LineEye LE Series Quick Start Manual

Data line monitor
Hide thumbs Also See for LE Series:
Table of Contents

Advertisement

Quick Links

Download this manual
Thank you for your purchase of LE-series.
This booklet tells you only the basic operation. For more detailed
information, please refer to the instruction manual (PDF) in the utility CD
attached to the product.
When you unpack the product, make sure you have all
following items
□
Line Monitor
□
Dsub 9pin Monitor Cable (LE-009M2)
□
10pin External Input/Output Cable (LE-10ES1) 1
□
Micro USB Cable
□
AA-sized NiMH batteries
□
Utility CD
□
Carrying Bag
Quick Start Guide (this booklet)
□
Warranty, Registration Card
□
Please let us know if you find any damage to the product or accessories lacking.
It is prohibited to reprint or duplicate any part of this manual without prior permission
from LINEEYE.
The content of this manual and specification of the product is subject to change without
any notice.
Quick Start Guide
2019 by LINEEYE CO., LTD . All rights reserved
DATA LINE MONITOR
LE-170SA
＜ 1st edition ＞
1
1
1
2
(Battery installed)
1
1
1
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LE Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LineEye LE Series

Summary of Contents for LineEye LE Series

  • Page 1 It is prohibited to reprint or duplicate any part of this manual without prior permission from LINEEYE. The content of this manual and specification of the product is subject to change without any notice. ＜ 1st edition ＞ 2019 by LINEEYE CO., LTD . All rights reserved...

  • Page 3: Safety Information

    Safety Information Please do not use the line monitor in the following conditions [Description of the symbol and mark] There is a possibility of getting hurt, such as a death or a Warning: serious injury. There is a possibility of getting injured or damaging the Caution: product.
  • Page 4 Nomenclature [LE-170SA] Name Function Power Switch Turn on / off the power [Run] key Start monitoring / simulating [ S t o p ] k e y Stop monitoring / simulating [ Menu ] key Display the top menu [ Esc ] key Return to the previous display 4.3 inch color LCD with touch panel Line State LED...

  • Page 5: Power And Battery

    To charge the Ni-MH batteries, use the battery charger for AA sized Ni-MH batteries. LINEEYE has confirmed it works with “BQ-CC23” or “BQCC55” of Panasonic, and “TNHC-34SMC” or “TNHC-34HBC” of Toshiba. The line monitor is able to charge the Ni-MH batteries by appropriate settings.

  • Page 6: Operation

    Operation There are 5 keys and touch panels to control the line monitor. Touch panels enable to select settings by soft touch or to scroll the display by swipe. Basic operations are made by key operations. Pressing 2 keys simultaneously have the special functions.

  • Page 7: Initial Settings

    Initial Settings Press [ ] to turn on the power. Select the language and set date & time. Press [Menu] key to set the initial settings. Function : Select a function. CAN Configuration : Select basic communication conditions. LIN Configuration : Select basic communication conditions.
  • Page 8 e.g.: CAN monitor Function: Monitor CAN Configuration: 500Kbps, sample point 75% e.g.: LIN monitor Function: Monitor LIN Configuration: 9600bps, ID filter “None” e.g.: CAN Simulation Function: CAN Simulation *Set the communication condition in “CAN Configuration”. *Touch “Tx-frame registration” and register test data to send.
  • Page 9 Connect to the Target Device [Connect to CAN interface] Connect the CAN port of analyzer and target device using the attached monitor cable. < CAN Port > 5Pin 1Pin MONITOR Cable CAN Port (LE-009M2) 6Pin 9Pin Dsub9 Pin (female) Input/output Signal name Description Monitor...
  • Page 10 MIL box type 10pin cable Cable color Signal Input/output Description LE-10ES1 LE-5LS Monitor Simulation name External Input1 Brown Brown External Input2 Orange External Input3 Green Orange External Input4 Purple Yellow Signal Ground White Green Signal Ground External Trigger Output Yellow External Trigger Input blue LIN bus signal...

  • Page 11: Measurement Start And Stop

    Measurement Start and Stop Press [Run] to start measuring. [Monitoring] The line monitor displays the communication data in real time and records data in the capture buffer. [Simulating] It displays the monitored data and simulates data registered in the data table. Able to select the transmission data by pressing [Menu] or [...] displayed in the bottom.
  • Page 12 6) 7) Each data is displayed in specific colors. CAN frame -> yellow. LIN frame -> green. External input data -> white. Measuring 〔　　〕 , Pause 〔　　〕 Position of data/ all data. Able to type the position to dispiay. Other status Selected Mode [CAN/LIN]: Monitor CAN/LIN [CAN sim]: Simulate CAN...
  • Page 13 〔 Display 〕 Display Description Time stamp Time of receiving frames (H/M/S/ms) （ ： Matched with trigger condition ） SyPID Sync byte field and Protected ID field of LIN (in HEX). Standard/ expansion ID of CAN, or LIN frame ID (in HEX). Type Frame type.

  • Page 14: Useful Functions

    Useful Functions Trigger Function ■ Trigger function is for starting a specific action upon occurrence of a specific facetor as a trigger. e.g.: Stop measuring when detecting a “ID=023” CAN frame. Press [Menu] → [Trigger] → Mark on “Trigger0”to t u r n o n t h e t r i g g e r function.
  • Page 15 e.g.: Output a pulse to the external device when receiving a specific error. Trigger Factor : Error Trigger Action : TRGOUT pulse output Output a low pulse for about 1msec from the external trigger terminal OUT. Auto Backup ■ Measurement data is erased when turning off the power of line monitor.

  • Page 16: Specification

    Specification Item LE-170SA Interface CAN (ISO11898) / LIN (ISO9141) Protocol CAN 2.0LIN (Rev. 1.1, 1.2, 1.3, 2.0, 2.1) Communication speed(bps) CAN: 20kbps to 1MbpsLIN: 400bps to 26kbps Capture memory 16Mbyte (about 500K data). Able to divide in two. <CAN> Standard/extended format are supported, bit receiving timing can be set, filtering is available, arbitrary speed Monitor function can be set.

  • Page 17: Warranty And After-Service

    Warranty and After Service Warranty Trouble ■ Contact the distributor or LINEEYE. Warranty Card ■ The warranty card is attached to the product. Confirm the content and fill out the blanks and keep it. Warranty period: 1 year from the purchase (Does not include the one for the software.)
  • Page 18 Memo...
  • Page 20 For any technical issues Read "FAQ" in our website or email us. http://www.lineeye.co.jp/html/contact.html LINEEYE CO., LTD. 4F., Marufuku Bldg., 39-1, Karahashi Nishihiragaki-cho, Minami-ku, Kyo- to, 601-8468, Japan Tel : 075(693)0161 Fax:075(693)0163 URL http://www.lineeye.co.jp Email : info@lineeye.co.jp Printed in Japan M-19170SAQE/LE...

This manual is also suitable for:

Le-170sa
