LineEye LE-1500R Quick Start Manual

Compact protocol analyzer

Advertisement

Quick Links

Quick Start Guide
When you unpack the product, make sure of the following.
AC Adapter: 1
RS-232C Monitor Cable : 1
USB Cable: 1
Utility CD: 1
Carrying Bag: 1
Quick Start Guide (this booklet): 1
Registration Card, Warranty: 1
Please let us know if you find any damage to the product or accessories
lacking.Save the outside package and contact LINEEYE or LINEEYE
distributors.
The Nickel-Hydrogen battery is built into the product. It is not full charged to keep
the quality. Before using the product, charge the battery first. If you dispose the
product, follow the regulations of your city.
The utility CD attached to the product contains the instruction manual.
Refer to the instruction manual for more detailed operation and important notes.
COMPACT PROTOCOL ANALYZER
---Note---
Ver. 1
LE-1500R

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LE-1500R and is the answer not in the manual?

Questions and answers

Summary of Contents for LineEye LE-1500R

  • Page 1 Quick Start Guide (this booklet): 1 Registration Card, Warranty: 1 Please let us know if you find any damage to the product or accessories lacking.Save the outside package and contact LINEEYE or LINEEYE distributors. ---Note--- The Nickel-Hydrogen battery is built into the product. It is not full charged to keep the quality.
  • Page 2: Read This First

    Warning Do not use the AC adapter or battery excepting the one LINEEYE designated.This may cause of exothermic reaction, ignition, electric shock, and malfunction. Do not disassemble, modify or repair analyzer.This may result in a injury, electric shock, and ignition.
  • Page 3: Table Of Contents

    ---- Contents ---- Read this first ������������������������� 1 Nomenclature ������������������������� 3 Charging the Battery ���������������������� 5 Turn on the Power, Software Reset ���������������� 5 Connect to the Target Devices ������������������ 6 Interface Setting ������������������������ 7 Measurement Function ��������������������� 7 Condition Setting ����������������������� 8 Communication Condition ��������������������...
  • Page 4: Nomenclature

    Nomenclature General ⑤ ① ⑧ ⑦ ⑥ ⑫ ⑨ ② ⑩ ⑬ ⑯ ④ ③ ⑮ ⑭ ⑪ N a m e F u n c t i o n Connects the AC adapter.(It deals with the polarity of plus and ①...
  • Page 5 Function [ RUN ] Starts monitoring, measuring or testing operation. [ STOP ] Stops monitoring, measuring or testing operation. Interrupts printing. Returns to the top menu for selecting functions and setting conditions. [ MENU ] *Returns to the previous screen. Displays the monitored or measured data.
  • Page 6: Charging The Battery

    * The analyzer can perform the battery drive for about 6.5 ~ 8 hours with the full charge. [Note] Do not use the AC adapter or battery excepting the one LINEEYE designated. If you are not going to use the analyzer for a long term, fill up the battery before putting back.
  • Page 7: Connect To The Target Devices

    Connect to the Target Devices Connect to RS-232C To monitor the communication data Connect the monitor cable (LE-25M1) to the Dsub Either is Dsub 25 pin connector 25pin connector of RS-232C for the target devices. Dsub25 To have the transmission/reception (simulation) test Set the interface condition according to the DTE/DCE MONITOR Cable(LE-25M1) specification and pin assignment of RS-232C cable...
  • Page 8: Interface Setting

    Interface Setting Select the measurement port which is used in the target device. Press [1] on the top menu screen([MENU]), and select “INTERFACE.” PORT (Selecting Ports to Measure) ■ Select "RS232C" to measure RS-232C, "RS485" to measure RS- 422/485, "TTL" to measure TTL interface.
  • Page 9: Condition Setting

    ONLINE Function Monitor communication data at real time (->P10) DELAY Function Measure the delay time of the signal changes and voltage of RS-232C/TTL. BERT Function Measure the transmission quality of communication line. (->P12) MANUAL Function Have the transmission/reception test by key operation. (->P11) FLOW Function Have the flow control on Simulation function.
  • Page 10: Communication Condition

