MULTI PROTOCOL ANALYZER
LE-8500XR-RT
LE-8500X-RT
INSTRUCTION MANUAL
《 Ver.4 2022.12　》

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LE-8500XR-RT and is the answer not in the manual?

Questions and answers

Related Manuals for LineEye LE-8500XR-RT

Summary of Contents for LineEye LE-8500XR-RT

  • Page 1 MULTI PROTOCOL ANALYZER LE-8500XR-RT LE-8500X-RT INSTRUCTION MANUAL 《 Ver.4 2022.12　》...
  • Page 3 This instruction manual has been designed and edited with great care to give you all necessary information. If you have any questions, feel free to direct your inquiries to LINEEYE. LINEEYE makes no warranty or guarantee, either expressed or implied with respect to its quality, performance, merchantability, or fitness for a particular purpose.

  • Page 4: Safety Information

    Safety Information Read this first !! This Safety Information includes the following important information in order to not only have you learn the right way to use the analyzer, but also prevent you from causing damage to people and property. Before using, please read the main contents after you understand the following symbols &...
  • Page 5 Caution ● Do not leave the analyzer in the following conditions. ・ Strong magnetic field, static electricity or dusty place. ・ Temperature and humidity above the specification or where dew condensation appears. ・ Not flat, or shaking place. ・ Place with leaking water or electricity ・...

  • Page 6: Table Of Contents

    CONTENTS Safety Information Chapter 4 Simulation Function Chapter 1 Before Using the Product 4.1 Register Transmission Data ....74 4.2 RS-422/485 Driver Control ....82 1.1 Description on This Manual ....6 4.3 Auto Line Control ......83 1.2 Unpacking .......... 6 4.4 Manual mode ........
  • Page 7 Chapter 7 Save and Load of the Data 7.1 Storage device........155 7.2 File Management Function ....156 Chapter 8 Utiltty 8.1 PC Link Function ......161 8.2 Capture data files while measuring . 163 8.3 PC Remote Control Library ..... 164 Chapter 9 Documents 9.1 Calculation of the Block Check ..

  • Page 8: Chapter 1 Before Using The Product

    □ Registration card, Warranty The card packed with the product is the user registration card for Japanese customers. For overseas customers, there is a user registration page on our web site.( https://www.lineeye. com ) Please let us know if you find any damage to the product or accessories lacking.

  • Page 9: Functions And Feature

    : Various Utilities 1.3 Functions and Feature LE-8500X-RT/LE-8500XR-RT is a multi-protocol analyzer that can measure and test RS-232C, RS- 530, RS-422/RS-485, and TTL level serial communication by one unit. Using the monitor function, communication simulation function, bit error rate function, etc. according to the test situation, it can be widely used for the development/maintenance of PC peripherals, serial interfaces of FA equipment, and UART, SPI, and I2C of embedded boards.

  • Page 10: Name Of Each Part

    1.4 Name of Each Part General Description Name AC adapter plug Connects the AC adapter, which serves as a battery charger. Power Switch Press for about 1 second to turn the power on/off. SD Card Slot The inlet for a SD/SDHC card. USB Host Port Connection port for a USB flash drive.
  • Page 11 (*1) RS-422/485 measurement port . Detachable terminal block, 5 RS-422/485 Port poles. SMA (female) connector GPS antenna connector When synchronizing the time with GPS, connect the optional GPS antenna . 7 Inch Color Display 7 Inch Color Display with capacitive touch panel. Line State LED Displays the status of the interface to be measured.
  • Page 12 ‫ ڦ‬Data display window 1) 2) 7) 8) Measuring “ ” , Pause “ ” Current status of the capture buffer. ０ :Entirely in use 　１　 / 　２ ： Divided into 2 parts and in use. 　　　　　 2.2.2 Record Control Recording area Description of the current window.
  • Page 13 Key operation There is a keyboard to input data and operate commands. ‫ ڦ‬Keys Operations Function Turn ON/OFF the power. Press it for more than 1sec. [RUN] Start monitoring, measuring or testing operation. [STOP] Stop monitoring, measuring or testing operation. [MENU] Return to the top menu.

  • Page 14: Power Supply And Battery

    1.5 Power Supply and Battery ‫ ڦ‬Power supply Works with the included AC adapter or built-in lithium-ion battery. Battery life is about 4 hours. Increases or decreases depending on usage. It does not work with bus power supply from the USB device port. AC adapter ‫...
  • Page 15 The clock built into the unit is backed up by the built-in lithium primary battery for about 5 years even when the power is turned off. If the watch goes wrong or will be reset, replacement of the lithium primary battery at our factory is required. In that case please contact LINEEYE or LINEEYE distributor. -13-...

  • Page 16: Hand Strap

    1.6 Hand Strap You are able to put and remove this hand strap. Put on the hand strap Hand strap is already set in the analyzer when you purchase. <Remove the hand strap> 1) Open the Velcro. 2) Remove the belt. 3) Remove the hand strap from the analyzer Reverse the process when putting on the hand strap.

  • Page 17: Chapter 2 Basic Operation And Set-Up

    At the first boot, the Japanese-English display language selection screen will be displayed. When it is already set, the top menu screen will be displayed. Both LE-8500XR-RT and LE-8500X -RT models are displayed as “LE-8500X”. Language (English or Japanese) At the first boot, you can switch the display language between Japanese and English.

  • Page 18: Top Menu

    2.2 Top Menu Press [MENU] to set the initial settings. Touch the setting item, or press [ENTER] after selecting the item by [ ▲ ] [ ▼ ][ Press [ESC] to move to the measurement result display screen. To switch the measurement mode, tap “Mode” or press [ENTER] while selecting “Mode” and select from the displayed mode list.

  • Page 19: Switching Between Normal Mode And High-Speed Mode

    2.2.1 Switching between normal mode and high-speed mode The LE-8500X-RT can be used by switching between a normal measurement mode and a high-speed mode that supports up to 20Mbps measurement. In high-speed mode, only Online, Manual, and PULSGEN can be used, and some functions such as triggers are also different. Press [SHIFT]+[0] on the top menu screen to enter normal mode, and press [SHIFT]+[3] to enter high-speed mode.
  • Page 20 ‫ ی‬Time stamp The time when the first data of the communication frame was captured can be recorded in the capture buffer as a time stamp. Set “Off ” or the time resolution from “Day Hour:Minute”, “Hour:Minute:Second”, “ M i n u t e:S e c o n d .10 m s e c ”, “ Ye a r / Mo n t h / D ay Ho u r : M i n u t e ”, “ Mo n t h / D ay Hour:Minute:Second”, “Day Hour:Minute:Second.10msec”, “100µs”, “10µs”...
  • Page 21 ‫ ڦ‬Capture Buffer Tap the tab of “Capt. Buffer” and set the capture memory setting of recorded data. ‫ ی‬Recording area T h e c a p t u r e m e m o r y i s 10 2 4 Mbytes.
  • Page 22 ‫ ڦ‬Auto save function Tap the Auto Save tab to configure autosave settings and auto backup settings. By using the auto save setting, you can automatically save the contents of the capture buffer (that is taken by monitoring in real-time) continuously for a long period of time as a measurement log file (auto save file) of a specified size to a storage device such as an SD card.
  • Page 23 ‫ ی‬File Size Specify the file size of the auto save f ile f rom 4M, 16M, 64M, 256Mbytes or “Buffer size” . The “Buffer size” will be the same as the capture memory size. Max files Max. Files ‫ی‬ Set the maximum number of auto save files to be automatically saved.
  • Page 24 ‫ ڦ‬Auto Run Function By using this function, you can repeat the measurement automatically for the specified period by specifying the date and time when the measurement starts and ends. It can start the measurement in conju nction with power- on and automatically finish the measurement at the specified date and time.

