Summary of Contents for LineEye LE-150PF
- Page 1 Communication Protocol Analyzer Instruction Manual The attached CD-ROM contains the latest instruction manual in a PDF format. The 1th edition...
-
Page 3: Table Of Contents
Contents INTRODUCTION ............................1 NOTICE ..............................1 USER LIMITATION ..........................1 Safety Information ............................2 Read this first ! ! ............................2 Software License Agreement ........................3 Chapter 1 Before Using the Product ......................4 1.1 Composition ............................4 1.2 Outline ..............................4 1.3 Explanation of Each Part ........................ -
Page 4: Introduction
INTRODUCTION Thank you for your purchase of LINEEYE's protocol analyzer. To use it correctly, you are advised to read and understand this instruction manual thoroughly. Keep this together with the warranty. If you encounter any problems, you will find helpful information in this manual. -
Page 5: Safety Information
Safety Information Read this first ! ! This Safety Information includes the important information in order to not only have you learn the right way to use the analyzer, but also prevent you from causing damage to people and property. Before using, please read the main contents after you understand the following contents (symbols and marks). -
Page 6: Software License Agreement
5. Limitation of Liability In no event shall LINEEYE or its licensors be liable for loss of business or profits, or for any direct, indirect, incidental or consequential damages arising from products of this software or the related software. Besides LINEEYE shall not be liable damages arising from the equipment or the medium. -
Page 7: Chapter 1 Before Using The Product
: 1 (This book) Warranty * Please contact LINEEYE distributor or us if you find any insufficient part or any damage to the product caused by transportation. * Please keep the box carefully to use it when sending the product back to us for repair etc. -
Page 8: Explanation Of Each Part
*2: By starting measurement in the analyzer mode, you can set the PC's time to the internal clock. *3: Contact LINEEYE distributors or LINEEYE for support. SD/RD: Indicate the status of SD line (green light) and RD line (red light). - Page 9 4) RUN/STOP Switch Press to start measuring. Press for a while to stop measuring. 5) SD Card Slot Insert the SD card as the following figure. To remove the SD card, press the SD card and it will come out from the analyzer. 6) USB Connector Use the included USB cable to connect the host PC.
-
Page 10: Chapter 2 Installation
Chapter 2 Installation Install the analysis software to the PC you are going to operate the analyzer. 2.1 System Requirement PC/AT Compatible (DOS/V) HDD: 20MB + capacity for recording communication log OS: Windows 10/11 Port: USB port SD card drive: It is required for the Logger Mode to save log files and configuration settings. 2.2 Installation Guide ■... -
Page 11: Setting For Wi-Fi
2.3 Setting for Wi-Fi To use Wi-Fi function of LE-150PF/ LE-200PF, you need to power the analyzer after inserting SD card in which Wi-Fi configuration file (WLANCFG.WL) is written. < How to make a Wi-Fi setting file > 1. Click 「LE Wireless LAN configuration」 from the start menu. -
Page 12: Chapter 3 Basic Operation
<External power supply> ・ External power supply range for DC IN is from DC7V to 34V. ・ Consumption current of LE-150PF/LE-200PF is about 220 mA when Wi-Fi is used and about 160mA when Wi-Fi is not used. ・ Suitable DC plug is center plus 5.5mm (outside) / 2.1mm (inside). - Page 13 (12, 13, 15, 17th pins are only for LE-200PF.) * RS-422/485 Connect to the RS-422/485 pin of the Dsub 25 connector. 19 pin ------ TXD ( - ) 18 pin ------ TXD ( + ) 13 pin ------ RXC ( - ) 12 pin ------ RXC ( + ) 13 pin ------ RXD ( - ) 10 pin ------ RXD ( + )
- Page 14 [Connection for Simulation] Terminal Control Terminal Control 120ohm 1/2W LE-150PF/LE-200PF does not have the terminal control. To connect terminal controls on the analyzer, use the external controls (120Ω 1/2W) and put together with the signal lines. 120ohm 1/2W Terminal Control * TTL The option “OP-5ML”...
-
Page 15: Configuration Of Analysis Software
3.2 Configuration of Analysis Software ■ Data Window Execute the analysis software From [Start] menu of Windows, go to [LINEEYE] -> [LE-LINK20F]. Execute “LE-LINK20F” and then following display will be appeared. 1) Menu 1) → Perform various operations 2) →... - Page 16 * Measurement Data Select the saving folder and file size of measured data. [A folder to save the measured data] This folder is for saving the measured data. To change the settings, click “Change” button. Then the window to select a folder will be appeared.
- Page 17 ■ nalyzer Settings Click “ ” on the tool bar of the data window (or click “Measurement” -> “Measurement setting”) to set the protocol, speed and so on. On the measurement setting window, every time you change the setting on the left side of the window, the contents of the setting (on the right) will be different.
