Humminbird HELIX Series Installation Diagrams page 3

3
MK
Heading
Sensor
Trolling
Motor
Batteries
CONSOLE UNIT
Graph
1
4
5
Cranking
Transducer supplied with
Battery
MEGA Side Imaging unit at
INSTALLATION DIAGRAMS
Minn Kota Trolling Motor with i-Pilot Link
and (1) console-mounted Humminbird unit
1
Ethernet Adapter Cable
720074-1
2 GPS + Heading Sensor
408400-1
Minn Kota Trolling Motor with
3
i-Pilot Link *
4 Transducer Splitter Cable
720101-1
5 High Speed Transducer (fiberglass hull)
710276-1
High Speed Transducer (aluminum hull)
710274-1
NMEA 0183
* One (1) AS ECX 30E Ethernet Extension cable included with i-Pilot Link trolling motor
2
The accessories and part numbers listed are valid as of April 2020. Installations shown are for
HELIX G3N and SOLIX G2 networking models and Minn Kota trolling motors with i-Pilot Link.
console
Compatible Accessories
HELIX Series
Ethernet Adapter Cable
AS EC QDE NA
GPS + Heading Sensor
AS GPS HS 408400-1
720080-1
Minn Kota Trolling Motor with
i-Pilot Link *
Transducer Splitter Cable
9 M SIDB Y 720103-1
High Speed Transducer (fiberglass hull)
XP 9 HW T 710287-1
High Speed Transducer (aluminum hull)
XNT 9 HW T 710285-1
Ethernet 12V DC Power
SOLIX Series
AS GPS HS
AS GPS NMEA
14 M SIDB Y
XP 14 HW T
XNT 14 HW T
Transducer Cable Bluetooth® Signal