  • Page 25: System Config

    2.2.4 System Config ‫ ڦ‬Display / Power ‫ ی‬Backlight brightness A d j u s t t h e b r i g h t n e s s of t h e backlight. The brighter the backlight, the shorter the running time (higher consumption of current).
  • Page 26 ‫ ڦ‬Network At the time of shipment, the built- in Wi-Fi module is disabled and no wireless radio waves are output. When connecting to a computer remotely via wireless LAN, you need to set up a Wi- Fi connection. The Wi-Fi function is not available for LE-8500X-RT.
  • Page 27 ‫ ۑ‬Station Mode • Port number S e t t h e p o r t n u m b e r of analyzer. The initial value is “10101” . • SSID SSI D of w i reless access point. •...
  • Page 28 ‫ ۑ‬Access point mode Tap “Apply setting” at the end. • Port number S e t t h e p o r t n u m b e r of analyzer. The initial value is “10101” . • Security Select the security protocol from OPEN, WPA, WPA2 or WPA/WPA2.

  • Page 29: Diagnostics Function

    ‫ ڦ‬Version It displays the current firmware version of the analyzer, executes the firmware update mode, and initializes the main unit. 10.5 How to update the firmware 10.4 Factory reset 2.2.5 Diagnostics function Diagnostics function checks the conditions of analyzer. After the diagnostics, the power of analyzer need to be turned off [Preparation] Remove all measurement cables from analyzer and save important data.

  • Page 30: Time Settings

    2.2.6 Time Settings Current time and date are displayed in the screen. Set the time in order of Hr(24hour)/Min/Sec, and date in order of Yr/Mon/Day. Manual Set ・ Manually set the date and time. Use [ ] to move the cursor, use [0] to [9] to enter, and press “Set”...

  • Page 31: Measurement Port

    2.3 Measurement Port Select and set the measurement port to use. The settings are common to all modes. Select “Interface” from the top menu screen. Select the measurement port of target device. ] , [ Also it is able to select the item by [ ] and change the setting by [ ▲...
  • Page 32 ‫ ڦ‬Polarity Select “Normal”. If selecting “Invert”, all signals are inverted. ‫ ڦ‬Driver control (for RS-422/485 only) Select Off/Manual/Auto of driver IC control for simulation. 4.2 RS-422/485 Driver Control ‫ ڦ‬V.35 mode (RS-422/485/530 only) Check to enable only when measuring the V.35 interface using the V.35 monitor cable “LE- 25M34”.

  • Page 33: Communication Condition Settings

    2.4 Communication Condition Settings Select “Conf iguration” from the top menu screen. On the displayed screen, set the basic communication conditions according to the communication conditions to be tested. Tap each item to select it, or enter it with the [0] to [F] and [X] keys.
  • Page 34 Communication Speed Set the communication speed of target devices. For simulation function, it is able to check the tolerance of target device by setting the different speed on purpose. ‫ ڦ‬TXD speed S e t t h e c o m m u n ic a t io n s p e e d of transmission line.
  • Page 35 Details of Each Protocol Setting Each protocol has different settings. 〇 ASYNC ‫ ڦ‬Data code Select a data code from ASCII, EBCDIC, EBCDIK, JIS, EBCD, Transcode, IPARS, Baudot and HEX. For some data codes, it changes the character by SHIFT control. “JIS7”...
  • Page 36 ‫ ڦ‬End code Set the block error check calculation end character in hexadecimal. 03h and 17h are preset at the time of shipment. Please note that bits higher than the data bit length set in “Data bit” are regarded as invalid. ‫...
  • Page 37 〇 SYNC/BSC (Character SYNC) ‫ ڦ‬Data code Same as ASYNC. 9.4 Data Code Chart ‫ ڦ‬Data bit Set a data bit length. Only the bit length allowed for each data code can be set. Total bit of data bit and parity should be 6 or 8. ‫...
  • Page 38 ‫ ڦ‬Suppress code Set a suppress code in HEX. When codes set in this section are monitored continuously, the second byte and after ones are not recorded in the capture buffer. ‫ ڦ‬BCC Same as ASYNC. ‫ ڦ‬Bit sequence Set a bit sequence. For general protocols, select “LSB first”. ‫...
  • Page 39 ‫ ڦ‬Idle mode for simulation Select an idle state (“Mark” or “Flag”) between frames. ‫ ڦ‬Leading flag for simulation Set the number of transmission starting flags from 1 to 10. The initial value is 1. When phase-aligning the receive clock with data in normal mode, multiple flags must be output for synchronization alignment.
  • Page 40 Half-duplex Mode ID Filter Setting Monitor Screen Display Don't care settings for both TXD TxD is displayed on the TXD side and and RXD addresses RxD is displayed on the RXD side. Set all RXD addresses to don't Only those that match the ID filter of care, TXD addresses to non- TxD are displayed on the TXD side.
  • Page 41 〇 ASYNC-PPP ‫ ڦ‬Data code Select a data code from ASCII, EBCDIC, EBCDIK, JIS and HEX. When selecting “ASYNC-PPP”, it automatically sets “Data bit: 8”, “Parity: none” and “Stop bit: 1”. 9.4 Data Code Chart ‫ ڦ‬FCS Select a frame checking sequence (error check) type from “None”, “FCS-16” or “FCS-32”. 9.1 Calculation of the Block Check ‫...
  • Page 42 ‫ ڦ‬Slave address Set the address of analyzer in HEX during slave simulation. b9 b8 b7 b6 b5 b4 b3 b2 b1 b0 Input data A7 A6 A5 A4 A3 A2 A1 7-bit address A9 A8 A7 A6 A5 A4 A3 A2 A1 A0 10-bit address (Exp.) Input 123 (0100100011b) 7-bit address is “0010001”...
  • Page 43 ‫ ڦ‬Frame end time This setting is necessary only for high-speed mode. Set the SPI frame end time (resolution: 0.1 μs). In the case of SS signal is not changed every frame, it is recognized as the frame end when clock signal has not changed during the set time.
  • Page 44 MODBUS ‫ۑ‬ ‫ ڦ‬Transmission Select a transmission mode from “ASCII” or “RTU”. RTU: If there is a frame with 3.5 characters or more of silent interval (non-communication time), the last second byte is recognized as CRC error check code. Data structure of ASCII: Begin code (“:”(3Ah)), + Data (“0”(30h) ~ “9”(39h), “A”(41h) ~ “F”(46h)), + End code (“CR”, “LF”(0Dh, 0Ah)).

  • Page 45: Connection

    2.5 Connection Connect to RS-232C To measure RS-232C, select “RS-232C” from “Interface” -> “Measurement port”. 2.3 Measurement Port ‫ ڦ‬For monitoring Either is Dsub 25 pin connector Dsub25 MONITOR Cable RS-232C Port If the connector of either target device is Dsub 25 pin, use attached DSUB 25 pin monitor cable (LE-25M1) to connect to the analyzer.
  • Page 46 Both Dsub 9 pin connector Dsub9 DSUB25-9 MONITOR Cable (conversion (Dsub9pin ) adapta) RS-232C Port If the connectors of both target devices are Dsub 9 pin, use attached DSUB 9 pin branch cable (LE009M2) and DSUB 25-9 conversion adapter to connect to the analyzer. [ Connection of LE-009M2 and DSUB25-9 adapter ] ( ) is the pin number.
  • Page 47 Connect to RS-422, RS-485 To measure RS-422/485, set “Measurement port: RS-422/485” at “Interface” setting. 2.3 Measurement Port If the RS-422/485 connector (or terminal b l o c k ) o f t a r g e t d e v i c e u s e s u n i q u e specification, check the signal assignment carefully.
  • Page 48 Connections with RS-530, X20/21, RS-449 and V.35 devices. Set “port” to be “RS-422/485/530” in the “Interface” setting. 2.3 Measurement Port X.21 Device X.21 Device RS-530 Port X.21 monitor cable Various legacy serial protocols are able to monitor by using the following optional cables. Also, use this port to measure RS-422 line with control signals such as RTS and CTS.
  • Page 49 Connect to TTL To measure UART, I2C and SPI, set “Measurement port: TTL (5.0V) ~(1.8V)” at “Interface” setting. 2.3 Measurement Port Connect appropriate signals to the TTL port of analyzer using the attached 5-line TTL probe cable (model: LE5LS). TTL port is 2.54mm pitch 10 pin MIL box type connector. Use the one equivalent to “HIF3FC-10PA-2.54DS(71)”...
  • Page 50 < Example of connection for ASYNC > Lead Input/Output Signal of target device Signal Monitor Simulation Monitor Simulation wire Brown Orange Yellow Green Signal GND Signal GND < Example of connection for SYNC/HDLC > Lead Input/Output Signal of target device Signal Monitor Simulation...

