A Caller ID command is a command requested over-the-phone by
an end-user whose telephone number is present in the configuration
of the actions to be carried out following the command. This type of
telephone number must be associated with a user code.
The SmartLinkAdv recognizes the Caller ID and activates the
programmed actions.
The remaining credit control feature is subject to temporary or even
permanent unavailability caused by changes in the implementation of the
methods used by the GSM/GPRS service provider.
INIM provides device programming functions which may be capable of
restoring this feature, by means of manual changes to the respective
parameter settings.
The "answerphone" function, if enabled by the installer on the PSTN
or GSM network line, allows the SmartLinkAdv to answer incoming
phone calls. Following is the procedure which activates the
programmed action:
1. Call the number of the SIM Card inserted in the SmartLinkAdv or
the telephone number of the PSTN line connected to the device.
2. After a programmed number of rings, the SmartLinkAdv will
engage the line and play the voice message:
3. Enter a valid user-code then press "#" on the telephone key-
pad.
4. The SmartLinkAdv will start a voice message listing the short-
cuts associated with the entered code and the corresponding
keys on the telephone keypad (voice menu).
5. Activate the required commands by pressing the correspond-
ing keys on the telephone keypad.
The "Easyscan" function of the SmartLinkAdv allows the installer to
select the best GSM network provider for the SmartLinkAdv
installation, in accordance with the signal reception.
This function can be activated exclusively via the SmartLeague
software program and does not require a SIM card to be inserted in
the SmartLinkAdv.
Once initialized, the SmartLinkAdv scans the GSM signals in the
installation zone. When the scan is complete the software will show
a list of the operators detected in the area and the reception quality
of their signals. This data can be used by the installer to optimize
the installation.
The "jamming detector" function allows the SmartLinkAdv to check
for the presence of radio frequency and generate the "Jamming"
event should the any eventual source detected inhibit the proper
operating capacity of the device over the GSM network.
16
Type-in code followed by "#"

Jamming detector

Answerphone

Easyscan

Telephone dialler
INCOMING CALLER ID
COMMANDS
Note
3-6-2
3-7
3-8
SmartLinkAdv functions
