Installation and programming manual
The outputs can be configured as:
• Bistable
• Pulse
This is an output whose status can be controlled (activated/
deactivated) and used for other activations.
An electrical input point used for the management/control of signals
coming from two devices.
The terminal the zone is connected to must be configured as a
"double input zone". Terminals with this configuration allow the
system to distinguish between two distinct alarms coming from the
two different zones it is connected to.
The SmartLinkAdv is capable of recognizing specific external signals
coming from the PSTN or GSM network or via input terminals T1, T5
or internal signals such as "events".
When such events occur or when they clear (reset/return to default
status), the SmartLinkAdv can implement the following activations:
• activate outputs
• generate voice calls
• send digital protocol messages
• send SMS messages
In Appendix A, Events you can find the complete list of events
generated by the SmartLinkAdv.
The digital dialler function generates digital-protocol calls directly to
alarm receiving centres.
The available protocols are: Ademco 10bps, Ademco 14bps, Franklin
20bps, Radionics 40bps, Scantronic 10bps, Contact-ID, SIA-IP
The SMS dialler function generates outgoing SMS messages. The
outgoing SMS messages are sent in response to an event.
During the programming phase you can select the SMS message
type, which can be automatic, predefined by the SmartLinkAdv or
customized by the installer.
The voice-dialler function activates outgoing calls containing
recorded voice messages.
During the programming phase you can select the voice messages,
which can be either predefined by the SmartLinkAdv or customized
by the installer.
INIM does not guarantee the total availability of all the GSM
functions described in this manual, due to the various combinations
of GSM service providers, SIM types and telephone models that may
be in use.
SmartLinkAdv functions

Event activations

Dialler function

CONTROLLED OUTPUT
DOUBLE ZONE
3-3
3-4
DIGITAL
SMS FUNCTION
VOICE
ATTENTION!
13
