INIM SmartLink Advanced Series Installation And Programming Manual page 9

Installation and programming manual
PCB board
E
G
F
A
A
B Open-tamper microswitch
C
D
E
F
G Default-data reset button
H
I
J GSM signal reception LED
n.
1
2
3
4
5-6-7-8-9
14
15-16
17-18
Device description
D
H
B
Table 2-1:
Terminal board
Battery connector
USB connector
SIM card connector
Antenna connector
Buzzer
Activity LED
Table 2-2:
Terminals on the terminal board
icon/identifier
+ 14V
- 14V
+AUX
T1-T2-T3-T4-T5
PSTN
Metal backbox
C
I
J
A
Description of parts
K
L
M
N
O Dislodgement-tamper microswitch location
P
function
Positive power terminal
Negative power terminal
12V Ancillary power supply
Power supply negative (earth or GND)
Control panel input terminals: T1, T2, T3, T4 and T5
Earth connection
Internal telephone-line connection
Landline connection
P
M
L
O
N
K
L
M
Battery housing
Wall-mount screw locations
Screw holes
Cable entries
Antenna placement hole
M
L
N
L
M
