The wiring and respective balancing method depend on the type of
detector you are installing, and the level of protection you wish to
achieve. The detectors can be powered through:
terminal [+AUX/12V] and [-/negative] present on the PCB
from any ancillary 12V power source as long as it has a ground
reference (GND) in common with the ground reference of the
SmartLinkAdv
The resistors used for balancing are:
3K9Ohm 1/4W
6K8Ohm 1/4W
The following table indicates the protection level of each detector
type and the balancing options provided:
BALANCING
Infrared or
Double technology
Magnetic contact
(*) The level of protection of Single balanced mode is as secure as
Double balanced mode if the tamper contact of the detector is
connected to a balanced zone on the SmartLinkAdv.
For N.C. (normally closed) and N.O. balancing
(normally open), it is possible to detect two distinct
zone conditions:
standby
alarm
For each of these the SmartLinkAdv reads different
values of the equivalent resistance on the terminal,
shown below in Ohm:
Ohm
> 2 x 3900 + 6800
> 2 x 3900 + 6800
3900 + 6800
2 x 3900
3900
0
Installation
Wiring and balancing alarm
Table 4-1:
N.O.
very low
very low
N.C./N.O. Balancing
N.C.
alarm
standby
alarm
standby
alarm
alarm
standby
standby
detectors
Protection level
N.C.
Single
medium
low
(*)
low
medium
N.O.
alarm
alarm
alarm
alarm
4-8
Red
White
Orange
3K9
Ohm
1/4W
Red
Grey
Blue
6K8
Ohm
1/4W
Double
Double
zone
with EOL
high
medium
medium
4-8-1
Gold
Gold
Double
zone
high
high