-
Page 18: Chapter 4 Interface Setup
Chapter 4 Interface Setup Select a port for monitoring. And, select output specifications for simulation. Click “ ” after setting. ■ Port Select from RS-232C or RS-422/485. * Mode Select DTE or DCE mode for simulation. * Polarity Select the signal polarity of data. N o r m a l l y s e l e c t s “... - Page 19 * DCE Meaning 1) CTS ON Time between RS becomes ON and CS becomes ON. 2) CTS OFF Time between RS becomes OFF and CS becomes OFF. 3) DCD ON Time between it starts sending and CD becomes ON. 4) RXD Send Time between CD becomes ON and it sends data to RD.
-
Page 20: Chapter 5 Monitor Function
Chapter 5 Monitor Function T he purpose of the monitor function is to record communication data into files without affecting the communication lines. Also, it is to display data clearly following each communications protocol. Not only communication data but also time stamp for data frame and idle time are recorded. As a result, error time and time out conditions are investigated. - Page 21 * SYNC code Set a synchronism settle data for SYNC. * Reset Code Set a synchronism reset code for SYNC. Set “FF”for normal operation. * Suppress Code When codes set in this section are monitored continuously, the second code and after ones are not stocked in the memory.
-
Page 22: Start And Stop Measuring
5.2 Start and Stop measuring ■ Start Measuring Click “ ” on the tool bar of data window (or click “Measurement” -> “Run measurement ”). “Measuring” is displayed in the status display, and display data from the analyzer on the screen. Click “ ”... - Page 23 ■ Error Data and Special Character Code Name Meaning Parity Error Displayed when parity is incompatible Framing Error Displayed when stop bit is "0". Parity & Framing Error Parity error and framing error are generated at the same time. Displayed when all of start bit, character bit, (parity bit), stop Break bit are "0".
- Page 24 ■ Display each frame in different line Click [Data monitor (Frame view)] tab to display frame divided by time stamp for ASYNC/SYNC communication. ■ Translation Display For HDLC/PPP measurement, “Data Monitor (translation view)” tab will be added. [PPP Translation] Item Meaning Time Shows the frame receiving time.
- Page 25 [SDLC/SDLCE/X.25/X.25E Frame Translation](LE-200PF) Item Meaning Time Shows the frame receiving time. Addr Displays the contents of address field in HEX. Type Displays the frame type in the form of mnemonic. Displays the frame sequence number in decimal. Displays the logical value of P/F bit. Displays the frame sequence number in decimal.
- Page 26 [X.25 Packet Translation] (LE-200PF) Meaning Time Shows the frame receiving time. Indicates the logic channel group number in decimal. Indicates the logic channel number in decimal. Type Displays the packet type in the form of mnemonic. Displays the packet sequence number in decimal. Displays the packet sequence number in decimal.
-
Page 27: Chapter 6 Simulation
Chapter 6 Simulation The simulation function is the tool that makes the analyzer operates as a counterpart to the test devices even if the target devices are not prepared, and that executes a test for transmission and reception following protocols. A margin can be evaluated at staggered communication speed on purpose because appointed communication speed can be set. -
Page 28: Data Transmission
6.2 Data Transmission Click “ “ on tool bar of data window (or “Measurement” -> “Measurement setting”) and select “Simulation (Manual)”. Item Description Delay Time Space between characters Repeat Repeat transmission of frame Idle Time Interval of repeat transmission 1) Click “ “... -
Page 29: Chapter 7 Useful Functions
Chapter 7 Useful Functions 7.1 Trigger Function Trigger function is to start a specific action upon occurrence of a specific event as the trigger. A perplexing flow of data, which is not easy to be analyzed in the normal monitor operation, is analyzed on the basis of occur rence of the specific event. - Page 30 4) Timer/Counter Trigger action will take place when the timer or the counter reaches a preset value. 5) Idle Time Trigger action will take place when the idle time reaches a preset value. Idle time has to be set in the “Record control” and the resolution of idle time should be the same as the one in the “Record control”...
-
Page 31: Timer/Counter
7) LED Out Light ON/OFF the specific LEDs. It is useful to check the measurement in visual during the data logger function. 8) Capture control Select “Enable (recording)”, “Disable (not recording)”, or “Change the state (Enable<- >Disable). If selecting “Disable”, monitored data will not be recorded as log data. - Page 32 * Idle Time Idle time which is in mark state (no communication time) can be measured. In ASYNC, idle time between frames indicate that the time between the last stop bit and next start bit. * Time Stamp This function can record the time when the top character of each frame transmitted through on the communication line.
