select "Error" on the trigger factor setting and check the BCC error you want to detect.
  • Page 24 ‫ ڦ‬Timing Waveform Measurement Function This function periodically records the logical state of the communication line and displays the timing waveform like a logic analyzer. Shortcut key 　［ MENU ］ ,[4] Press [MENU] and touch "Wave monitor" . Mark on the box of Enable wave monitor and configure the sampling clock (50ns to 1ms), trigger position, and trigger pattern.
  • Page 25 ‫ ڦ‬Auto Save Function With this function, it automatically saves the communication data as a measurement log file in the optional SD card or USB flash drive while measuring. Since long time communication data can be recorded, it is useful to clarify rare communication failures of unknown cause.
  • Page 26 ‫ ڦ‬Auto Backup Function Since the capture memory is DDR3-SDRAM which loses data when the power is turned off, at the end of measurement the analyzer automatically backs up the about 512 KB of the latest part of the measurement data into the SRAM backed up by the battery.
  • Page 27 ‫ ڦ‬Communication Condition Auto Setting Function The monitor processing of the analyzer estimates the communication conditions of unknown communication lines for measurement. By touching “Auto Configuration” in the [ ] menu, “Analyzing transmission speed...” is displayed and the analysis process of communication condition starts.
  • Page 28 Use OP-SB7XL. ‫ ڦ‬Loading and switching of extended firmware The firmwares for expansion options are available on the LINEEYE website. Load it to the analyzer using le8firm.exe included in the attached CD. Once written, the corresponding firmware starts up simply by replacing the sub- board.

  • Page 29: Pc Link Function

    The PC Link software offers remote monitoring and conversion of measurement data to text files on a PC. The "lite version" with some restrictions can be downloaded free of charge from the LINEEYE website. Unzip the downloaded file and execute setup.exe in the folder.
  • Page 30 [Example of Remote Monitor Screen] [Example of text conversion] ‫ ڦ‬How to update the firmware The latest firmware is available on the LINEEYE website below. https://www.lineeye.com/html/download_update.html Download the firmware and update it from your PC using the firmware transfer software le8firm.exe included in the "Utility" folder of the attached CD.
  • Page 31 When measuring the TTL port, the input voltage range is -1 to 6V. * 3 : For USB flash drive only. Not all one are supported. * 4 : For optional SDHC card sold by LINEEYE. * 5 : Based on our measurement conditions.
  • Page 32 For any technical issues Read "FAQ" in our website or email us. https://www.lineeye.com/html/contactus.html LINEEYE CO., LTD. 4F., Marufuku Bldg., 39-1, Karahashi Nishihiragaki-cho, Minami-ku, Kyoto, 601-8468, Japan Tel : 075(693)0161 Fax : 075(693)0163 URL https://www.lineeye.com Printed in Japan M-30235XQE/LE...