    Communication Condition Press [MENU] -> [0] "Configuration" to set the communication conditions. Move " "mark by pressing [ ▼ ],[ ▲ ],[PAGE DOWN],[PAGE UP] keys or press [0] - [F] keys to set the configuration. PROTOCOL Select ASYNC for Asynchronous communication. S-SPEED (Sets the transmission communication speed.) R-SPEED (Sets the reception communication speed.) When "S-SPEED"...
  • Page 11: On-Line Monitor Function

    On-line Monitor Function This function records communication data in the capture buffer without affecting the communication. Also, it displays clearly following each communications protocol. Operation Press [MENU](top menu) and select“ONLINE". Press [0] to set the configuration. (->P9) Press [Menu]->[3]->[1] to set the time stamp, idle line, line state, and BSC translation.
  • Page 12: Simulation Function

    Simulation Function With the simulation function, the analyzer acts as the counterpart to the target device and performs transmission/ reception tests. In this section, it only describes the MANUAL mode, which sends the data registered in transmission table corresponds to the keys. To know about other modes, refer to the instruction manual stored in the CD.
  • Page 13: Bit Error Rate Test Function

    Bit Error Rate Test Function With Bit Error Rate Test function, the analyzer evaluates the quality of a data communication line of target devices (modems and converters etc.). (e.g.,) Connection of Loop-back test LINE DIGITAL DIGITAL ANALOG ANALOG       PART        PART PART PART...
  • Page 14: Useful Functions

    Useful Functions Trigger Function Trigger Function is for starting a specific action upon occurrence of a specific event as the trigger.For example, when receiving the specific data, it changes the external terminal or counts the error times. Press [MENU](top menu) ->[2]"Trigger". Enable the trigger by pressing [SHIFT]+[0]-[3].
  • Page 15: Timing Waveform Measurement

    *External Trigger Input/Output Signal name Pin name Input/Output Power for external circuit External trigger output 2 (TTL level output) Connector : 2.54mm pitch External trigger output 1 (TTL level output) pin header type External trigger input (TTL level input) Signal GND * 1: Voltage () can be set in "LEVEL"...
  • Page 16: Auto Start/Stop Function

    Auto Start/Stop Function The AUTO RUN function enables to start and stop a measurement at the specified time. It is useful when you monitor at the specific time only. Press [MENU]->[3]->[4]("AUTO RUN"). Set Mode (repeat mode), RUN TIME (starting time), STOP TIME (end time), P-ON RUN (Auto run when powering on).
  • Page 17: Auto Saving To A Usb Flash Or Sd Card

    Auto Saving to a USB flash or SD Card Transfer the data on the captured memory into the optional USB flash or SD Card at specified size automatically while measuring. It is useful for rare network trouble of unknown case by recording communication data for a long time.
  • Page 18 PC link software “LE-PC300R (Light Edition)” With this software you can take the monitor data into PC through USB port, AUX port(serial), Wi-Fi, or storage device. Wi-Fi is only available in Japan, USA, and Canada. ■ Install of PC link software The Utility folder of attached CD-ROM includes the light edition of the PC link software “LE- PC300R”.Double-click setup.exe in the folder and install it following the install wizard.
  • Page 19: Troubleshooting

    LED.This is not a product malfunction. "ILLEGAL CARD" is displayed after inserting the SD card and pressing [LOAD/SAVE]. Use the LINEEYE optional SD card. Max capacity of SD card depends on the analyzer model. LINEEYE does not warranty the SD card for other manufacture.
  • Page 20 LINEEYE CO., LTD. 4F., Marufuku Bldg., 39-1, Karahashi Nishihiragaki-cho, Minami-ku, Kyoto, 601-8468, Japan Phone : +81-75-693-0161 Fax : +81-75-693-0163 URL : http://www.lineeye.com Printed in Japan M-1715QE/LE...