-
Page 33: Text Conversion
7.4 Text Conversion Measured data can be converted into text file or CSV file. Clicks “ “ on the tool bar of the data window (or “Tool” -> “Text Conversion”). * Format Select from “Normal”, “with line state”, “Translated”, “CSV format (data)”... - Page 34 [Normal printing] [Normal printing with line state] [Translation printing (PPP)] [Dump printing (PPP)] -31-...
-
Page 35: Wave Monitor Setting
7.5 Wave Monitor Setting It is possible to measure the timing of change of the communication line with a time resolution of up to 50nsec and display it as a waveform like a logic analyzer do so. Clicks “ “ on the tool bar of the data window ( or select menu [ Measurement ] [ Measurement setting ] ), Sets the Wave Monitor setting. - Page 36 ■ Wave Monitor Data Display When wave monitor is enabled, a [Wave monitor] tab is added to the data window after measurement is stopped. (Wave monitor results cannot be displayed during measurement) 3) 4) 5) 6) 7) 1) Toolbar for wave monitor It is used to perform each operation of the wave monitor data display.
- Page 37 Following operations are possible on the toolbar for wave monitor. * Zooming rate change By moving the slider on the left end of the toolbar, the display magnification on the time axis can be changed. The zooming rate is displayed at the right side of the slider. * Signal ordering set Clicking [ ] button displays a window for settings.
-
Page 38: Chapter 8 Logger Mode
According to the configuration settings in the SD card, analyzer can record data for long hours without a PC. 8.1 Preparation of Logger Mode Execute the “LE-LOGGER20F” from start menu -> “LINEEYE” -> “LE-LOGGER20F”. ■ elect the model type ■ elect the configuration for Data logger mode. -
Page 39: Start And End Of The Measurement
5) Click “File” -> “Save”and save the configuration in the SD card. When you save the file, name it “LE150PF#.SU” for LE-150PF, and “LE200PF#.SU” for LE-200PF. Before starting the measurement as a data logger mode, read the configuration file to the analyzer. -
Page 40: Receive The Logger Files By Wi-Fi Connection
8.3 Receive the logger files by Wi-Fi connection. In logger mode, log files in the SD card can be transmitted to PC via Wi-Fi using “LE file downloader” (ledatadownload.exe). When you use this function, you need to make the Wi-Fi function valid by uploading the configuration file and Wi-Fi configuration file (WLANCFG.WL) made at “LE Wireless LAN configuration”... -
Page 41: Auto Run/Stop Function
8.4 Auto Run/Stop Function The analyzer can start/end measuring at the specified date. Set “Auto RUN/STOP” using the “LE-LOGGER20F”. * Mode [Monthly]: Start measuring at the specified time every month. [Daily]: Start measuring at the specified time every day. [Hourly]: Start measuring at the specified time every hour. -
Page 42: Chapter 9 Update Firmware
You can update to the latest firmware by the PC. Check the version of analysis software (LE-LINK20F) from “Help” menu. The latest firmware will be available from the LINEEYE website. Connect the analyzer to the PC and execute “LE-LINK20F” and follow the instruction. -
Page 43: Chapter 10 Specifications
Chapter 10 Specifications 10.1 Interface (RS-232C/422/485) Dsub 25pin connector is for RS-232C and RS-422/485 port. Signal definition of RS-232C RS-232C (V.24) Signal Input/Output (*3) Signal DSUB25 Pin (*2) MONITOR SIM-DTE SIM-DCE Shield ground Signal ground Transmission data Receiving data Transmission request Capable of transmission Terminal ready Data set ready... -
Page 44: External Input/Output Terminal
10.2 External Input/Output Terminal (2) (1) (4) (3) Pin No. Signal name Function Color of LE-4TG TRIGGER Open drain output, +5V, 10K ohm pull up TTL level input, range: -0.5V to 6.0V TRIGGER IN Brown +5V, 10K ohm pull up TRIGGER Open drain output, +5V, 10K ohm pull up Orange... -
Page 45: Specifications Of Analyzers
Environment of PC OS: Windows 10/11, PC: PC/AT compatible *1: Only SD/SDHC cards sold or attached by LINEEYE are supported. *2: The Wi-Fi function of the analyzer is available only in Japan, USA, Canada, and the EU nations where the product needs to be conformable to RE directive (2014/53/EU) for use. -
Page 46: Chapter 11 Warranty And Repair
* LINEEYE will repair the product according to the warranty. * After the warranty period, LINEEYE will repair the product for you to use the functions properly at your own expense. If your product needs to be repaired, please tell us the model name, serial number, purchased date, and the details of problems. - Page 48 LINE EYE CO., LTD. 4F., Marufuku Bldg., 39-1Karahashi Nishihiragaki-cho, Minami-ku, Kyoto, 601-8468 Japan Phone: 81-75-693-0161 Fax: 81-75-693-0163 URL https://www.lineeye.com Email :info@lineeye.co.jp M-1420PFE/LE...
