OPTIONAL KIT
FOR MULTI PROTOCOL ANALYZER
LE-8500X-RT/LE-8500XR-RT
PC Link Software
LE-PC800X
Instruction Manual
The CD-ROM attached contains the English and Japanese instruction manuals in PDF format.
The actual display or manner of operation may differ from that of the instruction manual
because of the improvement of the product and so on. Please refer to the online help also for
the use of the software.
The 1th Edition
Advertisement
Table of Contents
Related Manuals for LineEye LE-8500X-RT
Summary of Contents for LineEye LE-8500X-RT
- Page 1 OPTIONAL KIT FOR MULTI PROTOCOL ANALYZER LE-8500X-RT/LE-8500XR-RT PC Link Software LE-PC800X Instruction Manual The CD-ROM attached contains the English and Japanese instruction manuals in PDF format. The actual display or manner of operation may differ from that of the instruction manual because of the improvement of the product and so on.
-
Page 2: Table Of Contents
Add the Remote Setting ..............................23 Open the Data Window ..............................24 Delete the Remote Setting ..............................24 Operate Setting When Starting............................24 Startup Options ................................. 25 Chapter 12 Specification ........................26 Copyright 2008-2020 by LINEEYE CO., LTD. All rights reserved. -
Page 3: Chapter 1 Before Using The Product
5. Limitation of Liability In no event shall LINEEYE or its licensors be liable for any loss of business or profits, or for any direct,indirect, incidental or consequential damages arising from products of this software or the related soft- ware. -
Page 4: Chapter 2 Introduction
CD-ROM attached to the analyzer.) □ CD-ROM (software) □ Instruction Manual (This book) □ User Registration Card Please contact your LINEEYE distributors if you find any damage to the product caused by trans- portation, or if there are accessories lacking. -
Page 5: Chapter 3 Before Start-Up
Chapter 3 Before Start-up USB Driver Installation When using this software by USB connection, connect the USB port of PC and analyzer using the USB cable before using it. Confirm the IP address of analyzer. When using this software by LAN or Wi-Fi (appropriate model only), confirm the IP address and port number of analyzer before using it. -
Page 6: Installation Guide
Please enter the serial number of this software written on the attached user registration card. For the light version “LE-PC800X (LITE)” which you can download free of charge from the LINEEYE website, the serial number will be automatically entered as “LITE”. 6. When the installation completion message is displayed, click “Finish”. -
Page 7: Chapter 4 Data Window
Chapter 4 Data Window Data Window of PC link software ■Starting the PC link software. Start "LE-PC800X" from the "Start" of Windows. Usually, the following display will appear. Data Window 1) → 2) → 3) → ↑ ↑... - Page 8 Displays the model name of your analyzer being set at the time of offline, and one of your analyzer being connected at the time of online. * For LE-8500X-RT, “LE-8500X+SB-R2TS1” is displayed. For LE-8500XR-RT, “LE-8500XR+SB-R2TS1” is displayed. Refer to the "On-Line Help" for more details of operation.
-
Page 9: Chapter 5 Environment Setting
Chapter 5 Environment Setting Remote Setting Click on the tool bar of the data window (or “Remote Setting” of “Remote” menu) to set the remote setting. The remote setting consists of “Connection”, “Model selection”, “Key emulation” and “Miscellaneous”. ■ Connection Sets the remote connection “Connection Method”... - Page 10 ■Model selection Sets your analyzer settings. Mainly, it is used at the time of offline. However in the case of that there is information which is not received by remote communication at the time of online, it is used as it is set. In addition.
- Page 11 ■Remote monitor Sets the remote monitor “A folder to save the remote monitor data” This folder is to save data received by your analyzer for the remote monitor function. To change the setting, click “Change” button. Then the window to select a folder appears. Select the proper folder and click “OK”...
- Page 12 “Append mode” When measurement starts, a newly-created file is saved in the order after the existing files. If the numbers of the whole data files are over the maximum block count setting, a data file with a small number file (includes data files which were saved on the former measurement) is deleted even in the append mode.
- Page 13 ■“Miscellaneous” “Settings synchronization” Transmits and receives the setting automatically a the time of the opening and closing the ana- lyzer setting window. If you mark on “Disable automatic setting receive”, you only transmit and do not receive. “Simulation programs transmission” The setting data to be sent to or be received from the analyzer contains simulation programs data when this term is marked.
