5. Ex-Data

5.1 NEC & CEC
Ex-Marking:
248090
Ambient temperature: -20 °C ≤ Ta ≤ +55 °C
Approved for Division 2 / Zone 2, Class I.

5.2 Audio Jack Parameter

The use of the standard Samsung EHS64AVFWE in-ear headphones is
allowed (no additional assessment required) or other intrinsically safe wired
audio accessory that must match with the entity parameter of the Tab-Ex
audio jack as follows:
Audio Jack output parameter
Uo/Voc 3.2 V
Io/Isc 150mA
Po 100mW
Ci 1.4uF
Li 100uH

6. Radiation Exposure Statement

Warning: This equipment complies with Federal Communications Commissi-
on Office of Engineering and Technology (OET) Bulletin 65 and Industry Cana-
da license exempt RSS limits for exposure to radio frequency (RF) radiation.
For typical operation, this device has been tested and meets FCC and IC
SAR guidelines. The FCC has granted an Equipment Authorization for this
device with all reported SAR Levels evaluated as in compliance with FCC RF
exposure guidelines. This device has FCC ID: A3LSMT397U [Model Number:
SM-T397U] or A3LSMT390 [Model Number: SM-T390]. The Industry Canada
(IC) has granted an IC Certification Number for this model device based on
the compliance of all reported SAR levels with the IC RF exposure guidelines.
NI CL I DIV 2 GRP A-D T5
Class I Zone 2 Group IIC T5
Audio Jack input parameter
Ui/Vmax 0V
Ii/Imax
Pi
Co/Ca
Lo/La
0mA
0mW
5uF
3.9mH
02*
®
5