  • Page 51: Connection And Setting Of Time Stamp Synchronous Function

    2.6 Connection and Setting of Time stamp Synchronous Function The timestamp synchronization feature has the following connections. 2.2.3 Record Control ‫ ڦ‬Synchronize by GPS antenna Synchronizes the LE-8500X-RT's time stamp using GPS antenna a GPS active antenna. Connector for GPS antenna Then optional GPS active antenna is needed.

  • Page 52: Chapter 3 Monitor Function

    Chapter 3 Monitor Function 3.1 Online Monitoring (ONLINE) The monitor function records measured data in the capture buffer without impacting on a communication channel. Also, it displays data clearly following each communication protocol. Not only communication data but also the time stamp and idle time are recorded. As a result, error time and time out conditions can be investigated.
  • Page 53 Operation To start measurement, press [RUN]. Then, data will be recorded in the capture buffer while displaying data on the screen. Transmission and reception data is displayed in two lines as one set. “ ” is the mark which indicates the place of new data. Stop Renewing Display When [ESC] key or “Pause display”...
  • Page 54 Character Errors and breaks are displayed in unique characters. Character Description Parity Error (parity bit error) Framing Error (stop bit is “0”) Parity & Framing Error Break (start bit, character bit, (parity bit), stop bit are all “0”.) Abort (7bits or more of “1” is continuously detected) (*1) Shart Frame (frame length is short) Block check code normal (BCC or FCS is normal)
  • Page 55 Change Display Code Once start measuring, data is displayed in selected data code set in the configuration setting. Touch the current data code (“ASCII” in the figure) to display in different data code. Tap “HEX display” to change the display code.
  • Page 56 ● For High-speed mode 100us 10us Set the resolution of time stamp in the “Record control” (additional information tab). 2.2.3 Record Control It consumes 4bytes to record the time stamp of “D/H/M”, “H/M/S”, “M/S/10ms” in the normal mode. And, it consumes 8 bytes for other settings and in the high-speed mode. ‫...
  • Page 57 Change Display Format Following data display types can be changed by “Change display” key. It will return to the “Data display”. <Data display> It displays raw data. <Frame translation display> It displays translated data set in the “protocol translation display”. 3.1 Online Monitoring (ONLINE) Protocol Translation Display <User defined translation display>...
  • Page 58 Line state display Status of control lines (RTS, CTS, DCD, DTR, DSR, RI) and trigger input (TRG) can be displayed in waveform. Control lines are displayed as high level when the line state LEDs light in read. Signal status of external trigger input terminal is displayed in the “TRG”. <Line state display>...
  • Page 59 Scroll and Jump ‫ ڦ‬Scroll Swipe the data to scroll measured data. Swipe down the display to see backward (old) data. Swipe up the display to see forward (new) data. Also, use keys to scroll data, and [SHIFT]+ [▲]or [SHIFT]+ [▼]to jump to another page. ‫...
  • Page 60 Mark & Jump It is able to register (mark) max. 9 positions of data. This function is useful to go back to the registered (marked) positions when you have a huge amount of data. Register the data position by [SHIFT] + [1]- [9].
  • Page 61 Specification of Frame Translation for SDLC, SDLCE, X.25, X.25E Item Meaning Time stamp Shows the time when the frame was received. Displays the contents of the address field in HEX codes. Type Displays the frame type in the form of mnemonic. Displays the frame sequence number with the decimal notation.
  • Page 62 Specification of Packet Translation for LAPD Item Meaning Time stamp Shows the time when the packet was received. Displays the protocol identifier with the hexadecimal notation. Displays the contents separately for message type in the form of Message mnemonic. Displays the value of nominal number flag. Displays the value of nominal number with HEX.(Maximum 2 octet) Displays the results of frame check.
  • Page 63 □ MODBUS Frame dump display and translation display (only address/control on top of frame) is possible. Touch “MODBUS” on the bottom of screen and select “Dump” or “MODBUS”. It is able to change the specification of Translation display anytime. (during test too) Item Meaning Time stamp...
  • Page 64 ・ Detail view “Detail view” is available after the measurement (not available while measuring). “Detail view” displays data conformed to the Power Meter “KW1M (by Panasonic)”. It translates the frame on top of the screen. “Request/Response” function translates the frame as “Response”...
  • Page 65 ・ Modbus Translation display Press [SHIFT] key and “Display control”-> “Modbus detail view” -> “Setting”. Define the slave address up to 16 kinds. Input the slave address and character to be displayed. To valid the table, mark on the check box. If selecting more than two check boxes for same address, the younger number will be applied.
  • Page 66 □ I2C It translates data using some arrows to explain the data flow. Item Meaning Time stamp Shows the time when the frame was received. Transmission data of master. ⇒ Reception data of master. ⇐ etc. Non-acknowledge data. Address/Data Display the slave address and data in HEX. □...
  • Page 67 Display item Display contents TXD/RXD Indicates the port in which frame is received. Time stamp Indicates the time when frame is received. Displays the Destination address in decimal. DSAP Displays the Destination service access point in decimal. Displays the source address in decimal. SSAP Displays the Source service access point in decimal.
  • Page 68 Bit Shift Function This function shifts the separation of characters of received data bit by bit, to find errors such as deviations from the character synchronization of serial data. When the characters are displayed on the data display, press [SHIFT]+[ ] .Then, the character separation is shifted one bit from the lower bit to the upper bit.

  • Page 69: Retrieval Function

    3.2 Retrieval Function The retrieval function finds specific data among the vast amount of data recorded in the capture memory. It also counts the number which satisfies a particular condition. Retrieval Setting Touch “Search” on the bottom of screen and select the factor at “Search factor”. ‫...
  • Page 70 ‫ ڦ‬Idle Time It cannot be used for high-speed mode. Retrieve idle time which exceeds the set value. The u nit of idle time for ret r ieval should be the same unit of idle time when it is measured. To retrieve the data with timeout, input the timeout time here.

  • Page 71: Delay Time And Signal

    3.3 Delay Time and Signal Voltage (DELAY) Delay time function measures the delay time between state changes of the interface signal, and measures the voltage (Max./Min./Current) of the signals on RS-232C/422/485. It cannot be used for high-speed mode. Setting Press “Mode” -> ”Delay”-> ”Delay Opt.” from top menu to set the start/stop conditions of delay time measurement.
  • Page 72 Start and End of Measurement Press [RUN] to start measuring of delay time and signal voltage. Press [Stop] to stop measuring. ‫ ڦ‬Display of signal voltage Measure voltage of target interface and display signal voltage (MAX. MIN. Now). Target signals For RS-232C port TXD,RXD,DTR For RS-422/485,RS-530 port...

  • Page 73: Statistic Analysis Function (Trend)

    3.4 Statistic Analysis Function (Trend) The statistical analysis function is capable of counting the occurrence of the events such as the number of characters and frames in a specific period, and displaying the results on graph to check how the occurrence of them changes over time. This function is useful to check the frequency of the use of a channel.
  • Page 74 Start and End of Measurement Press [Run] to start measurement. As a number of times of statistical processing passes, the results of calculated value are updated on a graph. A vertical scale is automatically adjusted according to the results of data. Press [STOP] to stop measuring.

