Humminbird HELIX Series Installation Diagrams page 5

3
Trolling
Motor
Battery
CONSOLE UNIT
Networking
MFD
1
4
supplied with
MEGA Side
Imaging unit at
Cranking
Battery
INSTALLATION DIAGRAMS
Saltwater - Minn Kota Riptide Trolling Motor with
i-Pilot Link and (1) Console Mount Humminbird Unit
1
Ethernet Adapter Cable
720074-1
MK
2 GPS + Heading Sensor
Heading
Sensor
408400-1
Minn Kota Trolling Motor with
3
i-Pilot Link *
4 Transducer Splitter Cable
720101-1
5
High Speed Transducer (fiberglass hull)
710276-1
6
High Speed Transducer (aluminum hull)
710274-1
2
NMEA 0183
* One (1) AS ECX 30E Ethernet Extension cable included with i-Pilot Link trolling motor
The accessories and part numbers listed are valid as of April 2020. Installations shown are for
HELIX G3N and SOLIX G2 networking models and Minn Kota trolling motors with i-Pilot Link.
5
Transducer
console
Compatible Accessories
HELIX Series
Ethernet Adapter Cable
AS EC QDE NA
GPS + Heading Sensor
AS GPS HS 408400-1
720080-1
Minn Kota Trolling Motor with
i-Pilot Link *
Transducer Splitter Cable
9 M SIDB Y 720103-1
High Speed Transducer (fiberglass hull)
XP 9 HW T 710287-1
High Speed Transducer (aluminum hull)
XNT 9 HW T 710285-1
Ethernet 12V DC Power
SOLIX Series
AS GPS HS
AS GPS NMEA
14 M SIDB Y
XP 14 HW T
XNT 14 HW T
Transducer Cable Bluetooth® Signal