-
Page 14: Chapter 6 Remote Monitor
Chapter 6 Remote Monitor This function allows to start measurement of your analyzer and to record measurement data in the HDD/ SSD of the PC, displaying the data in real time. Connection After finishing the remote setting, click on the tool bar of the window (or click “Connect” of the remote menu) to connect with you analyzer. -
Page 15: Simulation Data Setting
Simulation Data Setting Click on the toolbar of the data window to select the simulation data table you would like to set (or click “Analyzer setting” of the measurement menu.) Change the data to hexadecimal or character code. Change the input method to hexadecimal or character code. The character which is focused is set to the parity error (or the multi-processor bit) Input BCC (or FCS). -
Page 16: Max Speed When Remote Monitoring
Max speed when remote monitoring Max speed which analyzer can measure is depending on the connection to the PC. Refer to the following standard speed. USB (USB3.0/3.1) : Max. 5Mbps : Max. 2Mbps Wi-Fi : Max. 1Mbps *1 The max. measurement speed becomes lower by the network load. However, when measuring 10Mbps with 2K byte data for every 0.02 seconds, the actual communication speed is about 1Mbps, and you can measure this communication without any data loss. -
Page 17: Remote Monitor Screen
Remote Monitor Screen There are following methods to switch the screen display. -Change display code Select a character code from the drop down list (marked above 1) which displays the character code. -Hexadecimal display Click (Displays in hexadecimal including the special characters.) -Control line informa- Click tion display... -
Page 18: Read The Measurement Data
Read the Measurement Data Click on the toolbar of the data window (or click “File” -> “Open data file”) to select a file of the measurement data. When two or more files are opened, they are displayed as continuous data. Click “File”... -
Page 19: Chapter 7 Bit Error Rate Test (Bert)
Chapter 7 Bit Error Rate Test (BERT) Bit error rate test (BERT) can monitor the quality of communication lines in the long distance. Start Measurement Click on the toolbar of the data window (or click “Run measurement” of the measurement menu). After measurement starts, the following screen appears. -
Page 20: Chapter 8 Key Emulation
Chapter 8 Key Emulation This function allows to control the analyzer from a far place. (remote control) Run Key Emulation Click on the toolbar of the data window (or click “Key emulation” of the tool menu.). 1. Displays the screen of your analyzer being connected. 2. -
Page 21: Chapter 9 Text Conversion
Chapter 9 Text Conversion This function allows to convert the data which is measured on the remote monitor, and which is saved on such as a memory card and HDD/SSD into a text file. Text Conversion Function Setting Click on the toolbar of the data window (or click “Text conversion” of the menu.). The following text conversion window opens. - Page 22 -Output format Selects a format you wish to convert from the following. “Normal” (Print format of your analyzer) “With line state” (Print format of your analyzer which includes control line information) “Translated” (Translated print format of your analyzer) “CSV format (data)” (Every data divided.) “CSV format (frame)”...
-
Page 23: Start Text Conversion
If the CSV conversion is selected, the following window appears. -Select data line Selects from “SD and RD,” “SD only” and “RD only.” -Data format Selects from “Hexadecimal,” “Decimal” and “Character.” -Column Sets the range between 1 and 65535. -Delimit char. Sets the delimit character such as “,”... -
Page 24: Chapter 10 Waveform Monitor Data
Chapter 10 Waveform Monitor Data When the analyzer has logic analyzer data, the waveform monitor data is received and displayed. -Scaling factor Move the slider and select the scaling factor. -Cursor display Click . The cursor mark is displayed by double-clicking. -Marker display Click . -
Page 25: Chapter 11 Connecting Multiple Analyzers
Chapter 11 Connecting Multiple Analyzers To connect multiple analyzers at the same time, add the necessary setting for the number of analyzers to connect. Adds the remote setting on the remote setting list window. To open the remote setting list window, click from the toolbar of the window (or click “remote setting list”... -
Page 26: Open The Data Window
When opening this setting window from the remote setting list window, you can rename the setting name. Adds the remote setting for the number of analyzers you wish to connect. (It does not allow you to rename the setting name when the window opened from the data window.) Open the Data Window To open the selected data window for remote setting, select the specific remote setting from the list of the remote setting list window (multiple selections possible), and click... -
Page 27: Startup Options
It saves measured data to the data file immediately, and try to keep the format of data file as normal. (LINEEYE does not warrant the condition is normal.) Also, it will allow to read the measured file which is in the process of saving data, and able to copy the data file. -
Page 28: Chapter 12 Specification
Chapter 12 Specification Applicable analyzer LE-8500X-RT,LE-8500XR-RT Applicable Option SB-R2TS1 Connection with analyzer USB, LAN, Wi-Fi(appropriate model only) How much analyzers Can connect with multiple analyzers and control them remotely (PC capability determines how much can be connected.) Key emulation function It emulates the display and control part of the analyzer on PC and you can control as if you are controlling it directly. - Page 29 *1 Available by adding SB-R2TS1 for LE-8500X/XR and LE-8600X/XR. *2 See "Max speed when remote monitoring" on page 14 for the communication speed of the measurement target that can record the measurement data without fail on the remote monitor. The LE-PC800X (light version) included in the CD that comes with the analyzer automatically terminates the remote monitor in 10 minutes, so long-term continuous measurement cannot be used.
- Page 30 Please register your product for further support. We will provide you the software update information and sales information etc. LINEEYE CO., LTD. 4F., Marufuku Bldg., 39-1, Karahashi Nishihiragaki-cho, Minami-ku, Kyoto, 601-8468, Japan Phone : 81-75-693-0161 Fax : 81-75-693-0163 URL https://www.lineeye.com Email :info@lineeye.co.jp Printed in Japan M-12PC8XE/PC...