  • Page 75: Chapter 4 Simulation Function

    Chapter 4 Simulation Function The simulation function is the tool that makes the analyzer operating as a communication partner with a test device, and that executes a test for transmission and reception following protocols. Even if communicated devices are not prepared at the first step in developing, the testing like real operation will be able to be executed.

  • Page 76: Register Transmission Data

    4.1 Register Transmission Data Register transmission data in the data tables before starting simulation. For Polling/Program mode, this registered data is used as comparison data with received data. Register data Data code and BCC/FCS used in the registration table are set on the configuration setting. Press [MENU] and then touch “Configuration”...
  • Page 77 On top of the screen, table number, position of cursor, and rest of buffer (remained bytes) on the transmission data table are displayed. A cursor position on the screen where under-line is blinking is the place to input data. Move the cursor position by [ ],[ ],[▼],[▲] or touch the place.
  • Page 78 ‫ ڦ‬Parity Error and MP Bit Setting By tapping “Set/Cancel Parity/MP/”, the data at the cursor position will be added with the attribute of parity error or multiprocessor bit 1 and it will turn red. Perform the same operation again to return to the original.
  • Page 79 Data Editing Method ‫ ڦ‬Copy, cut and paste If you long-t ap or press [ENTER] anywhere in the data to be sent, it enters into the range selection mode with the data at that location selected. The selection range can be changed by dragging the selection edge or by [ ], [ ] operations.
  • Page 80 ‫ ڦ‬Fill in data Select “Edit Optoin” from “Data fill” and enter start/end data and size. Begin data< End data : A character from “Begin data” toward “End data” will be inputted increasing one by one till the number of size set in “Fill size” is filled.
  • Page 81 Fixed Transmission Data (Pre-set data) Special characters like ENQ, ACK, etc. can be inputted. Preset data can also be input by tapping the display shown when [SHIFT] is pressed, or by operating the keys described in the table below. [SHIFT]+[0] [SHIFT]+[7] [SHIFT]+[1] [SHIFT]+[8]...
  • Page 82 Register I2C Simulation Data To receive data, it is necessary to register the same amount of dummy data. □ I2C Master Mode At first, set the slave address (including a read/write bit) and then set transmission/reception data. Start/stop sequence are added automatically at the beginning and end of data. To receive data, it is necessary to set the same amount of dummy data.
  • Page 83 □ I2C Slave Mode Set the transmission data to send after receiving a request from the master. To receive data, it is necessary to register the same amount of dummy data. Registered data (more than 1byte) is used repeatedly when it receives data from the master, and when it transmits data after receiving a request from the master.

  • Page 84: Rs-422/485 Driver Control

    4.2 RS-422/485 Driver Control Select the method of controlling RS-422/485 transmission driver IC for simulation on RS-422/485 port. Select “Interface” from the top menu screen, select “RS-422/485/530” from “Measurement port”, and set the method of “Driver control”. 2.3 Measurement Port ‫...

  • Page 85: Auto Line Control

    4.3 Auto Line Control ON/OFF of control lines and timing of data transmission can be controlled automatically according to the setting of interface mode (DTE/DCE) for simulation. “ON” means active, and “OFF” means non-active. Select “Interface” from the top menu screen, select ‟RS-232C”...
  • Page 86 〇 DCE mode Set the timing of following item in the range between 0 and 9999 ms. ‫ ڦ‬CTS on Time between RTS becomes “ON” and CTS becomes “ON”. ‫ ڦ‬CTS off Time between RTS becomes “OFF” and CTS becomes “OFF”. ‫...

  • Page 87: Manual Mode

    4.4 Manual mode Data in the data table corresponding to each key will be transmitted by pressing a key. Setting Before starting the Manual simulation, set protocol and communication conditions in the ‟Configuration”, and register transmission data in the data table. 2.4 Communication Condition Settings 4.1 Register Transmission Data Select “Manual”...
  • Page 88 Operation Press [RUN] and it will be in a wait state till a key corresponding to the transmission data table is entered. □ When the analyzer is DTE mode After starting the measurement, RTS and DTR become active. If using the Auto signal control, RTS and DTR change their status according to the setting.

  • Page 89: Buffer Mode

    ‫ ڦ‬Repeat transmission When ON is set to “REPEAT”, data corresponding tables will be transmitted continuously spacing idle time. To stop this operation, press [TOP/DEL] or select a data table with no data. Press [STOP] to finish testing. ‫ ڦ‬Data that does not require registration The parity bit, SYNC and BSC protocol SYNC codes and synchronization release codes, and HDLC and SDLC protocol start and end flags are automatically added and sent, so there is no need to register them in the send data table.
  • Page 90 Setting Select “Buffer” from “Mode” on the top menu screen and tap “Buffer Opt.” to display the detailed settings screen for this function. Set the flowing items below. Items Description Range of Selection BUF1-TXD:Data side of TXD BUF1 TXD BUF1-RXD:Data side of RXD BUF1 RXD Send data BUF2-TXD:Data side of TXD...

  • Page 91: Flow Mode

    Operation Press [RUN] and data in the selected buffer on the TXD or RXD will be transmitted from the oldest data. Data is transmitted by one frame unit continuously spacing “Idle time”. ‫ ی‬Limitation of operation ・ If one frame contains more than 4K characters, analyzer divides its data and sends the first 4K characters.
  • Page 92 ‫ ڦ‬Test Mode Select “Send” if analyzer becomes the transmitter. Select “Receive” if analyzer becomes the receiver. ‫ ڦ‬Initial Initial state of flow control at the begging of test. Off : Prohibit transmission On : Allow transmission ‫ ڦ‬Control Select the control method. Char : X-ON/X-OFF character Line...
  • Page 93 ‫ ڦ‬On counter The number of a reception character until interruption request is transmitted. (1~999999) ‫ ڦ‬Off time Time between interruption request and re-transmission request. (0 to 99999ms) Operation Press [RUN] to start the flow control test. ‫“ ۑ‬Send” with X-ON/X-OFF flow control 1) When the analyzer is DTE mode, RTS and DTR will become active.
  • Page 94 ‫“ ۑ‬Receive ” with X-ON/X-OFF flow control 1) When the analyzer is DTE mode, RTS and DTR will become active. When the analyzer is DCE mode, CTS, DSR an DCD become active. 2) If the “Initial state” is “ON”, it will start the data transmission immediately. If the “Initial state”...

  • Page 95: Echo Back Test (Echo Mode)

    4.7 Echo back test (ECHO mode) The echo back test is the function that makes received data repeatedly transmitted from the analyzer. This is not available for the high-speed mode. This function cannot be used if protocol is set to I2C, SPI or Burst at ‟Configuration” setting. 2.4 Communication Condition Settings Setting Select “Echo”...
  • Page 96 Operation Press [RUN] to start the loop-back test. ‫ ڦ‬Buffer Return the received data per a frame accord i ng to t he ‟Con f ig u r at ion” setting. If it receives a new frame while it is in the “Response time” after receiving 1 frame, it can record max.

  • Page 97: Polling Mode

    For RS-422/485 DCE (Terminal 5pin) DTE (DSUB25pin) TXD +- c o n n e c t e d i n RXD+- RXD+- c o n n e c t e d i n TXD +- internal circuit internal cir In this case, full-duplex connection is used, so set “Driver control” in the interface settings to “Off”.
  • Page 98 Slave mode In the slave mode, analyzer works as a slave station. When a station address is received, response message will be returned. 　 　　◆ Set following conditions Item Description Range of Selection Address Station Address Within eight characters in HEX Response Delay Time 0 ～...
  • Page 99 Master mode In the master mode, analyzer works as a master station. And it transmits a polling message to each st at ion add ress, a nd analyzes returned data. ‫ ڦ‬Response Set t he t i me bet we e n re ceiv i ng a message from slave station and sending a response message.
  • Page 100 [Error ⇒ X] When communication errors are generated in response message from slave station, selected transmission data table will be transmitted from the analyzer. Protocol Description of Error Checking ASYNC Parity Error, Framing Error, BCC Error SYNC ･ BSC Parity Error, BCC Error HDLC ･...
  • Page 101 <Operation> 1) Press [RUN] and control lines (RTS/CTS for DTE mode. CTS/DSR/DCD for DCE mode) become active. And then, polling simulation starts. 2) It operates corresponding to setting conditions and response from slave station like below. The number of REPEAT times -1 Next station No.

