LineEye LE-110SA Quick Start Manual

Data line monitor
Hide thumbs Also See for LE-110SA:
Table of Contents

Advertisement

Quick Links

Download this manual
Thank you for your purchase of LE-series.
This booklet tells you only the basic operation. For more detailed
information, please refer to the instruction manual (PDF) in the utility CD
attached to the product.
When you unpack the product, make sure you have all
following items
□
Line Monitor
□
DB9 Monitor Cable (LE-009M2)
□
Trigger Input/Output Cable (LE-4TG)
□
10pin External Input/Output Cable (LE-10ES1) 1 ... only for LE-120SA
□
Micro USB Cable
□
AA-sized NiMH batteries
□
Utility CD
□
Carrying Bag
□
Quick Start Guide (this booklet)
□
Warranty, Registration Card
Please let us know if you find any damage to the product or accessories lacking.
It is prohibited to reprint or duplicate any part of this manual without prior permission
from LINEEYE.
The content of this manual and specification of the product is subject to change without
any notice.
Quick Start Guide
2018 by LINEEYE CO., LTD . All rights reserved
DATA LINE MONITOR
LE-110SA
LE-120SA
1
1
1 ... only for LE-110SA
1
2
(Battery installed)
1
1
1
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LE-110SA and is the answer not in the manual?

Questions and answers

Related Manuals for LineEye LE-110SA

Summary of Contents for LineEye LE-110SA

  • Page 1 It is prohibited to reprint or duplicate any part of this manual without prior permission from LINEEYE. The content of this manual and specification of the product is subject to change without any notice. 2018 by LINEEYE CO., LTD . All rights reserved...

  • Page 3: Safety Information

    Safety Information Please do not use the line monitor in the following conditions [Description of the symbol and mark] There is a possibility of getting hurt, such as a death or a Warning: serious injury. There is a possibility of getting injured or damaging the Caution: product.
  • Page 4 Nomenclature [LE-110SA] 14) 13) Name Function Power Switch Turn on / off the power [Run] key Start monitoring / simulating [ S t o p ] k e y Stop monitoring / simulating [ Menu ] key Display the top menu...
  • Page 5 [LE-120SA] Name Function Power Switch Turn on / off the power [Run] key Start monitoring / simulating [ S t o p ] k e y Stop monitoring / simulating [ Menu ] key Display the top menu [ Esc ] key Return to the previous display 4.3 inch color LCD with touch panel Line State LED...

  • Page 6: Power And Battery

    To charge the Ni-MH batteries, use the battery charger for AA sized Ni-MH batteries. LINEEYE has confirmed it works with “BQ-CC23” or “BQCC55” of Panasonic, and “TNHC-34SMC” or “TNHC-34HBC” of Toshiba. The line monitor is able to charge the Ni-MH batteries by appropriate settings.

  • Page 7: Operation

    Operation There are 5 keys and touch panels to control the line monitor. Touch panels enable to select settings by soft touch or to scroll the display by swipe. Basic operations are made by key operations. Pressing 2 keys simultaneously have the special functions.

  • Page 8: Initial Settings

    Initial Settings Press [ ] to turn on the power. [LE-110SA] Select the language and set date & time. * The top screen will be "LE-120SA" for the model of LE-120SA. Press [Menu] key to set the initial settings. : Select a measurement port of line monitor and a function.
  • Page 9 Monitor RS-232C Speed: 38400bps, Data length: 8bit, Parity: Even, Stop: 1bit e.g.: Simulate RS-485 [LE-110SA] Speed: 460.8Kbps, Data length: 8bit, Parity: None, Stop: 1bit *Register test data in the “Tx-data registration”. e.g.: Monitor TTL (UART 3.3V) [LE-120SA]...
  • Page 10 Connect to the Target Device [Connect to RS-232C] Connect the RS-232C connector of target device < RS-232C Port > and the RS-232C port of line monitor, using 5Pin 1Pin included cable or appropriate cable. 6Pin 9Pin To monitor data ■ One of the target devices Both target devices have has Dsub 9pin connector.
  • Page 11 [Connect to RS-422/RS-485] (LE-110SA) Connect the signals of target device to < RS-422/485 Port > the corresponded RS-422/485 port of line monitor. LINEEY recommends using the twisted pair cable. (Pair: TXD+/-, RXD+/-) Need to have a terminal control (100 to * RS-422/485 port is the removal terminal.
  • Page 12 [Connect to TTL interface] (LE-120SA) Connect the TTL (UART) signals of target device to the corresponded TTL port of line monitor. MIL box type 10pin cable Cable color TTL Port Signal name Input/ LE-10ES1 LE-5LS output TXD TTL monitor input Brown Brown RXD TTL monitor input...

  • Page 13: Measurement Start And Stop

    Measurement Start and Stop Press [Run] to start measuring. [Monitoring] The line monitor displays the communication data in real time and records data in the capture buffer. Tr a n s m i s s i o n ( T X D) a n d r e c e i v i n g ( R X D) d a t a a r e displayed in two lines.
  • Page 14 6) 7) Measuring 〔　　〕 , Pause 〔　　〕 Position of data/ all data. Able to input the position of data. Speed and character (*1) framing while measuring (e.g. B8-PO-S1) Other status Measuring (selected) interface. Selected Mode. [Mon]: Monitoring, [Sim]:Simulating Status of USB device mode (Green: Connected) (*2) Status of Host port (Green: Connected) Level of remained battery.

  • Page 15: Useful Functions

    “Stop measurement” as trigger action. e.g.: Output a pulse to the external device when receiving a specific error. 〔 LE-110SA 〕 〔 LE-120SA 〕 Trigger Factor : Error Trigger Action : OT2 pulse output Output a low pulse for about 1ms in the external trigger terminal...
  • Page 16 Auto Configuration ■ Auto configuration function estimates the communication conditions of target device. It is useful if knowing nothing about the target conditions. Press 〔　 　〕 and select “Auto configuration”. Measurement will start after setting the communication conditions (speed, data length, parity). To have the right communication conditions, following conditions are necessary.
  • Page 17 PC. USB driver ■ Install a USB driver from attached CD (“Driver” folder) or LINEEYE webpage. Execute “setup.exe” before connection the line monitor and a PC. * Refer to the instruction manual in the utility CD.
  • Page 18 Specifications of Function and Hardware Item LE-110SA LE-120SA Interface RS-232C,RS-422/485 RS-232C,TTL Signal level None 1.8V,2.5V,3.3V,5V Protocol ASYNC ASYNC, UART Capture memory 16Mbyte (4000Kdata). Able to divide in two. 50, 75, 150, 300, 600, 1200, 2400, 4800, 9600, 12800, Speed(bps) 14400, 19200, 28800, 38400, 57600, 115200, 230400,...
  • Page 20 For any technical issues Read "FAQ" in our website or email us. http://www.lineeye.co.jp/html/contact.html LINEEYE CO., LTD. 4F., Marufuku Bldg., 39-1, Karahashi Nishihiragaki-cho, Minami-ku, Kyo- to, 601-8468, Japan Tel : 075(693)0161 Fax:075(693)0163 URL http://www.lineeye.co.jp Email : info@lineeye.co.jp Printed in Japan M-18112SAQE/LE...
