- Page 1 © 2019 Order #XXXXX VK-1222 General Layout 10’ 10’ Top View Perspective View SETUP INSTRUCTIONS If you would like to tell us about your experience with your setup instructions please email us at info@classicexhibits.com...
-
Page 2: General Setup Instructions
© 2019 Order #XXXXX General Information General Setup Instructions - Read entire setup instruction manual prior to WARNING unpacking parts and pieces. - The setup instructions are created specifically for this configuration. - Setup instructions are laid out sequentially in steps, including exploded views with detailed explanation for assembly. - Page 3 © 2019 Order #XXXXX Case Packing Top View of Each Level Lights Wings Base Plate Graphic Graphic Counter Setup Hardware w/ Shelf Level 1 (Bottom Level) Level 2 Level 3 Case 1 of 1...
-
Page 4: Front View
© 2019 Order #XXXXX VK-1222 Backwall Assembly Item Qty. Description Steps: Base Plate 1) Attach base plates [1] to verticals [2A] and [3A], using bolts. 2A,2B 42” Vertical Extrusion w/ Clamps 2) Connect verticals [2A to 2B] and [3A to 3B] with connection bars [B]. 3A,3B 42”... - Page 5 © 2019 Order #XXXXX VK-1222 Backwall Attachments Steps: Item Qty. Description 1) Connect lights to [5A/5B]. See Light Connection detail. 7/8/9 1/1/1 Assembled Header Frame 2) Attach assembled header frame [7/8/9] to [5A/5B]. Support Leg 3) Attach fabric graphic to Velcro on back of assembled header.