  • Page 102: Program Mode

    3) It displays the result of each slave station. Swipe the screen or press [▲],[▼]to display all data. Touch “Change display” to go back to normal monitored data display. OK-Msg : The number of received times for response message from slave station which matches compared data of response map.
  • Page 103 ‫ ڦ‬Transmission data table Register transmission data table before starting the program simulation used for SEND TBL command and IF TBL command. 4.1 Register Transmission Data ‫ ڦ‬Timer There are four timers of “TM 0-3'' that are used when creating programs such as timeout processing using the IF TM command.
  • Page 104 Program input Before starting the Program simulation, set the protocol and communication conditions in the “Configuration”. 2.4 Communication Condition Settings Select “Program” from “Mode” on the top menu screen and tap “Program Edit” to display a screen to select a program (A to D). Select one of them and tap “Edit” to display the program input screen.
  • Page 105 〇 Input Method ‫ ی‬Command Field Touch or press [0]~[C] to select a desired sub-command (SEND, WAIT, IF commands etc.) or [TOP/ DEL] to delete commands. After deleting a command, the following commands comes up instead and NOP command is added at the end. ‫...
  • Page 106 ‫ ۑ‬Save program Programs A to D that you created do not disappear even when the power is turned off. If you want to create more programs and select and use them, use a storage device to save and load them as setting data files.

  • Page 107: Commands For Program Mode

    4.10 Commands for Program Mode Command Operation 0 NOP No Operation. Go to next step. SEND CHR □□□□□□□□ Data communications up to 8 characters. SEND TBL □□ Data transmission of the specified data send table. Data communications of the transmission data table specified by a SEND REG □...
  • Page 108 If the frame stored in the receive frame buffer matches the specified 4 IF FT □□□□ L □□□ type, it branches to the line where the specified label is defined. 5 CALL L□□□ Jumps to a subroutine marked with a specified label number. 6 RET Returns from the subroutine.
  • Page 109 NOP Command (Invalid Command) The NOP command, which is displayed as “,” is the command that has no impact on the program execution. <Entering> Cursor Position Enter & Operation Command Field Sub-Command Field Operand Field <Operation> ・ When the program is running, the NOP command is ignored and the instruction of the next line number is executed.
  • Page 110 3 ) SEND REG□ GRP□ (Register-Specified Data Table Transmission Command) <Entering> Cursor Position Enter & Operation Command Field Sub-Command Field Enter a register number with [0] to [F] keys and a table group Operand Field number with [0] to [9] keys. By [END/X]:* (Don't care), all the groups will be the target.
  • Page 111 6 ) SEND DA□□+REG* (Data Array Transmission Command) <Entering> Cursor Position Enter & Operation Command Field Sub-Command Field Enter two digits of a data array number with the key, 0 to 9. Operand Field Enter a register number with the key, [0] to [F]. Offset cannot be set by [END/X]: “*”...
  • Page 112 7 ) SEND BRK (Break Transmission Command) <Entering> Cursor Position Enter & Operation Command Field Sub-Command Field Operand Field <Operation> ・ Transmits a break. (ASYNC mode only) 8 ) SEND FRM □□□□□ TBL □(Transmits a X.25 frame) <Input> Cursor Position Enter &...
  • Page 113 WAIT Command (Command to Halt Program Execution) The WAIT command is used to halt the execution of a program until the particular conditions are satisfied. If the “INT TRG” command interrupts this command, a wait state is canceled. 1 ) WAIT CHR□□□□□□□□ (Command to Wait for Character Reception) <Entering>...
  • Page 114 3 ) WAIT TRG□ (Command to Wait for Satisfaction of Trigger Conditions) <Entering> Cursor Position Enter & Operation Command Field Sub-Command Field Enter a trigger number with the key, 1 to 3 (Trigger 0 is not Operand Field selectable). <Operation> ・...
  • Page 115 7 ) WAIT MLT command < Input> Cursor Position Enter & Operation Command Field Sub-Command Field Operand Field < Action> ・ Consecutive WAIT commands are executed at the same time. During the WAIT commands executed at the same time, all wait states are canceled when any of the conditions are met. ・...
  • Page 116 GOTO Command (Designated Label Number Branch Command) The GOTO command branches the program control unconditionally to designated label number. GOTO L□□□ <Entering> Cursor Position Enter & Operation Command Field Sub-Command Field Enter a label number in three digits decimal figures with the key, Operand Field [0] to [9].
  • Page 117 Factor Judgment Content Error Data in the frame buffer is checked to see if the conditions are satisfied. Character The conditions are checked to see if it is satisfied when the Line state command is executed. Does not perform anything. The next command is executed Timer/Counter unconditionally.
  • Page 118 6 ) IF REG□ □ REG□ L□□□ (Judgment Command on Register Value) <Entering> Cursor Position Enter & Operation Command Field Sub-Command Field Operand Field Input the inequality by 0 : = , 1 : ≠, 2 : <, 3 : > , 4 : ≤, 5 : ≥ Operand Field Enter the label number in three digits decimal figures with the key, [0] to [9].
  • Page 119 <Action> ・ When the frame stored in the receive frame buffer matches the specified type, it branches to the line where the specified label is defined. (Specify one of “INFO”, "RR”, “RNR”, “REJ”, “DM”, “SABM”, “SABME”, “DISC”, “UA”, or “FRMR”) ・...
  • Page 120 <Operation> ・ The content of the register specified in the operand field is changed. Register Preset Value Setting Condition Six Digits Decimal Figure The preset value is entered in the register. 1 is added to the register contents “INC”. 1 is subtracted from the register contents “DEC”. ・...
  • Page 121 4 ) SET CT□ □□□□□□ (Counter Control Command) <Entering> Cursor Position Enter & Operation Command Field Sub-Command Field Enter a counter number with the key, [0] to [3]. Enter a preset value of the counter in six digits decimal figures Operand Field with the key, 0 to 9.
  • Page 122 <Operation> ・ The specified character strings are set to the data array of the designated number. 8 ) SET DV□□ REG□ □ (Data Array Setting Command) < Input> Cursor Position Enter & Operation Command Field Sub-Command Field Operand Field: Specify 2 digits of data array number with the key, 0 to 9.
  • Page 123 < Action> ・ Set the value of the address part of the frame to be sent by the SEND FRM command. SET AD nnH Sets the constant value specified at the address. SET AD REGm Sets the value of the register specified at the address. If the value of the register is 256 or more, the remainder obtained by dividing that value by 256 is set.
  • Page 124 13 ) SET PF □ <Entering> Cursor Position Enter & Operation Command Field Sub-Command Field Operand Field Input the setting value with 0 or 1 <Operation> ・ Set the value of the P/F bit of the frame to be sent with the SEND FRM command. 14 ) SET DP □□□□...
  • Page 125 INT Command (Trigger Interrupt Command) The INT command monitors whether or not the conditions of trigger 0 are satisfied while the program is running. And when the conditions are satisfied, the program control branches to the designated label number. INT TRG0 L□□□ <Entering>...
  • Page 126 RETI Command (Trigger Interrupt Reset Command) The RETI command returns the program control to the main routine from a subroutine which the program control is branched to by the INT command. RETI L□□□ <Entering> Cursor Position Enter & Operation Command Field Sub-Command Field Operand field: input 3 digits of label number with the key, 0 to 9.
  • Page 127 LBL Command (Command to Define Label) The LBL command defines the destination of a branch command. L□□□ <Entering> Cursor Position Enter & Operation Command Field Sub-Command Field Enter a label number in three digits decimal figures with the key, 0 Operand Field to 9 <Operation>...
  • Page 128 L004 SEND TBL02 ･････　 Transmits data in the data table 02. RETI L005 ･････　 Branches to the end of the program. ’ L005 STOP <Other setting > Data table 01:0123456789 Data table 02:NG Data table 03:TIMEOUT Factor of trigger “0”: Timer/Counter Timer/Counter setting: Timer 0, comparison value: 3000, resolution: 1ms Factor of trigger “1”: error <...

  • Page 129: Pulse Generator Mode (Pulsgen)

    4.11 Pulse Generator Mode (PULSGEN) Generate the waveform measured by the Timing waveform function. Also, it can edit the data and have various kinds of tests, such as sending at different timing. Preparation Measure and record the waveform using the Timing waveform function, which you would like to generate later.
  • Page 130 2) Insertion ▶ Tap “Shift Mode” to enter shift mode, then press [ ] to insert the same signal (1 timing) on the right side of the cursor. Before insertion After insertion 3) Deletion Tap “Shift Mode” to enter shift mode, then press [ ◀...
  • Page 131 5) Setting the waveform data output clock On the waveform edit screen, tap the waveform data output clock to select it. 6) Repeating output setting On the waveform edit screen, tap Repeat to select it. When Repeat is selected, waveform data will continue to be sent repeatedly. Operation Press [Run] to reproduce the waveform data according to the waveform data output clock settings on the waveform edit screen.

  • Page 132: Chapter 5 Bert Function

    Chapter 5 BERT Function The analyzer has the function to send a test pattern and the function to compare the received data with the test pattern. By a loopback test or a face-to-face test, the quality of the data communication line including the modem etc.
  • Page 133 End-to-End Test The end-to-end test is a test in which a device with the BERT function as this unit has is connected to the other party and the same test pattern is sent and received each other. This test allows you to evaluate the transmit line and receive line separately. Setting of Test Mode The BERT function works in either asynchronous or synchronous communication.
  • Page 134 ‫ ۑ‬W h e n t e s t i n g s y n c h r o n o u s communication Set the protocol “SYNC / BSC”. It is tests at the speed set by “TXD speed” and “RXD speed”, and the test pattern is sent and received by the synchronous clo c k s p e c i f ie d by “...
  • Page 135 ‫ ڦ‬Pattern Select the test pattern data to be sent/ received. Name Content - 1 ( Generator polynomial X + X + 1 ) Random code - 1 ( Generator polynomial X + 1 ) Random code 2047 - 1 ( Generator polynomialX + 1 ) Random code PN15 - 1 ( Generator polynomial X...

  • Page 136: Start And Stop

    5.2 Start and Stop When you press [RUN], it starts to transmit the test pattern and compares the received data and the test pattern. Initially, until the initial pattern of the test pattern is received and synchronization is established,‟ SYNC Search” message is displayed. After synchronization is established, “Measuring” message is displayed and error rate measurement starts.

  • Page 137: Contents Of The Line Quality Data

    If “Repeat” is selected at “Test mode”, it displays measured data where the cursor is pointed at. Move the cursor by [ ],[ ] to change the data displayed. Swipe the graph to change the range of data. 5.3 Contents of the Line Quality Data You can measure the communication error rate with parameters which comply with ITU-T Recommendation G.821.

  • Page 138: Chapter 6 Useful Functions

    Chapter 6 Useful Functions 6.1 Trigger Function The trigger function is a function that triggers a special measurement process (action) triggered by a specific condition (factor) such as the occurrence of a communication error during measurement operation or reception of specified data. By controlling the timer/count, it can measure the communication response time and count the number of occurrences of specific events.
  • Page 139 External trigger input/output You can use an abnormal signal from an external device as a trigger input, or can detect the occurrence of a special factor on the communication line by this analyzer and notify it to an external measuring instrument such as an oscilloscope. TTL port The TRG IN terminal can be specified as the line state condition of the trigger factor.
  • Page 140 Trigger Factor For normal mode, select a trigger factor for Trigger0 to Trigger7. For high-speed mode, select a trigger factor from “TXD character”, “RXD character”, “error” and “TRG IN”. Other setting items cannot be set (grey out). □ Error A specific condition such as error or break are treated as a trigger condition.
  • Page 141 □ Line state (for Normal mode), TRG IN (for High-speed mode) For high-speed mode, low level of TRG IN is the trigger condition. For normal mode, the conditions of the control line and TRG IN are treated as the trigger condition. Specify the signal logic to detect with 1(High), 0(Low), and X(don't care).
  • Page 142 Trigger Action For normal mode, select any trigger actions for Trigger0 to Tigger7. For high-speed mode, select a trigger action from “Stop measurement” or “OT2 pulse output” for Trigger0 to Tigger3 (trigger action cannot be set for each trigger). □ Buzzer This setting is available only for normal mode.
  • Page 143 □ Save data T h is set t i ng is available on ly for Normal mode. The measurement data before and after the trigger factor match is automatically saved in the storage device as a trigger save f ile (TGSAVEnn.DT - nn is a serial number from 0 to 99 in the order of saving).
  • Page 144 □ Trigger control This setting is available only for normal mode. Specify the trigger to be controlled (Trigger0 to Trigger7), disable/enable, change the stat us (reverse enable/ disable from the current status) of it. A trigger that is invalid at the start of measurement can be enabled by another t r igger when it detect s a specif ic condition during the measurement (sequential trigger).
  • Page 145 Trigger Setting Example Example of trigger setting (in normal mode): ♦ When a communication error occurs, the buzzer sounds and the number of error occurrences is counted Enable trigger 0 and 1 and set Error as the factor and Buzzer and Counter control (increment) as the action.

  • Page 146: Timer/Counter Function

    6.2 Timer/Counter Function The timer/counter function is used together with the trigger function and program simulation function to measure the elapsed time from a specific condition and the number of occurrences of a specific factor. Timers are used to measure the elapsed time after the occurrence of specific factor. Counters are used to count the number of times which a specific factor occurs.

  • Page 147: Timing Waveform Measurement

    Counter action 1) Cleared to 0 at the start of measurement. 2) It is incremented (+1) or cleared by the control information from the trigger function. 3) When the set value (comparison value) of counters 0 and 1 and the current value of counters 0 and 1 match, that information is passed to the trigger function.
  • Page 148 ‫ ڦ‬Trigger position Tap the item to select the trigger position of the waveform monitor. Set the trigger position in the waveform monitor sampling memory (for 2K sampling) depending on which part of the waveform measurement data -before or after the trigger- is prioritized. Before : Captures some data from the trigger point and then stops.
  • Page 149 Control 1) Press [RUN] to start timing waveform measurement at the same time as the normal measurement function starts. “ ” Is displayed in the upper left of the screen. 2) When the waveform monitor trigger condition is met and the timing waveform sampling is completed, “...
  • Page 150 ‫ ڦ‬Time measurement between two points On the screen, the blue dotted line is cursor C and the red dotted line is marker M. First, move the cursor to the first signal position with [ ], [ ], and touch [ENTER] or “Mark”...

  • Page 151: Auto Configuration Function

    6.4 Auto Configuration Function By using this function at online monitoring, you can automatically determine the communication conditions of the line to be monitored and start the measurement. How to use Connect appropriate monitor cables to the target port and set the measurement port (“Interface”-> “Measurement port”).

  • Page 152: Split Display

    6.5 Split Display ‫ ڦ‬Split Display Display data in two separated screen Display saved data in BUF1 and BUF2 in the separated screen at the same time. It is useful to compare two data for finding a problem. 1) Save data in BUF1 or BUF2. S e l e c t B U F 1 o r B U F 2 f r o m “Record cont rol”...

  • Page 153: Translation Function

    6.6 Translation Function User Translation Definition Function ‫ ڦ‬The outline of User Translation Definition Function Field 1 Field 2 Field 3 Field 4 User Translation Definition Function is the f u nct ion that t ranslates the frame data of communication into the character strings or numbers according to the rule defined by user.
  • Page 154 ‫ ڦ‬Procedure of setting User's defined translation 1. Tap “Display Control”. ● User Translate Mark on the check box of “User Translate”. ● Field1-4 Name “ F i e l d 1 - 4 N a m e ” w i t h 6 characters.
  • Page 155 3. Select the No. by moving the cursor with [▲][▼], and press [Enter]. Or tap the item to edit in the translation definition display. Set the condition on which the measured frame is translated and displayed in the raw of Field1 to Field4.
  • Page 156 ● String Set how to translate data “1” to “4” into characters. you can set up to 6 characters. When nothing is set, the data is displayed in HEX. ● Bit Mask Set bit mask(Bit7 to 0) of Data1 to 4 to specify in bit unit. You can set “Bitmask”...

  • Page 157: The Data

    An SD/SDHC card or USB flash drive can be used as a storage device, and measurement data and setting data can be saved to it. Optional SDHC cards (SD-8GX, SD-16GX, SD-32GX, sold by LINEEYE) are available. You can use a USB flash drive, but we do not guarantee the operation of all USB flash drives.

  • Page 158: File Management Function

    7.2 File Management Function You can save, read, and delete the measured data and setting data in the storage device as a file that can be read/written by a PC. Set the storage device to this device and tap “File Manager” at the bottom of the screen to display the directory screen.
  • Page 159 Save setup W hen you touch “Save set up” on t he directory screen, the full key image and the text input window will be displayed on the screen. Touch the full key on the screen to enter the file name, and then touch “OK” or press [ENTER] to save all setting data of the top menu and return to the directory screen.
  • Page 160 ‫ ی‬Filter Tap “ ” on the directory screen to display only the specified file type. The following file types can be specified for the filter display. All files Analyzer measurement data file and setting data fil Analyzer setting data file Analyzer measurement data file File automatically saved by the trigger function (TGSAVEnn.DT) File automatically saved by the auto save function (#nnnnnnn.DT)
  • Page 161 ‫ ی‬Loading the file in subdirectory On the directory screen, double-tap the subdirectory that contains the file you want to read (hereinafter, the folder), or tap it or select it with [▼] or [▲] and then tap “Open” to display the files in that folder. Select the file and execute the load operation. Select “...
  • Page 162 ‫ ی‬Batch deletion of multiple files To delete multiple files at once, long-tap (touch for about 1 second) any file on the directory screen to display the file selection display. Tap the file you want to delete (or select it with [▼] or [▲] and press [ENTER]), and a checkmark will be added to the file.

  • Page 163: Chapter 8 Utiltty

    The PC Link software offers remote monitoring and conversion of measurement data to text files on a PC. The “lite version” with some restrictions can be downloaded free of charge from the LINEEYE website. * The PC link software for LE-8500X-RT will be released in November 2022 Unzip the downloaded file and execute setup.exe in the folder.
  • Page 164 [Example of Remote Monitor Screen] [Example of text conversion] -162-...

  • Page 165: Capture Data Files While Measuring

    How to use 1. Download and unzip the “LE file downloader (lefiledownload.exe)” of ver.1.04 or later from LINEEYE website to an appropriate folder on the PC. No installation required. 2. Make sure that the analyzer and PC are connected LAN or Wi-Fi.

  • Page 166: Pc Remote Control Library

    8.3 PC Remote Control Library The libraries for Windows are available to make a user application software which remotely controls the analyzer from a PC. The library can be downloaded from LINEEYE website. ‫ ڦ‬For Windows Windows 11/10/8.1, VC++6.0 and VC++.NET are supported.

  • Page 167: Chapter 9 Documents

    Chapter 9 Documents 9.1 Calculation of the Block Check The block check is executed as follows. For ASYNC, SYNC, and BSC ・ Start calculation : When any characters set in “Begin code” is received, calculation will start with the next character. ・...
  • Page 168 Transparent mode (Only for ASYNC, SYNC/BSC) ・ If you select “ON” for the “Transparent” setting, the analyzer will enter the transparent mode and calculate BCC as follows. ・ The character set in the “DLE mode” is handled as the Data Link Escape code. ・...

  • Page 169: Send/Receive Clock

    9.2 Send/Receive Clock When sending/receiving data in synchronization with an external clock, setting of the transmission clock and the receiving clock varies according to the setting of DTE/DCE as shown below. Therefore, the synchronous clock for the specifications of the communicating device must be selected with “Clock”...
  • Page 170 ‫ ڦ‬Change the selection of clock and port This analyzer allows selection of the synchronous clock with “Clock” to enable monitoring/ simulating with any clock setting. This analyzer also allows to change specifications of the port with “DTE/DCE mode” in order to simulate the device whichever of DTE and DCE by an attached cable.

  • Page 171: About The Frame

    9.3 About the Frame The definition of 1 frame is as shown in the table below for each protocol. Protocol Definition of 1 frame A data string until detecting the idle time (1 to 100ms) which set at “Frame end ASYNC time”...

  • Page 172: Data Code Chart

    9.4 Data Code Chart ・ Blank box (not defined code) appeared in the code table is displayed in HEX. ・ For JIS7, EBCD and Baudot codes, SHIFT IN and SHIFT OUT displays are alternated in accordance to SI/SO data. ・ Display is started with the SHIFT IN display. ・...
  • Page 173 ‫ ڦ‬JIS7(7) For Roman characters For Kana characters SHIFT IN SHIFT OUT NU DL △ NU DL △ タ ミ SH D1 SH D1 。 ア チ ム SX D2 ” SX D2 「 イ ツ メ EX D3 EX D3 」...
  • Page 174 ‫ ڦ‬EBCDIK NU DL DS & △ ソ ＼ SH D1 ア タ ～ SX D2 FS SY イ チ ヘ EX D3 WS IR ウ ツ ホ PF RE BP PN エ テ マ HT NL LF TN オ ト...
  • Page 175 ‫ ڦ‬EBCD SHIFT IN SHIFT OUT < △ △ & ” > ‫ ڦ‬Transcode ‫ ڦ‬IPARS & △ < < △ -173-...

  • Page 176: Translation Display Specification

    9.5 Translation Display Specification BSC Translation display Only the control characters used in the BSC communication are displayed. T r a n s m i s s i o n EBCDIC ASCII Display Transcode control character (EBCDIK) (JIS) ・ A character next to DLE is always displayed unconditionally. ・...
  • Page 177 ‫ ڦ‬SDLC mnemonics chart (modulo 8) Mnemonic Name Control bit configuration TXD side RXD side TXDside RXDside b5 b4 INFO INFO INFOmation N(R) N(S) Receive Ready N(R) Recieve Not Ready N(R) REJect N(R) SNRM Set Normal Responce Mode SNRME Set Normal Response ModeExtended Request DISC DISConnect...
  • Page 178 ‫ ڦ‬X.25 mnemonics chart (modulo 8) Mnemonic Name Control bit configuration TXD side RXD side TXD side RXD side b8 b7 b6 b5 b4 b3 b2 b1 INFO INFO INFOmation N(R) N(S) Receive Ready N(R) P/F 0 Recieve Not Ready N(R) P/F 0 REJect...
  • Page 179 ‫ ڦ‬LAPD mnemonics chart Mnemonic Name Control bit configuration TXD side RXD side TXD side RXD side N(S) INFO INFOmation N(R) Receive Ready N(R) Recieve Not Ready N(R) REJect N(R) Set Asynchronous SABME BalancedMode Extended Disconnected Mode Unnumbered Infomation DISC DISConnect Unnumbered Acknowledgement...
  • Page 180 Packet level translation display ‫ ڦ‬X.25 packet composition ～ ～ Flag Address Control part Information Frame check Flag (8-bit) INFO frame part (16-bit) (8,16-bit) ～ ～ ～ ～ LCGN P-Type data 4-bit 4-bit 8-bit 8,16-bit ～ ～ Transltaion display P-Type M Q D Data ‫...
  • Page 181 ‫ ڦ‬LAPD packet configuration ～ ～ Flag Add ress sect ion Control section Data section Frame Flag (16-bit) INFO frame (8, 16-bit) check (16-bit) ～ ～ ～ ～ Protocol 0 fixing Length of call Call reference Call reference Message Information identifier 4-bit reference number...
  • Page 182 PPP translation display ‫ ڦ‬PPP frame constitution Flag Address Control Protocol Data section Flag section Code Identifier Data after length Translation screen Protocol Code Data Protocol value (h) Mnemonic Name 0001 Padding Padding Protocol 0021 Internet Protocol 0023 OSI Network Layer 0025 Xerox NS IDP 0027...
  • Page 183 Protocol value (h) Mnemonic Name SigmaNS Sigma Network Systems 8021 IPCP Internet Protocol Control Protocol 8023 OSINLCP OSI Network Layer Control Protocol 8025 XNSCP Xerox NS IDP Control Protocol 8027 DNCP DECnet Phase IV Control Protocol 8029 ATCP Apple Talk Control Protocol 802b IPXCP Novell IPX Control Protocol...
  • Page 184 MODBUS translation display ‫ ڦ‬Function code Code Display Description 0x01 Read coils Read Coils 0x02 Read discrete inputs Read Discrete inputs 0x03 Read holding registers Read Holding Registers 0x04 Read input registers Read Input Registers 0x05 Write single coil Write Single Coil 0x06 Write single register Write Single Register...
  • Page 185 ‫ ڦ‬Modbus detail view (KW1M conformed) Target function code ・ Read Holding Registers(0x03) ・ Write Single Register(0x06) ・ Write Multiple registers(0x10) (This function cannot be set to invalid. The function is not perfectly supported because it translates the previous frame as request. And it is impossible to display by converting it to prescale set value.) Translation displayed Meaning...
  • Page 186 Modbus protocol (conforming to KW1M) is displayed as following. Function Codes Request Response Translation Value Translation Value Read coils Starting address Byte count Decimal Quantity Decimal Status Binary (0x01) Read discrete inputs Starting address Byte count Decimal Quantity Decimal Input status Binary (0x02) Read holding registers...
  • Page 187 Write file record Request data length Decimal Response data length Decimal Reference type Reference type (0x15) File number Decimal File number Decimal Record number Decimal Record number Decimal Record length Decimal Record length Decimal Record data Record data Mask write register Reference address Reference address And_Mask...
  • Page 188 ‫ ڦ‬Sub-function(Detailed translation) Sub-function Display Display Return query data Data Restart communications option Data Return diagnostic register Data Change ASCII input delimiter Data Force listen only mode Data 10 Clear counters and diagnostic register Data 11 Return bus message count Count Decimal 12 Return bus communication error count...
  • Page 189 PROFIBUS translation display ‫ ڦ‬Function code Function Code Request Code Meaning Translation b7 b6 b5 b4 b3 b2 b1 b0 Clock Value Time Event Send Data Acknowledged - low priority SDA_LOW Send Data Not acknowledged - low priority SDN_LOW Send Data Acknowledged - high priority SDA_HIGH Send Data Not acknowledged SDN_HIGH...

  • Page 190: Maintenance

    * 4 : 4 All frames may not be recorded in the storage because of the high traffice line or low performance of the external storage. * 5 : For LE-8500XR-RT only. For PC connection. * 6 : According to our test conditions assuming a normal usage situation.

  • Page 191: Signal Definition Of

    10.2 Signal Definition of the Measurement Ports 2.3 Measurement Port 〇 RS-232C/RS-530 port It is for RS-232C/RS-530 port. To use it for X.20/X.21/RS-449/V.35 port with optional cables, select RS-530 port ([Menu] -> “interface” -> “port”). ‫ ڦ‬Signal definition of the RS-232C RS-232C(V.24) Input/Output (*3)
  • Page 192 ‫ ڦ‬Signal definition of RS-422/485 port (V35 Mode=off) X.20/21 (*1) RS-449 (*2) Input/Output (*3) RS-530(standard) Signal Dsub25 Dsub15 Dsub37 Pin MONITOR SIM-DTE SIM-DCE Shield ground TXD[A]:- T [A]:- SD[A]:- Transmission data TXD[B]:+ T [B]:+ SD[B]:+ RXD[A]:- R [A]:- RD[A]:- Receiving data RXD[B]:+ R [B]:+ RD[B]:+...
  • Page 193 ‫ ڦ‬Signal definition of RS-422/485 port (V35 Mode=on) V.35 ( *1 ) Input/Output ( *2 ) Port status Signal Dsub25 M type 34 MONITOR Shield ground TXD[A]:- TXD[A]:- Transmission data TXD[B]:+ TXD[B]:+ RXD[A]:- RXD[A]:- Receiving data RXD[B]:+ RXD[B]:+ Data set ready V24_DSR V24_DSR Terminal ready...
  • Page 194 〇 RS-422/485 port RS-422/485 measurement/test port. ‫ ڦ‬Signal definition of RS-422/485 port Input/Output Line state (*1) Signal Terminal MONITOR DTE TXD- Transmission data TXD+ RXD- Receiving data RXD+ Signal Ground *1: “I” is an input to the analyzer. “O” is an output from the analyzer. 〇...
  • Page 195 ‫ ڦ‬SPI signal definition Input/Output (*1) Line state Signal Pin name SIMULATION MONITOR MASTER SLAVE MOSI MOSI (*2) MISO MISO (*2) Signal Ground ‫ ڦ‬Signal definition of the external trigger Input/ Signal Signal level name Outpu (*1) LLVTTL(3.3V) / External trigger input External PPS input open collector 5V pull-up External trigger output1...

  • Page 196: Shortcut Keys

    10.3 Shortcut Keys The shortcut key operation similar to the operation by the menu number of the conventional model is available. By pressing [0] to [F] after [MENU], you can move to the frequently used setting screen. Shortcut key Setting display Remark [MENU],[0] Configuration...

  • Page 197: Factory Reset

    For this analyzer updating the firmware and recovering by writing back the entire system are available. The latest firmware file and system recovery file can be downloaded from the LINEEYE website. https://www.lineeye.co.jp/html/download_update.html Download it to an easy-to-find folder on your PC, unzip it, and check the firmware file (extension: FW3) or system recovery file (extension: FWR).

  • Page 198: Trouble Shooting

    An SD card cannot be used on ・ SD (SDXC) card of more than 32GB is not supported. the analyzer ・ Please use optional SD card from LINEEYE. An USB card cannot be used ・ USB flash drive formatted by exFAT and NTFS is not supported.
  • Page 199 Problem Cause / Remedy Connect the USB connector well. Cannot connected to a com- ・ puter via the USB port. ・ Check if the connection is blocked by security softwares. Cannot connect to the PC via ・ Conform the IP address and other network setting. LAN port ・...

  • Page 200: Warranty And After Service

    LINEEYE. If the defects exist during the Warranty period, please send back the products to LINEEYE distributors or LINEEYE. LINEEYE will repair or exchange them at no charge. In this case , the shipping charge will be at your own expense.
  • Page 201 After Support Read “FAQ” in our Website or email us. Please refer to “FAQ” . We also have support by email regarding the technical issue. When you use it, please register your product via our website. Website : 　　　 https://www.lineeye.co.jp/...
  • Page 202 LINEEYE CO., LTD. 4F., Marufuku Bldg., 39-1, Karahashi Nishihiragaki-cho, Minami-ku, Kyoto, 601-8468, Japan Tel : 075(693)0161 Fax : 075(693)0163 URL https://www.lineeye.com Email :info@lineeye.co.jp Printed in Japan M-4285RTE/LE...

This manual is also suitable for:

Le-8500x-rt

Table of Contents
